OWNER'S MANUAL
MOTORCYCLE
MXT890D (NIKEN GT)
Read this manual carefully
before operating this vehicle.
BFD-28199-E0
For your safety - pre-operation checks
1
2
3
4
5
6
7
8
9
10
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NIKEN GT 2023 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yamaha NIKEN GT 2023

Summary of Contents for Yamaha NIKEN GT 2023

  • Page 1: Table Of Contents

    Read this manual carefully before operating this vehicle. Safety information OWNER’S MANUAL Description Smartphone Connectivity System Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage Specifications MOTORCYCLE Consumer information MXT890D (NIKEN GT)
  • Page 2 For Europe Declaration of Conformity: Hereby, YAMAHA MOTOR ELECTRONICS Co., Ltd declares that the radio equipment type, IMMOBILIZER, BFD-00 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://global.yamaha-motor.com/eu_doc/...
  • Page 3 For UK Declaration of Conformity: Hereby, YAMAHA MOTOR ELECTRONICS Co., Ltd declares that the radio equipment type, IMMOBILIZER, BFD-00 is in compliance with the Radio Equipment Regulations 2017. The full text of the declaration of conformity is available at the following internet address: https://global.yamaha-motor.com/eu_doc/...
  • Page 4 EAU96870 For Israel ‫מספר אישור התאמה מטעם משרד התקשורת‬ 55-13843 ‫חל איסור לבצע פעולות במכשיר שיש בהן כדי לשנות את תכונותיו‬ ‫האלחוטיות של המכשיר, ובכלל זה שינוי תוכנה, החלפת‬ ‫חיצונית, בלא‬ ‫אנטנה מקורית או הוספת אפשרות לחיבור לאנטנה‬ ‫אלחוטיות‬ ‫קבלת אישור משרד התקשורת, בשל החשש להפרעות‬ ‫חל...
  • Page 5 No.270, Huaya 2nd Rd., Guishan Dist., Taoyuan City 333, Taiwan, R.O.C. Importer (EU): YAMAHA MOTOR EUROPE N.V. Koolhovenlaan 101, 1119 NC Schiphol-Rijk, 1117 ZN, Schiphol, the Netherlands Importer (UK): YAMAHA MOTOR EUROPE N.V., BRANCH UK Units A2-A3, Kingswey Business Park, Forsyth Road, Woking, Surrey. GU21 5SA. United Kingdom.
  • Page 6 EAU98372 Use of trade marks ® The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. Android™ is a trademark of Google LLC. ® ® Wi-Fi is a registered trademark of Wi-Fi Alliance iOS is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
  • Page 7 EAU10103 Welcome to the Yamaha world of motorcycling! As the owner of the MXT890D, you are benefiting from Yamaha’s vast experience and newest technology regarding the design and manufacture of high-quality products, which have earned Yamaha a reputation for dependability.

  • Page 8: Important Manual Information

    Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 9 Important manual information EAU10202 MXT890D OWNER’S MANUAL ©2023 by Yamaha Motor Co., Ltd. 1st edition, September 2022 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 10 Table of contents Safety information......1-1 Brake lever ........4-36 Parking..........6-5 Brake pedal........4-36 Description ........2-1 ABS ..........4-36 Periodic maintenance and Left view ......... 2-1 Fuel tank cap ........4-37 adjustment........7-1 Right view........2-2 Fuel ..........4-38 Tool kit ..........7-2 Controls and instruments ....
  • Page 11 Table of contents Changing the brake fluid ....7-21 Specifications ........9-1 Drive chain slack ......7-22 Cleaning and lubricating the Consumer information....10-1 drive chain........7-23 Identification numbers ....10-1 Checking and lubricating the Diagnostic connector....10-2 cables.........7-24 Vehicle data recording ....10-2 Checking and lubricating the throttle grip ........7-24 Index ..........

  • Page 12: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU84510 out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 13 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 14 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 15 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 16 Safety information  Remove all loose items from the operator and may limit control ability, therefore, such accesso- motorcycle.  Confirm there are no fuel or oil ries are not recommended.  Use caution when adding electri- leaks.  Shift the transmission into gear. cal accessories.

  • Page 17: Description

    Description EAU10411 Left view 1. Windscreen (page 4-43) 2. Power outlet (page 4-47) 3. Storage compartment (page 4-42) 4. Tool kit (page 7-2) 5. Spring preload adjuster (page 4-45) 6. Rebound damping force adjuster (page 4-45) 7. Shift pedal (page 4-35)

  • Page 18: Right View

    Description EAU10421 Right view 1. Seat lock (page 4-41) 9. Engine oil level check window (page 7-11) 2. Battery (page 7-29) 10.Engine oil filler cap (page 7-11) 3. Fuses (page 7-30) 11.Brake pedal (page 4-36) 4. Rear brake fluid reservoir (page 7-20) 5.

  • Page 19: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 4-35) 9. Grip warmer (page 4-25) 2. Left handlebar switches (page 4-3) 10.Main switch/steering lock (page 4-2) 3. USB jack (page 4-48) 4. Multi-function meter unit (page 4-9) 5. Front brake fluid reservoir (page 7-20) 6.

  • Page 20: Smartphone Connectivity System

    Smartphone Connectivity System  After disconnecting/reconnecting EAU96128 Type of con- Smart features (communica- Smart Feature: nection: the battery, the CCU takes about tion control unit) GPS navigation (Audio 1 minute to boot. route guidance) (See page EWA21412 3-8.) WARNING Bluetooth Phone (See page 3-9.) ...
  • Page 21 Smartphone Connectivity System  Operate the joystick left-right Joystick/Home button MyRide - Link app  Short press enter “ ” Menu system operation:  Operate the joystick left-right-up- down to select and adjust menu items.  Short press enter “ ” to execute a selection.

  • Page 22: Initial Setup

    Smartphone Connectivity System  At facilities nearby that are EAU96107 Initial setup emitting strong radio waves (TV  Use of MyRide - Link is subject to or radio towers, power plants, your agreement to the MyRide - To use smart features: broadcasting stations, airports, Link terms of use.
  • Page 23 Smartphone Connectivity System  You can also pair by navigating Applications” → “Settings” to “ → “Connections” → “Bluetooth” → “Make system discoverable” in the menu system and then search for the vehicle’s CCU name in the smartphone’s bluetooth settings. The vehicle’s CCU name will be 1.
  • Page 24 Smartphone Connectivity System 3. In the MyRide – Link app, open “Settings” and then open “Vehi-  A request will appear on your cles”. Select the “+” in the top smartphone to share contact in- right corner of the screen and your formation with the vehicle.
  • Page 25 Smartphone Connectivity System  If a Bluetooth pairing record is de- password must be at least 8 digits leted from either the smartphone in length. The default password is or the CCU, the pairing record in random. the MyRide - Link app must also be deleted and paired again.
  • Page 26 Smartphone Connectivity System USB connection Connect a smartphone via the USB jack located in the front storage com- partment. (See page 4-48.) 1 1 1 After some time, your headset de- When connected, the display will vice name should appear on the switch to “Paired device list”...

  • Page 27: Navigation System: Garmin Motorize

    USB. Garmin Motorize terms of use.  Yamaha shall not be liable for any How to use the navigation system: damages resulting from the use of The navigation system is controlled us- the Garmin Motorize app.

  • Page 28: Telephone

    Smartphone Connectivity System answer the call. The active phone call EAU96138 Telephone indicator icon “ ” will appear on the This vehicle is equipped with a tele- top of the main display for the duration phone function that utilizes your smart- of the call.
  • Page 29 Smartphone Connectivity System Highlight the volume icon and operate play. The call audio will play the joystick up-down to adjust the call through the connected Bluetooth volume level. Highlight the end call headset. icon and short press enter “ ” to hang up the call.

  • Page 30: Connection Troubleshooting

    Smartphone Connectivity System If the error persists, try the following: EAU96882 Connection troubleshooting 1. Turn OFF the vehicle power. After If a connection error occurs between 30 seconds, turn ON the vehicle the smartphone, MyRide - Link app, power again. Garmin Motorize app and/or CCU, the 2.

  • Page 31: Instrument And Control Functions

     Do not place near magnets. Yamaha dealer to have them re-regis-  Do not place near items that tered. 1. Code re-registering key (red bow) 2. Standard keys (black bow) transmit electrical signals.

  • Page 32: Main Switch/Steering Lock

    Instrument and control functions EAU10474 EAU84035 EAU73803 Main switch/steering lock LOCK All electrical circuits are supplied with The steering is locked and all electrical power and the vehicle lights are turned systems are off. The key can be re- on. The engine can be started. The key moved.

  • Page 33: Handlebar Switches

    Instrument and control functions Right EAU66058 Handlebar switches If the steering will not lock, try turning Left the handlebars back to the right slight- To unlock the steering 1. Engine stop switch “ ” 2. YRC mode switch “MODE” 3. Hazard switch “ ”...
  • Page 34 Instrument and control functions turn off the hazard lights, turn the main EAU97550 Engine stop switch “ ” switch to the “ON” position and oper- Set this switch to “ ” before starting ate the hazard switch again. the engine. Set this switch to “ ”...
  • Page 35 Instrument and control functions  Operate the joystick left-right /  Long press enter “ ” to mute/un- Short press HB “ ” to open the mute all sound.  Operate the joystick left-right / pop-up menu.  Long press HB “ ”...

  • Page 36: Indicator Lights And Warning Lights

    If this occurs,  Do not add any electrical acces- have a Yamaha dealer check the on- sories that interfere with engine board diagnostic system. The electri- control.
  • Page 37  Maintain the drive chain properly. work correctly. Have a Yamaha dealer If the traction control system is turned  Maintain correct tire pressure. check the vehicle as soon as possible.
  • Page 38  If the engine is overheating, the do not start the engine, take the 30 seconds have passed, the indicator vehicle and all 3 keys to a Yamaha coolant temperature warning light will flash steadily to indicate the dealer to have the standard keys icon will come on.

  • Page 39: Display

    When the vehicle is turned on, this light 1. Indicator icons should come on for a few seconds and 2. Clock then go off. Otherwise, have a Yamaha 3. Tachometer dealer check the vehicle. 4. Transmission gear display 5. Quick shifter indicator “...
  • Page 40 Instrument and control functions When the menu system or the naviga- Fuel meter Low fuel indicator icon “ ” tion function are open, the information The fuel meter indicates the amount of This icon comes on when approxi- on the main display is relocated as fuel in the fuel tank.
  • Page 41 Instrument and control functions ECA26410 Wi-Fi connectivity indicator icon “ ” MyRide - Link app indicator icon “ ” NOTICE This icon indicates Wi-Fi connection This icon comes on when the MyRide - Do not continue to operate the en- status.
  • Page 42 Instrument and control functions icon stays on until you turn the vehicle ECA17932 NOTICE off or check the notifications by navi- The upshift and downshift functions Applications” → “Notifi-  Be sure to wear gloves when gating to “ are independent and can be activated cations”in the menu system.
  • Page 43 Instrument and control functions  Trip timer (TRIP TIME) Vehicle information display up/down to cycle which information  Cruise control system set speed display favorite is shown at the top of (CRUISE) the display. On the left-side display, only 3 items are displayed at a time.
  • Page 44 Instrument and control functions Two tripmeters (TRIP 1 / TRIP 2) distance traveled from that point. After will appear below the “ ”. The TRIP 1 and TRIP 2 show the distance refueling and traveling some distance, display items can be selected us- traveled since they were last set to ze- TRIP F will automatically disappear.

  • Page 45: Pop-Up Menu System

    Instrument and control functions  If the vehicle coolant temperature  Short press enter “ ” to execute EAU99356 Pop-up menu system is too high the coolant tempera- a selection. ture display will read “Hi”.  Short press HB “ ”...
  • Page 46 Instrument and control functions Access simple pop-up au- dio player. (See page “Audio” Each of the three themes has small 4-16.) variations which change when the YRC Access the smartphone application menu. (See mode is adjusted using the YRC mode “Applications”...
  • Page 47 Instrument and control functions Operate the joystick up-down to adjust module. If the volume is too high the volume. Operate the joystick left- or low, try adjusting the volume  The order of the icons can be or- right to skip to previous/next track. settings on your smartphone and ganized using the MyRide - Link Short press enter “...
  • Page 48 Instrument and control functions Applications” → “Settings” → Applications” → “Settings” → “Media”: Audio play and navigation “ “ “Audio” → “Equalizer” “Audio” → “Audio output” system volume. 20 levels. “Phone”: Phone call volume. 20 levels. Phone call volume is also adjustable via the pop-up menu telephone func- tion.
  • Page 49 Instrument and control functions Applications” → “Settings” → This module controls Bluetooth con- “ nections to smartphones and head- “Connections” sets. For instructions on pairing / connecting Bluetooth devices. (See page 3-3, 3-7.) If “Bluetooth auto connect” is enabled, the CCU will automatically connect with any previously paired devices which are available.
  • Page 50 “Completed.” is cord must be deleted from the To update system software: displayed. smartphone in order to pair it 1. Visit the Yamaha homepage and again. download the latest software up- date to a USB storage device. Applications” → “Settings” →...
  • Page 51 Instrument and control functions Do not turn the vehicle power off, re- This module can not be exited with move the USB drive, or put the vehicle short press HB. Use Long press HB to in motion until the update is complet- exit.
  • Page 52 Instrument and control functions Applications” → “Telephone” not completed, the CCU will not track, Play/Pause, Repeat off/Repeat “ be able to pair with the smart- all/Repeat one) short press If no call is active then a recent contact phone again. enter “...
  • Page 53 Instrument and control functions  Permission must be granted on If a call is started by selecting a pear (see page 4-10). Select a notifica- name/number from the list the follow- the smartphone before contact in- tion by short pressing enter “ ” to ing active call screen will appear: formation can be downloaded to view it.
  • Page 54 Instrument and control functions When there is an active call, this item will appear in the pop-up menu. Se- lecting it will open the telephone func- tion at the bottom of the display. (See page 3-9.) “ Traction Control” Weather information is shown here. If the traction control is already on, Update the information from your confirm “TCS OFF”...
  • Page 55 Instrument and control functions  The traction control system turns Machine Settings” → “Mainte- After maintenance to one of the items “ on automatically when the vehicle has been completed, select it by short nance” power is turned on. pressing enter “ ” and reset it. Machine Settings”...
  • Page 56 Instrument and control functions To manually adjust the clock, highlight The three vehicle information display items by operating the joystick left- favorites can be selected here. The fa- When “mile” is selected for the mileage right. Operate the joystick up-down to vorited items will appear on the right- unit, the fuel consumption unit is auto- adjust the value of the highlighted item.
  • Page 57 Instrument and control functions  Turn the quick shifter ON/OFF for Machine Settings” → “YRC Set- ing the joystick up-down. Confirm the “ settings by short pressing enter “ ” upshifts “QS ” and downshifts ting” and return to the previous menu. “QS ”...
  • Page 58 Instrument and control functions Machine Settings” → “Shift Indi- “ cator” TCS (Traction control system) Quick shifter This model uses a variable traction The quick shifter is divided into QS This module contains settings for the control system. For each setting level, (upshift) and QS (downshift) sec- shift indicator light.
  • Page 59 Instrument and control functions Select “ON” to have the indicator light Confirm the settings by short pressing steadily, “FLASH” to have the shift in- enter “ ” and return to the previous  The “Start” r/min cannot be higher dicator flash when the indicator start menu.

  • Page 60: Cruise Control System

    Instrument and control functions Machine Settings” → “All Reset” EAU99612 “ Cruise control system This model is equipped with a cruise control system designed to maintain a 1 1 1 set cruising speed. The cruise control system operates only when riding in 4th, 5th or 6th gear at speeds between about 50 km/h (31 mi/h) and 160 km/h (100 mi/h).
  • Page 61 Instrument and control functions  Pull the clutch lever. 2. Push the “SET–” side of the cruise you return the throttle grip, the vehicle  Shift gears. control setting switch to activate will decelerate to the previously set the cruise control system. Your cruising speed.

  • Page 62: Yrc Mode (Drive Mode)

    Instrument and control functions If the cruise control system is automat- EAU99782 YRC mode (drive mode) ically deactivated, the “ ” indicator Whenever the cruise control system or “YRC mode” is an electronically con- light will turn off and the “ ”...

  • Page 63: Quick Shifter

    Instrument and control functions  Accelerating (open throttle) RAIN “RN” - Mild engine response and EAU99571 Quick shifter limits engine output The quick shifter allows for clutch le- CUSTOM “CU” - User can customize Downshifting conditions ver-less, electronically-assisted shift-  Vehicle speed of at least 20 km/h the “PWR”...

  • Page 64: Traction Control System

    Yamaha dealer check the extended period of time. Other- ping. As with any vehicle, approach vehicle as soon as possible.

  • Page 65: Clutch Lever

    Instrument and control functions EAU12823 EAU83692 Clutch lever Shift pedal To prevent unintended shifts, the quick shifter is programmed to ignore un- clear input signals. Therefore, be sure to shift using quick and sufficiently forceful inputs. 1. Clutch lever 1. Shift pedal 2.

  • Page 66: Brake Lever

    Instrument and control functions EAU26827 EAU12944 EAU84570 Brake lever Brake pedal The brake lever is located on the right The anti-lock brake system (ABS) acts side of the handlebar. To apply the on the front and rear brakes indepen- front brake, pull the lever toward the dently.

  • Page 67: Fuel Tank Cap

    Instrument and control functions  The ABS performs a self-check EAU13077 Fuel tank cap when you first start off. During this time a clicking noise from the hy- draulic unit may be audible, and if the brake lever or brake pedal is applied a vibration can be felt, but this is not a malfunction.

  • Page 68: Fuel

    Instrument and control functions EAU13222 Fuel The fuel tank cap cannot be closed un- Make sure there is sufficient gasoline in less the key is in the lock. In addition, the tank. the key cannot be removed if the cap is EWA10882 WARNING not properly closed and locked.
  • Page 69 EAU86072 as well as to the exhaust system. Your Yamaha engine was designed to use unleaded gasoline with a research octane number of 95 or higher. If en- gine knocking or pinging occurs, use a gasoline of a different brand or higher ...

  • Page 70: Fuel Tank Overflow Hose

    Instrument and control functions EAU86160 EAU13435 Fuel tank overflow hose Catalytic converter See page 7-11 for canister information. The exhaust system contains catalytic converter(s) to reduce harmful exhaust emissions. EWA10863 WARNING The exhaust system is hot after op- eration. To prevent a fire hazard or burns: ...

  • Page 71: Seats

    Instrument and control functions To install the passenger seat EAU84580 Seats 1. Insert the projection on the front of the passenger seat into the seat Passenger seat holder as shown, and then push the rear of the seat down to lock it To remove the passenger seat in place.

  • Page 72: Storage Compartment

    Instrument and control functions  Do not exceed the maximum To install the rider seat EAU14465 Storage compartment 1. Insert the projection on the front of load of 191 kg (421 lb) for the ve- the rider seat into the seat holder hicle.

  • Page 73: Windscreen

    The rear view mirrors of this vehicle This vehicle is equipped with sidecase able windscreen. can be folded forward or backward for support holders. Consult your Yamaha parking in narrow spaces. Fold the mir- dealer before installing any sidecases. rors back to their original position be- fore riding.

  • Page 74: Adjusting The Front Fork

    Instrument and control functions tions, however such adjustments EAU84601 Adjusting the front fork are ineffective and may damage EWA10181 the suspension. WARNING Always adjust both fork legs equally, Compression damping force otherwise poor handling and loss of Turn the adjusting screw in direction (a) stability may result.

  • Page 75: Adjusting The Shock Absorber Assembly

    Instrument and control functions EAU84611 Compression damping setting: Adjusting the shock absorber Minimum (soft): assembly 13 click(s) in direction (b) This shock absorber assembly is Standard: 8 click(s) in direction (b) equipped with a spring preload adjust- Maximum (hard): ing knob and a rebound damping force 1 click(s) in direction (b) adjusting screw.
  • Page 76 Turn the adjusting screw in direction (a) 0 turn(s) in direction (b) sembly yourself. Take the shock to increase the rebound damping absorber assembly to a Yamaha force. dealer for any service. Turn the adjusting screw in direction (b) When turning the damping force ad-...

  • Page 77: Power Outlet

    Auxiliary DC connector power outlet. This vehicle is equipped with an auxil- 1 1 1 iary DC connector. Consult your Yamaha dealer before installing any accessories. 1. Power outlet cap 1. Power outlet A 12-V accessory connected to the 5. Turn the main switch on, and start power outlet can be used when the the engine.

  • Page 78: Usb Jack

    (or does not stay up), otherwise the sidestand could contact the ground and distract the operator, resulting in a possible loss of control. Yamaha’s ignition circuit cut-off system has been designed to assist the operator in fulfilling the respon- 1. USB jack sibility of raising the sidestand be- fore starting off.

  • Page 79: Ignition Circuit Cut-Off System

    Instrument and control functions this system regularly and have a EAU44905 Ignition circuit cut-off system Yamaha dealer repair it if it does not This system prevents in-gear engine function properly. starts unless the clutch lever is pulled and the sidestand is up. Also, it will...
  • Page 80 The neutral switch may not be working. 7. Move the sidestand up. The motorcycle should not be ridden until 8. Pull the clutch lever. checked by a Yamaha dealer. 9. Shift transmission into gear. 10. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 81: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 7-12 Coolant • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 7-19, 7-20 •...
  • Page 82 For your safety – pre-operation checks ITEM CHECKS PAGE • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. • Replace if necessary. 7-19, 7-20 Rear brake • Check fluid level in reservoir.
  • Page 83 For your safety – pre-operation checks ITEM CHECKS PAGE • Check operation. Instruments, lights, signals — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 4-48 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 84: Operation And Important Riding Points

    ECA10311 NOTICE there is a control or function you do not between 0 and 1600 km (1000 mi). For understand, ask your Yamaha dealer. this reason, you should read the fol-  Keep the engine speed out of EWA10272 lowing material carefully.

  • Page 85: Starting The Engine

    If a warning or indicator light does sidestand is up, and the clutch le- not work as described above, have a ver is pulled. Yamaha dealer check the vehicle. 1. 1/4 turn (20 degrees) To start the engine 3. Shift the transmission into the 1.

  • Page 86: Shifting

    Operation and important riding points EAU88781 EAU91543 ECA22523 Shifting NOTICE  When shifting, press the shift pedal firmly until you feel the This model is equipped with: gear shift is complete.  a lean angle sensor. This sensor  Even with the transmission in stops the engine in case of a vehi- the neutral position, do not cle turnover.

  • Page 87: Tips For Reducing Fuel Consumption

    Operation and important riding points 3. Open the throttle gradually, and at 4. Once motorcycle EAU16811 Tips for reducing fuel con- the same time, release the clutch stopped, the transmission can be sumption lever slowly. shifted into the neutral position. Fuel consumption depends largely on 4.

  • Page 88: Parking

    Operation and important riding points EAU17214 Parking When parking, stop the engine, and then remove the key from the main switch. EWA10312 WARNING  Since the engine and exhaust system can become very hot, park in a place where pedestri- ans or children are not likely to touch them and be burned.

  • Page 89: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 90: Tool Kit

    However, a torque wrench and other tools are necessary to perform certain maintenance work correctly. If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you.

  • Page 91: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts  Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills.  From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).
  • Page 92 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check control system for dam- Evaporative emis- √...

  • Page 93: General Maintenance And Lubrication Chart

    • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) • Check operation. √ √...
  • Page 94 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check bearing play and steering √ √...
  • Page 95 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation. √ √ √ √ √...
  • Page 96 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation. √ √ √ √ √...

  • Page 97: Removing And Installing The Panel

    Periodic maintenance and adjustment EAU18752 Removing and installing the panel The panel shown needs to be removed to perform some of the maintenance jobs described in this chapter. Refer to this section each time the panel needs to be removed and installed. 1.

  • Page 98: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 99: Canister

    Periodic maintenance and adjustment To check the engine oil level EAU36113 EAU99421 Canister Engine oil 1. On a level surface, place the mo- The engine oil level should be checked torcycle on the centerstand. regularly. In addition, the oil must be 2.

  • Page 100: Why Yamalube

    Thus, 1. Engine oil filler cap Yamalube mineral, semisynthetic and If genuine Yamaha coolant is not avail- 2. O-ring synthetic oils have their own distinct able, use an ethylene glycol antifreeze characters and value.
  • Page 101 The coolant must be changed at the in- tervals specified in the periodic main- tenance and lubrication chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is 1. Coolant reservoir cap hot.

  • Page 102: Air Filter Element

    Check the engine idling speed and, if maintenance and lubrication chart. changes with use, they must be necessary, have it corrected by a Have a Yamaha dealer replace the air checked and adjusted at the intervals Yamaha dealer. filter element.

  • Page 103: Tires

    Operation of this vehicle with im- wall is cracked, have a Yamaha dealer senger, cargo, and any accessories. proper tire pressure may cause se- replace the tire immediately.
  • Page 104 Tire information characteristics of the motorcy- EWA10472 WARNING cle may be different, which  Have a Yamaha dealer replace could lead to an accident.  Always make sure that the valve excessively worn tires. Besides being illegal, operating the vehi-...

  • Page 105: Cast Wheels

    If any damage is found, have high speeds. a Yamaha dealer replace the  Brand-new tires can have a rel- wheel. Do not attempt even the atively poor grip on certain road smallest repair to the wheel.

  • Page 106: Checking The Brake Lever Free Play

    Yamaha dealer check the internal clutch mechanism. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system.

  • Page 107: Brake Light Switches

    If a brake pad has worn to the point that a wear indicator almost 1. Brake pad wear indicator touches the brake disc, have a Yamaha dealer replace the brake pads as a set. 7-19...

  • Page 108: Checking The Brake Fluid Level

     Insufficient brake fluid may al- a Yamaha dealer replace the brake low air to enter the brake sys- pads as a set. tem,...

  • Page 109: Changing The Brake Fluid

    EAU22734 Changing the brake fluid id; otherwise, the rubber seals Yamaha dealer check the cause before Have a Yamaha dealer change the may deteriorate, causing leak- further riding. brake fluid every 2 years. In addition, age.

  • Page 110: Drive Chain Slack

    EAU92600 To adjust the drive chain slack each side of the swingarm in di- Consult a Yamaha dealer before ad- rection (a). To loosen the drive justing the drive chain slack. chain, turn the adjusting bolt on 1.

  • Page 111: Cleaning And Lubricating The Drive Chain

    Periodic maintenance and adjustment 7. Make sure that the drive chain EAU23027 Cleaning and lubricating the pullers are in the same position, drive chain the drive chain slack is correct, The drive chain must be cleaned and drive chain moves lubricated at the intervals specified in smoothly.

  • Page 112: Checking And Lubricating The Cables

    Yamaha dealer check or re- place it. WARNING! Damage to the outer housing of cables may result in internal rusting and cause inter- ference with cable movement.

  • Page 113: Checking And Lubricating The Brake And Shift Pedals

    Periodic maintenance and adjustment EAU44276 EAU23144 Recommended lubricant: Checking and lubricating the Checking and lubricating the Lithium-soap-based grease brake and shift pedals brake and clutch levers The operation of the brake and shift The operation of the brake and clutch pedals should be checked before each levers should be checked before each ride, and the pedal pivots should be lu-...

  • Page 114: Checking And Lubricating The Centerstand And Sidestand

    EWA10742 WARNING If the centerstand or sidestand does not move up and down smoothly, have a Yamaha dealer check or re- pair it. Otherwise, the centerstand or sidestand could contact the ground and distract the operator, resulting in a possible loss of control.

  • Page 115: Lubricating The Swingarm Pivots

    The swingarm pivots must be lubricat- face and hold it in an upright posi- fork does not operate smoothly, ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, have a Yamaha dealer check or re- specified in the periodic maintenance securely support the vehicle so pair it.

  • Page 116: Checking The Steering

    The front and rear wheel bearings must cause danger. Therefore, the operation be checked by a Yamaha dealer at the The steering bearings must be lubricat- of the steering must be checked by a intervals specified in the periodic main-...

  • Page 117: Battery

     Electrolyte is poisonous and 3. Fully charge the battery before in- stallation. NOTICE: When install- Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to ing the battery, be sure to turn furic acid, which causes severe have discharged.

  • Page 118: Replacing The Fuses

    Periodic maintenance and adjustment nect the positive lead before EAU84652 Replacing the fuses connecting the negative lead. The fuse boxes and individual fuses [ECA16842] are located under the rider seat (see 4. After installation, make sure that page 4-41) and behind panel A (see the battery leads are properly con- page 7-9).
  • Page 119 Periodic maintenance and adjustment rating than recommended to avoid causing extensive dam- age to the electrical system and possibly a fire. [EWA15132] 12 11 1. Fuse box 2 1. Spare fuse 2. Fuse box 3 2. Ignition fuse 2 3. Signaling system fuse 4.

  • Page 120: Vehicle Lights

    There are no user replaceable 1.0 A bulbs. Brake light fuse: 1.0 A If a light does not come on, check the ABS control unit fuse: fuses and then have a Yamaha dealer 5.0 A check the vehicle. Ignition fuse: 15.0 A ECA16581 NOTICE Ignition fuse 2: 7.5 A...

  • Page 121: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 122: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 123 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 124: Motorcycle Care And Storage

    Be performance and extend the useful life sure to wash the underside and sure to consult a Yamaha dealer for of many components. Washing, clean- chassis parts after riding in such ing, and polishing will also give you a advice on what products to use be- areas.
  • Page 125 Motorcycle care and storage detergent applications such as 4. Pre-soak stubborn stains like in- been exposed to salt. Warm wa- those available in coin-operated sects or bird droppings with a wet ter will increase salt’s corrosive car washers. towel for a few minutes. properties.
  • Page 126 Motorcycle care and storage  If necessary, clean the brake 3. Use a chrome polish to shine 8. When finished cleaning, start the chrome, aluminum, and stainless engine and let it idle for several discs and pads with brake steel parts. Often the thermally in- minutes to help dry any remaining cleaner or acetone.

  • Page 127: Storage

    Motorcycle care and storage 1. Make all necessary repairs and b. Pour a teaspoonful of engine EAU83472 Storage perform any outstanding mainte- oil into the spark plug bore. Always store the vehicle in a cool, dry nance. c. Install the spark plug cap onto place.
  • Page 128 Motorcycle care and storage wheels a little once a month in or- der to prevent the tires from be- coming degraded in one spot. 9. Cover the muffler outlet with a plastic bag to prevent moisture from entering it. 10. Remove the battery and fully charge it, or attach a maintenance charger to keep the battery opti- mally charged.

  • Page 129: Specifications

    Specifications Dimensions: Fuel injection: Starting system: Electric starter Overall length: Throttle body: Engine oil: 2150 mm (84.6 in) ID mark: Overall width: Recommended brand: BFD1 875 mm (34.4 in) Drivetrain: Overall height: Gear ratio: 1395/1430 mm (54.9/56.3 in) 1st: Seat height: 2.571 (36/14) 825 mm (32.5 in) 2nd:...
  • Page 130 Specifications Manufacturer/model: Front turn signal light: BRIDGESTONE/BATTLAX ADVENTURE A41R M Rear turn signal light: Loading: Auxiliary light: Maximum load: 191 kg (421 lb) License plate light: (Total weight of rider, passenger, cargo and accessories) Front brake: Type: Hydraulic disc brake Rear brake: Type: Hydraulic single disc brake...

  • Page 131: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number The vehicle identification number is The engine serial number is stamped stamped into the frame.

  • Page 132: Diagnostic Connector

    Yamaha dealer. cal analysis and development purpos- Although the sensors and recorded data will vary by model, the main data points are: ...
  • Page 133 Consumer information Yamaha will not disclose this data to a third party except in the following cas- es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data. Even in this case,...

  • Page 134: Index

    Index Diagnostic connector ......10-2 Dimmer/Pass switch ......4-3 ABS............4-36 Joystick and Home Button .....4-4 Display............ 4-9 ABS warning light ........4-7 Drive chain, cleaning and lubricating ... 7-23 Air filter element ........7-14 Main switch/steering lock .......4-2 Drive chain slack ........7-22 Auxiliary DC connector ......4-47 Maintenance and lubrication, periodic..7-5 Auxiliary system warning light ....4-9...
  • Page 135 Index Sidecase support holder ...... 4-43 Windscreen .......... 4-43 Sidestand ..........4-48 Smart features (communication Yamalube ..........7-12 control unit) .......... 3-1 YRC mode (drive mode)....... 4-32 Spark plugs, checking......7-10 YRC mode switch ........4-4 Specifications ......... 9-1 YRC settings ........4-27 Starting the engine .........
  • Page 138 Original instructions PRINTED IN JAPAN 2022.11-0.3×1 CR (E)

This manual is also suitable for:

Mxt890d

Table of Contents
