Yamaha NMAX 155 Owner's Manual page 39

Fuel reserve tripmeter
1
1. Fuel reserve tripmeter
If the last segment of the fuel meter
starts flashing, the display automati-
cally changes to the fuel reserve trip-
meter "TRIP F" and starts counting the
distance traveled from that point.
To reset the fuel reserve tripmeter,
push the "MENU" switch until it is re-
set.
TIP
If you do not reset the fuel reserve trip-
meter manually, it will reset automati-
cally and disappear from the display
after refueling and traveling 5 km (3 mi).
EAU86910
Oil change tripmeter
1
1. Oil change indicator "OIL"
2. Oil change tripmeter
This tripmeter shows the distance trav-
eled since the last engine oil change.
The oil change indicator "OIL" will flash
at the initial 1000 km (600 mi), the next
3000 km (1800 mi), and then every
4000 km (2500 mi) thereafter.
To reset the oil change tripmeter and
oil change indicator, select the oil
change tripmeter, and then push the
"MENU" switch until "OIL" and the trip-
meter start flashing. While "OIL" and
the tripmeter are flashing, push the
"MENU" switch until the tripmeter is
reset.
Instrument and control functions
EAU86920
TIP
When the engine oil has
changed, the oil change tripmeter and
the oil change indicator must be reset.
Otherwise, the oil change indicator will
not come on at the correct time.
V-belt replacement tripmeter
2
1. V-belt replacement indicator "V-BELT"
2. V-belt replacement tripmeter
This tripmeter shows the distance trav-
eled since the V-belt was last replaced.
The V-belt replacement indicator "V-
BELT" will flash every 25000 km
(15500 mi) to indicate that the V-belt
should be replaced.
6-6
been
EAU86930
1
6
2
