7.3.1 Load distribution

Observe the legally required and good engineering practice
safety factors and construction regulations!
Only central loads are permitted!
The maximum forces acting on the retaining structure
F [N] when the internal fall prevention system is
max.
acting
Mass
355
[kg]
F [N]
max.
10 7,100
20 10,000
30 12,300
40 14,200
50 15,800
60 17,200
7.4 Fixing and assembly options on the lifting columns
(without accessory parts)
To install the lifting column to the connecting construction (overhead assembly), there are two DIN 74-F8
countersunk holes available in the base plate.
The use of incorrect fastening material can lead to damage:
•
Always use fastening screws with a minimum strength of 8.8 (while
observing the recommended minimum screw-in depth).
•
To ensure that the lifting column is safely supported, the base must be
dimensioned appropriately.
•
The maximum tensile forces specified in these technical instructions
(compression forces and moment loads not permitted) must always be
considered for the dimensioning.
40
Stroke [mm]
400 450
F [N] F [N]
max. max.
7,500 8,000
10,600 11,300
13,000 13,800
15,000 16,000
16,800 17,800
18,400 19,500
500
F [N]
max.
8,400
11,900
14,600
16,800
18,800
20,600
F
