Read this manual carefully before operating this vehicle.
OWNER'S MANUAL
MXT9L
LIT-11626-33-50
BD5-28199-11

Advertisement

Table of Contents
loading

Related Manuals for Yamaha MXT9L 2019

Summary of Contents for Yamaha MXT9L 2019

  • Page 1 Read this manual carefully before operating this vehicle. OWNER’S MANUAL MXT9L LIT-11626-33-50 BD5-28199-11...
  • Page 2 EAU10045 Operating, servicing and maintaining a passenger vehicle or off-road vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary, service your vehicle in a well-ventilated area and wear gloves or wash your...
  • Page 3 Introduction EAU10084 Congratulations on your purchase of the Yamaha MXT9L. This model is the result of Yamaha’s vast experience in the pro- duction of fine sporting, touring, and pacesetting racing machines. It represents the high degree of craftsmanship and re- liability that have made Yamaha a leader in these fields.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10194 MXT9L OWNER’S MANUAL ©2020 by Yamaha Motor Corporation, U.S.A. 1st edition, September 2019 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Corporation, U.S.A. is expressly prohibited. Printed in Japan.

  • Page 6: Table Of Contents

    Table of contents Location of important labels... 1-1 Rear view mirrors ......4-27 Why Yamalube......7-14 Adjusting the front fork ....4-27 Coolant ......... 7-15 Safety information......2-1 Adjusting the shock absorber Air filter element......7-16 assembly........4-29 Checking the engine idling Description ........3-1 Auxiliary DC jack ......4-30 speed ........
  • Page 7 Checking the front fork....7-29 STREET & DUAL-PURPOSE Checking the steering ....7-30 MOTORCYCLE LIMITED Lubricating the steering WARRANTY....... 10-8 bearings ........7-30 YAMAHA EXTENDED SERVICE Checking the wheel bearings ..7-30 (Y.E.S.)........10-10 Battery ...........7-31 Replacing the fuses.......7-32 Index ..........11-1 Vehicle lights .........7-34 Stability bar ........7-34...

  • Page 8: Location Of Important Labels

    Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 9 Location of important labels WARNING NOTICE Cleaning with alkaline or BEFORE YOU OPERATE THIS VEHICLE, READ acid cleaner, gasoline or THE OWNER’S MANUAL AND ALL LABELS. solvent will damage ALWAYS WEAR AN APPROVED MOTORCYCLE windshield. HELMET, eye protection, and protective clothing. Use neutral detergent.
  • Page 10 Location of important labels WARNING Improper loading can cause loss of control. Read owner’s manual for proper loading. 3JJ-28446-A1 TIRE INFORMATION Cold tire normal pressure should be set 1.5 kg {3 lbs} as follows. 3SA-24877-A0 • Up to 90 kg (198 lbs) load FRONT : 225 kPa, (2.25 kgf/cm²), 33 psi REAR...

  • Page 11: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU84510 out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 12 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 13 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 14 Yamaha accessories, which are avail- performed to your vehicle that change able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 15 Safety information  Remove all loose items from the operator and may limit control ability, therefore, such accesso- motorcycle.  Confirm there are no fuel or oil ries are not recommended.  Use caution when adding electri- leaks.  Shift the transmission into gear. cal accessories.

  • Page 16: Description

    Description EAU10411 Left view 1. Battery (page 7-31) 9. Engine oil filter cartridge (page 7-12) 2. Storage compartment (page 4-26) 3. Tool kit (page 7-2) 4. Seat lock (page 4-24) 5. Spring preload adjuster (page 4-29) 6. Rebound damping force adjuster (page 4-29) 7.

  • Page 17: Right View

    Description EAU10421 Right view 1. Fuses (page 7-32) 9. Brake pedal (page 4-18) 2. Rear brake fluid reservoir (page 7-23) 3. Fuel tank cap (page 4-21) 4. Rebound damping force adjuster (page 4-27) 5. Compression damping force adjuster (page 4-27) 6.

  • Page 18: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-16) 9. Main switch/steering lock (page 4-1) 2. Left handlebar switches (page 4-2) 3. Auxiliary DC jack (page 4-30) 4. Multi-function meter unit (page 4-9) 5. Front brake fluid reservoir (page 7-23) 6.

  • Page 19: Instrument And Control Functions

    Instrument and control functions To lock the steering EAU10462 EAU10662 Main switch/steering lock All electrical systems are off. The key can be removed. EWA10062 WARNING Never turn the key to “OFF” or “LOCK” while the vehicle is moving. Otherwise the electrical systems will LOCK be switched off, which may result in loss of control or an accident.

  • Page 20: Handlebar Switches

    Instrument and control functions To unlock the steering Right EAU66055 Handlebar switches Left 1. Stop/Run/Start switch “ ” 1. Push. 2. Drive mode switch “MODE” 2. Turn. 3. Hazard switch “ ” 1. “MENU” switch From the “LOCK” position, push the 2.
  • Page 21 Instrument and control functions EAU66040 EAU66010 EAU84530 Turn signal switch “ ” Hazard switch “ ” “SELECT” switch To signal a right-hand turn, push this With the key in the “ON” or “ ” posi- This switch is used to make setting switch to “...

  • Page 22: Indicator Lights And Warning Lights

    If the lights do as soon as possible. 4. High beam indicator light “ ” not come on, have a Yamaha dealer Even if the oil level is sufficient, the 5. Oil level warning light “ ”...
  • Page 23 If the warning light then go off. If the light does not come then go off. Otherwise, have a Yamaha comes on while riding, the anti-lock on, or if the light remains on, have a dealer check vehicle.

  • Page 24: Cruise Control System

    Instrument and control functions Activating and setting the cruise EAU84291 Cruise control system control system This model is equipped with a cruise 1. Push the cruise control power control system designed to maintain a switch “ ” located on the left set cruising speed.
  • Page 25 Instrument and control functions  Apply the front or rear brake. You can also manually increase your  Squeeze the clutch lever. traveling speed using the throttle. After  Use the shift pedal. you have accelerated, you can set a new cruising speed by pushing the Push the power switch to turn off the “SET–”...
  • Page 26 Instrument and control functions When traveling with a set cruising ing speed. If this occurs, acceler- speed, if the cruise control system is ate to the desired traveling speed Pushing the power switch while the deactivated under the above condi- using the throttle.

  • Page 27: Multi-Function Meter Unit

    Instrument and control functions multi-function meter unit EAU85260 Multi-function meter unit equipped with the following:  speedometer  tachometer  clock  fuel meter  eco indicator  transmission gear display  drive mode display  TCS display 1. Transmission gear display ...
  • Page 28 Instrument and control functions Speedometer The tachometer shows the engine 4. Push the “MENU” switch, and the speed. minute digits will start flashing. 5. Push the “SELECT” switch up or ECA10032 NOTICE down to set the minutes. Do not operate the engine in the ta- 6.
  • Page 29 If a problem is detected in the electrical is appropriate for the vehicle circuit, the fuel level segments will flash speed. repeatedly. If this occurs, have a Yamaha dealer check the vehicle. Transmission gear display Eco indicator 1. Drive mode display This display indicates which drive mode has been selected: “1”, “2”...
  • Page 30 Instrument and control functions This display indicates which traction Multi-function display control system setting has been se- lected: “1”, “2”, or “OFF”. For more de- tails on the TCS settings and how to select them, see page 4-19. QS indicator 1.
  • Page 31 Instrument and control functions When the last segment of the fuel me- Instantaneous fuel consumption Average fuel consumption ter starts flashing, the display changes to the fuel reserve tripmeter “TRIP F” and starts counting the distance trav- eled from that point. In this case, push “...
  • Page 32 Instrument and control functions  After resetting, “– –.–” will be  The temperature displayed may shown until the vehicle has trav- vary from the actual ambient tem-  When the coolant temperature is eled a sufficient distance. perature. below 104 °F, “Lo” will be dis- ...
  • Page 33 Instrument and control functions To adjust the display brightness is selected when the indicator To set the shift light off r/min 1. Turn the key to “OFF”. light flashes four times per se- The shift light can be set between 6000 2.

  • Page 34: D-Mode (Drive Mode)

    Instrument and control functions MODE 3 EAU84550 EAU12823 D-mode (drive mode) Clutch lever This mode offers response that is D-mode is an electronically controlled somewhat less sharp compared to engine performance system. MODE 2 for riding situations that re- EWA18440 quire especially sensitive throttle oper- WARNING ation.

  • Page 35: Shift Pedal

    Instrument and control functions EAU84321 EAU84560 Shift pedal Quick shift system The quick shift system (QS) allows for full-throttle, clutch lever-less, electron- ically-assisted upshifts. When the shift switch detects motion in the shift ped- al, engine power and drive torque are momentarily adjusted to allow the up- shift to occur.

  • Page 36: Brake Lever

    Instrument and control functions EAU26827 EAU12944 EAU84570 Brake lever Brake pedal The brake lever is located on the right The anti-lock brake system (ABS) acts side of the handlebar. To apply the on the front and rear brakes indepen- front brake, pull the lever toward the dently.

  • Page 37: Traction Control System

    Instrument and control functions  The ABS performs a self-check EAU76317 Traction control system when you first start off. During this The traction control system (TCS) time a clicking noise from the hy- helps maintain traction when acceler- draulic unit may be audible, and if ating on slippery surfaces, such as un- the brake lever or brake pedal is paved or wet roads.
  • Page 38 Instrument and control functions TCS “2”: Maximizes traction control settings while riding can distract the assist; wheel spin is most strongly con- operator and increase the risk of an trolled. accident. TCS settings can be changed only  When the vehicle is turned on, when the vehicle is stopped and the throttle closed.

  • Page 39: Fuel Tank Cap

    Yamaha deal- er check the vehicle as soon as possi- ble. 4. Have a Yamaha dealer check the vehicle and turn off the “ ” warning light. 1. Fuel tank cap lock cover 2.

  • Page 40: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.

  • Page 41: Fuel Tank Overflow Hose

    ECA11401 NOTICE EAU86110 Use only unleaded gasoline. The use Your Yamaha engine was designed to of leaded gasoline will cause severe use premium unleaded gasoline. Con- damage to internal engine parts, firm the pump octane number [(R+M)/2...

  • Page 42: Catalytic Converter

    Instrument and control functions EAU13435 EAU84580 Catalytic converter Seats See page 7-12 for canister information. The exhaust system contains catalytic converter(s) to reduce harmful exhaust Passenger seat emissions. EWA10863 To remove the passenger seat WARNING 1. Open the seat lock cover, insert The exhaust system is hot after op- the key into the seat lock, and then eration.
  • Page 43 Instrument and control functions To install the passenger seat To install the rider seat 1. Insert the projection on the front of 1. Insert the projection on the front of the passenger seat into the seat the rider seat into the seat holder holder as shown, and then push as shown, and then place the seat the rear of the seat down to lock it...

  • Page 44: Helmet Holding Cable

    Instrument and control functions EAU84590 EAU14465 Helmet holding cable Storage compartment A helmet holding cable is provided to allow you to secure helmet(s) to the ve- hicle. 1. Storage pouch 2. Helmet holding cable 1. Storage compartment 3. Pass the helmet holding cable The storage compartment is located through the buckle on the helmet under the passenger seat.

  • Page 45: Rear View Mirrors

    Instrument and control functions  Do not exceed the maximum EAU39672 EAU84601 Rear view mirrors Adjusting the front fork load of 195 kg (430 lb) for the ve- The rear view mirrors of this vehicle EWA10181 hicle. WARNING can be folded forward or backward for parking in narrow spaces.
  • Page 46 Instrument and control functions tions, however such adjustments Compression damping setting: are ineffective and may damage Minimum (soft): the suspension. 13 click(s) in direction (b) Standard: 8 click(s) in direction (b) Compression damping force Maximum (hard): Turn the adjusting screw in direction (a) 1 click(s) in direction (b) to increase the compression damping force.

  • Page 47: Adjusting The Shock Absorber Assembly

    Instrument and control functions tions, however such adjustments EAU84611 Adjusting the shock absorber are ineffective and may damage assembly the suspension. This shock absorber assembly is equipped with a spring preload adjust- Rebound damping force ing knob and a rebound damping force Turn the adjusting screw in direction (a) adjusting screw.

  • Page 48: Auxiliary Dc Jack

    Maximum (hard): worn-out shock absorber as- 0 turn(s) in direction (b) sembly yourself. Take the shock absorber assembly to a Yamaha dealer for any service. When turning the damping force ad- juster in direction (b), it may turn be- yond...

  • Page 49: Auxiliary Dc Connector

    This vehicle is equipped with an auxil- The sidestand is located on the left iary DC connector. Consult your side of the frame. Raise the sidestand Yamaha dealer before installing any or lower it with your foot while holding accessories. the vehicle upright.

  • Page 50: Ignition Circuit Cut-Off System

    Instrument and control functions this system regularly and have a EAU57952 Ignition circuit cut-off system Yamaha dealer repair it if it does not This system prevents in-gear engine function properly. starts unless the clutch lever is pulled and the sidestand is up. Also, it will...
  • Page 51 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 52: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-15 • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary.
  • Page 53 • Make sure that operation is smooth. • Check throttle grip free play. Throttle grip 7-17, 7-27 • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 7-26 •...
  • Page 54 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-31 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 55: Operation And Important Riding Points

    ECA10311 NOTICE there is a control or function you do not between 0 and 1600 km (1000 mi). For understand, ask your Yamaha dealer. this reason, you should read the fol-  Keep the engine speed out of EWA10272 lowing material carefully.

  • Page 56: Starting The Engine

    This model is equipped with:  the transmission is in the neutral Yamaha dealer check the vehicle.  a lean angle sensor. This sensor position or stops the engine in case of a vehi- ...

  • Page 57: Shifting

    Operation and important riding points  This model is equipped with a 2. Shift the transmission into first EAU84370 Shifting quick shift system. (See page gear. The neutral indicator light 4-17.) should go out. 3. Open the throttle gradually, and at ECA23990 NOTICE the same time, release the clutch...

  • Page 58: Parking

    Operation and important riding points 2. At the recommended shift points could cause loss of control, an EAU17214 Parking shown in the following table, shift accident and injury. It could also When parking, stop the engine, and to a lower gear. cause engine or drive train dam- then remove the key from the main 3.

  • Page 59: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 60: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 61: Periodic Maintenance Chart For The Emission Control System

     From 24000 mi (37000 km) or 36 months, repeat the maintenance intervals starting from 8000 mi (13000 km) or 12 months.  Items marked with an asterisk require special tools, data and technical skills, have a Yamaha dealer perform the ser- vice.
  • Page 62 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...

  • Page 63: General Maintenance And Lubrication Chart

    30 months • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. Air filter element • Replace. Every 24000 mi (37000 km) • Check operation. √ √...
  • Page 64 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months •...
  • Page 65 Periodic maintenance and adjustment INITIAL ODOMETER READINGS 600 mi 4000 mi 8000 mi 12000 mi 16000 mi 20000 mi ITEM ROUTINE (1000 km) (7000 km) (13000 km) (19000 km) (25000 km) (31000 km) 1 month 6 months 12 months 18 months 24 months 30 months Brake pedal pivot...
  • Page 66 Every 3 years Front and rear √ √ √ √ √ √ 27 * • Check operation. brake switches • Apply Yamaha cable lubricant or √ √ √ √ √ √ 28 * Control cables other suitable cable lubricant thoroughly.
  • Page 67 Periodic maintenance and adjustment • Every two years replace the internal components of the brake master cylinders and calipers, and change the brake fluid. • Replace the brake hoses every four years or sooner if cracked or damaged.

  • Page 68: Removing And Installing The Panel

    Periodic maintenance and adjustment EAU18752 Removing and installing the panel The panel shown needs to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the panel needs to be removed and installed. 1.

  • Page 69: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 70: Canister

    Periodic maintenance and adjustment To check the engine oil level EAU36112 EAU1990G Canister Engine oil 1. After warming up the engine, wait The engine oil level should be checked a few minutes for the oil level to regularly. In addition, the oil must be settle for an accurate reading.
  • Page 71 An oil filter wrench is available at a oil filler cap and add oil. Yamaha dealer. 5. Check the engine oil filler cap O- 5. Apply a thin coat of clean engine ring. Replace if damaged.

  • Page 72: Why Yamalube

    9. After checking the engine oil filler EAU85450 Why Yamalube cap O-ring, install the filler cap. YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion Wipe off any spilled oil before starting and belief that engine oil is an impor- the engine.

  • Page 73: Coolant

    2. Maximum level mark soft tap water instead. Do not 3. Minimum level mark If genuine Yamaha coolant is not avail- use hard water or salt water 3. If the coolant is at or below the mi- since it is harmful to the engine.

  • Page 74: Air Filter Element

    The coolant must be changed at the in- maintenance and lubrication chart. necessary, have it corrected by a tervals specified in the periodic main- Have a Yamaha dealer replace the air Yamaha dealer. tenance and lubrication chart. Have a filter element.

  • Page 75: Checking The Throttle Grip Free Play

    3.0–5.0 mm (0.12–0.20 in) proper tire pressure may cause se- Periodically check the throttle grip free vere injury or death from loss of play and, if necessary, have a Yamaha control.  The tire air pressure must be dealer adjust it.
  • Page 76 When a tire tread begins to show crosswise lines, Cold tire air pressure: Up to 90 kg (198 lb) load: have a Yamaha dealer replace Front: the tire immediately. 225 kPa (2.25 kgf/cm², 33 psi)  The replacement of all wheel...
  • Page 77 1. Tire air valve ed below have been approved for this atively poor grip on certain road 2. Tire air valve core model by Yamaha. surfaces until they have been 3. Tire air valve cap with seal “broken in”. Therefore, it is ad-...

  • Page 78: Cast Wheels

    Measure the clutch lever free play as clutch does not operate correctly, have note the following points regarding the shown. a Yamaha dealer check the internal specified wheels. 1 (a)  The clutch mechanism.

  • Page 79: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 80: Checking The Front And Rear Brake Pads

    1. Brake pad wear indicator groove peared, have a Yamaha dealer replace indicator groove almost appears, have the brake pads as a set. a Yamaha dealer replace the brake pads as a set.

  • Page 81: Checking The Brake Fluid Level

    Periodic maintenance and adjustment  Use only the specified brake flu- Rear brake EAU40262 Checking the brake fluid level id; otherwise, the rubber seals Before riding, check that the brake fluid may deteriorate, causing leak- is above the minimum level mark. age.

  • Page 82: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Yamaha dealer check the cause before Have a Yamaha dealer change the The drive chain slack should be further riding. brake fluid every 2 years. In addition,...
  • Page 83 Locknut: To adjust the drive chain slack wheel forward. 16 N·m (1.6 kgf·m, 12 lb·ft) Consult a Yamaha dealer before ad- justing the drive chain slack. 4. Make sure that the drive chain Using the alignment marks on each 1. Loosen the axle nut and the lock-...

  • Page 84: Cleaning And Lubricating The Drive Chain

    If a cable is wet areas. Service the drive chain as damaged or does not move smoothly, follows. have a Yamaha dealer check or re- place it. WARNING! Damage to the ECA10584 NOTICE outer housing of cables may result...

  • Page 85: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 86: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 87: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- ce and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 88: Checking The Steering

    The front and rear wheel bearings must cause danger. Therefore, the operation be checked by a Yamaha dealer at the of the steering must be checked by a intervals specified in the periodic main- Yamaha dealer at the intervals speci- tenance chart.

  • Page 89: Battery

     Electrolyte is poisonous and 3. Fully charge the battery before installation. NOTICE: When in- Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to stalling the battery, be sure to furic acid, which causes severe have discharged.

  • Page 90: Replacing The Fuses

    Periodic maintenance and adjustment connect the positive lead before EAU84650 Replacing the fuses connecting the negative lead. The fuse boxes and individual fuses [ECA16842] are located under the rider seat (see 4. After installation, make sure that page 4-24) and behind panel A (see the battery leads are properly con- page 7-10).
  • Page 91 Periodic maintenance and adjustment avoid causing extensive dam- age to the electrical system and possibly a fire. [EWA15132] Specified fuses: Main fuse: 50.0 A ABS motor fuse: 10 9 8 7 6 5 4 30.0 A Cruise control fuse: 1.0 A 1.

  • Page 92: Vehicle Lights

    ABS control unit fuse: bulbs. 5.0 A Accessory fuse: If a light does not come on, check the 5.0 A fuses and then have a Yamaha dealer Ignition fuse: check the vehicle. 15.0 A ECA16581 NOTICE Specified fuses (fuse box 3):...

  • Page 93: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 94: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 95 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 96: Motorcycle Care And Storage

    Be performance and extend the useful life  high-pressure washers sure to consult a Yamaha dealer for of many components. Washing, clean- steam-jet cleaners. Excessive ing, and polishing will also give you a advice on what products to use be-...
  • Page 97 Motorcycle care and storage chemicals such as, solvents, Washing windshield. Additionally, some gasoline, rust removers, brake 1. Rinse off any degreaser and spray cleaning compounds for plastic down the vehicle with a garden fluid, or antifreeze, etc. may scratch the windshield, so hose.

  • Page 98: Storage

    Motorcycle care and storage ply silicone or oil spray to seats, ECA26320 EAU84141 Storage NOTICE hand grips, rubber foot pegs or Always store the vehicle in a cool, dry  Do not apply wax to rubber or tire treads. Otherwise these place.
  • Page 99 Motorcycle care and storage 1. Make all necessary repairs and a. Remove the spark plug cap 8. Check and correct the tire air perform any outstanding mainte- and spark plug. pressure, and then lift the vehicle nance. b. Pour a teaspoonful of engine so that all wheels are off the 2.

  • Page 100: Specifications

    Specifications Dimensions: Starting system: Coolant quantity: Electric starter Overall length: Coolant reservoir (up to the maximum level Engine oil: 2150 mm (84.6 in) mark): Overall width: Recommended brand: 0.25 L (0.26 US qt, 0.22 Imp.qt) 885 mm (34.8 in) Radiator (including all routes): Overall height: 1.93 L (2.04 US qt, 1.70 Imp.qt) 1250 mm (49.2 in)
  • Page 101 Specifications Chassis: Electrical system: Track: System voltage: 410 mm (16.1 in) 12 V Front tire: Battery: Type: Model: Tubeless YTZ10S Size: Voltage, capacity: 120/70 R 15 M/C 56V 12 V, 8.6 Ah (10 HR) Manufacturer/model: Bulb wattage: BRIDGESTONE/A41F M Headlight: Rear tire: Type: Brake/tail light:...

  • Page 102: Consumer Information

    These identification numbers are need- EAU26411 Vehicle identification number ed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. 1. Engine serial number VEHICLE IDENTIFICATION NUMBER: The engine serial number is stamped into the crankcase.

  • Page 103: Diagnostic Connector

    Record the information on tion label this label in the space provided. This information will be needed when order- ing spare parts from a Yamaha dealer. EAU26382 Key identification number 1. Diagnostic connector 1. Vehicle Emission Control Information label...

  • Page 104: Vehicle Data Recording

    Although the sensors and recorded data will vary by model, the main data Yamaha will not disclose this data to a points are: third party except in the following cas-  Vehicle status and engine perfor- es.

  • Page 105: Reporting Safety Defects

    If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immedi- ately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Yamaha Motor Corporation, U.S.A. If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.

  • Page 106: Motorcycle Noise Regulation

    Consumer information EAU26561 Motorcycle noise regulation TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED: Federal law prohibits the following acts or the causing thereof: (1) The removal or rendering inoperative by any person other than for purposes of maintenance, repair, or replacement of any device or element of design incorporated into any new vehicle for the purpose of noise control prior to its sale or delivery to the ultimate purchaser or while it is in use or (2) the use of the vehicle after such device or element of design has been removed or rendered inoperative by any person.

  • Page 107: Maintenance Record

    Consumer information EAU26633 Maintenance record Copies of work orders and/or receipts for parts purchased and installed on your vehicle will be required to document that maintenance has been completed in accordance with the emissions warranty. The chart below is printed only as a reminder that maintenance work is required.
  • Page 108 Consumer information Maintenance Date of Servicing dealer Mileage Remarks interval service name and address 36000 mi (55000 km) or 54 months 40000 mi (61000 km) or 60 months 10-7...
  • Page 109 Consumer information EAU61803 YAMAHA MOTOR CORPORATION, U.S.A. 2020 AND LATER MODEL STREET & DUAL-PURPOSE MOTORCYCLE LIMITED WARRANTY ENGINE Yamaha Motor Corporation, U.S.A. hereby warrants that Give notice to an authorized Yamaha motorcycle DISPLACEMENT each new Yamaha motorcycle purchased from an...

  • Page 110: Yamaha Motor

    CUSTOMER SERVICE What costs are my responsibility during the warranty period? If your machine requires warranty service, you must take it to any authorized Yamaha The customer’s responsibility includes all costs of normal maintenance services, motorcycle dealer within the continental United States. Be sure to bring your warranty non-warranty repairs, accident and collision damages, and oil, oil filters, air filters, registration card or other valid proof of the original date of purchase.

  • Page 111: Yamaha Extended Service (Y.e.s.)

    This excellent Y.E.S. plan coverage is only available to warranty. See the sample contract at your Yamaha Yamaha owners like you, and only while your Yamaha is still dealer to see how comforting uninterrupted factory- within the Yamaha Limited Warranty period. So visit your backed protection can be.
  • Page 112 TRIP coverage right away, and you’ll rest easy knowing you’ll have strong factory-backed protection even after your Yamaha Limited Warranty expires. A special note: If visiting your dealer isn’t convenient, contact Yamaha with your VIN number and we’ll be happy to help you get the YAMAHA EXTENDED SERVICE Y.E.S.

  • Page 113: Index

    Index D-mode (drive mode) ......4-16 Drive chain, cleaning and lubricating ... 7-26 ABS............4-18 Main switch/steering lock....... 4-1 Drive chain slack ........7-24 ABS warning light ........4-5 Maintenance and lubrication, periodic ... 7-5 Drive mode switch ......... 4-3 Air filter element........
  • Page 114 Index Spark plugs, checking ......7-11 Specifications .........9-1 Yamalube ..........7-14 Stability bar...........7-34 Starting the engine........6-2 Steering bearings, lubricating ....7-30 Steering, checking ........7-30 Stop/Run/Start switch ......4-3 Storage ...........8-3 Storage compartment......4-26 Swingarm pivots, lubricating ....7-29 Throttle grip and cable, checking and lubricating...........7-27 Throttle grip free play, checking ...7-17 Tires ............7-17 Tool kit ............7-2...
  • Page 115 Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products. They’re formulated and approved by the toughest judges we know: the Yamaha engineering teams that know your Yamaha from the inside out.
  • Page 116 PRINTED IN JAPAN 2019.10-0.3×1 CR (E)

This manual is also suitable for:
