- Page 1 User Manual PCE-LCT 3 Clamp Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 6 April 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
Auto Power Off function ....................7 Measurement ..................7 Current measurement (current clamp) ................7 Voltage measurement ...................... 8 Resistance measurement, continuity and diode test ............8 Replacing the batteries ................ 8 Warranty ....................9 10 Disposal ....................9 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Lieferumfang
Lieferumfang 1 x clamp meter PCE-LCT 3 1 x transport bag 1 x K-type thermocouple 1 x pair of test leads 2 x 1.5 V AAA batteries 1 x user manual Specifications AC current measurement measuring range Resolution Accuracy Accuracy 4-mA 0.001mA... - Page 5 0.01 nF ± (3% + 8 digits) 400.0 nF 0.1 nF 4,000 μF 0.001 μF 40.00 μF 0.01 μF 400.0 μF 0.1 μF 0.001 μF 4,000mF 0.01 μF 40.00 mF Overvoltage protection: 600V AC / DC RMS © PCE Instruments...
- Page 6 (50°C / 122°F (current ambient temperature)) - (40°C 104°F (operating temperature)) = 10°C / 50°F When current ambient temperature is lower than the temperature of the operating conditions (0°C / 32°F (operating temperature)) - (-5°C / 23°F (current ambient temperature)) = 5°C / 41°F © PCE Instruments...
-
Page 7: Device Description
Device description Description Measuring aperture for indirect measurement Rotary switch Connection for direct measurement (+) Connection for direct measurement (-) Display Keypad Lever to open the clamp Clamp © PCE Instruments... -
Page 8: Keys And Connections
Hold reading To freeze the currently displayed reading, short-press the “LPF/HOLD“ key. The reading will be held. To resume the measurement, press the “LPF/HOLD“ key again. An “H“ will be displayed as soon as this function is active. © PCE Instruments... -
Page 9: Low Pass Filter 50 Hz / 60 Hz Current Selection
Note: Only one cable can be measured at a time. Measuring several cables would cause incorrect readings. To obtain the most accurate measurement result possible, the cable must be positioned as centrally as possible. Important: During the current measurement, the test leads must not be connected to the meter. © PCE Instruments... -
Page 10: Voltage Measurement
You can now open the battery compartment at the rear side of the meter to replace the batteries. Insert two new 1.5 V AAA batteries. Observe correct polarity. Close the battery compartment. The meter should now work fine again. © PCE Instruments... -
Page 11: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 12 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
