Crux DKGM-51 Quick Manual

Radio replacement with swc retention and dash kit for gm lan 11 bit vehicles 2006-2012

- Retains factory features in select GM LAN 11 Bit vehicles while functioning with an

aftermarket radio.

- Pre-programmed to retain factory Steering Wheel Controls.

- Supports Bose, non-Bose and Y-91 audio systems.

- Retains chime functions.

- Retains front and rear parking sensors.

- EIA color coded wiring for easy installation.

1. DOES NOT support ONSTAR.

Antenna

GM-51

GM-2A

GM-2B

SWC Cables

Dash Kit

Module

Harness

Adaptor

1 / 4

Rev.031120

Table of Contents

Need help?

Do you have a question about the DKGM-51 and is the answer not in the manual?

Page 1 - Retains factory features in select GM LAN 11 Bit vehicles while functioning with an aftermarket radio. - Pre-programmed to retain factory Steering Wheel Controls. - Supports Bose, non-Bose and Y-91 audio systems. - Retains chime functions. - Retains front and rear parking sensors. - EIA color coded wiring for easy installation.
Page 2 SETTING THE AFTERMARKET RADIO BRAND With the key in the off position, set the DIP switches to the corresponding radio listed below. 3.5MM SWC CABLE Use the proper 3.5 to 4 pin SWC cable for the aftermarket radio being used: OPTION A is used for ALPINE, CLARION, (JVC and KENWOOD units will use the Blue/Yellow wire).
Page 3 Adjustment A double DIN radio replacement dash kit is included in the kit to make the installation quick and easy. You have the option of installing a Double DIN or two Single DIN radios. The DKGM-51 kit includes: Before installation: 1.
Page 4 Diagram B Diagram A 16 and 14 PIN CONNECTORS 24 PIN CONNECTOR CHEVROLET CHEVROLET 2007-2010 Cobalt 2005-2006 Cobalt 2006-2011 2004-2007 Malibu 2008-2012 Malibu PONTIAC PONTIAC 2007-2010 2005-2009 2006-2010 Solstice SATURN 2007-2010 Aura 2007 2007-2009 4 / 4 Rev.031120...
