6.4 Obvious danger points on the lifting columns

6.5 Electrical connection

6.5.1 Plug assignment

5 6
2
1
3

6.5.2 Hall sensor and circuitry

D3
E5 bottom
D1
Pin 1
Additional wiring is not required when using our Multilift controllers.
Multilift II safety
7
8
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
4
6. Product information
Motor +
N/A
+5 V
A
B
N/A
GND
Motor -
D4
+
E5 top
D2
Hall sensor
Pin 8
