6.1 Mode of operation

The RKMultilift lifting column works exclusively as a height-adjustable ceiling holder for e.g. monitors or
touch panels. It is driven by a DC motor.
6.2 Technical data

6.2.1 Technical specifications Multilift II safety

Floor area
Installation height
Stroke
Weight
Supply voltage (primary)
Protection class
Electrical connection
Max. power input
max. power consumption
Duty cycle (ED)
Lifetime
Protection class
Continuous sound pressure level
Lifting speed
Max. tensile force
Position signal
(Cancellation Hall sensor)
Transport and storage conditions
Operating conditions
Multilift II safety
355 mm, 400 mm, 452 mm, 498 mm
Basic weight: 5.27 kg + (0.017 kg/mm * Lifting range)
10000 double strokes with a stroke of 500 mm
Temperatures from -20 deg. C to +60 deg. C, relative humidity 30 per cent to 85 per
cent (no thawing), air pressure 700 hPA to 1060 hPA
In dry rooms at temperatures from +5 deg. C to +40 deg. C, relative humidity from
30 per cent to 75 per cent (no thawing), air pressure 700 hPA to 1060 hPA (up to an

6. Product information

312 x 90 mm (L x W)
Lifting range + 203 mm
24 V DC - 32 V DC
III
Mini-Fit Jr., 8-pin
4.0 A at U = 24 V DC
120 W
ED: S3 10 %
IP 20
less than 60 dBA
16 mm/s
600 N
Increments per mm travel:
6.5 per channel
altitude of 3000 m)
35
