Contra Angle Handpiece Titanium Body
X35L,X35,
X70L,X70,X75L,X75
X55L,X55,X57L,X57
OM-C0404E 002

Advertisement

loading
Need help?

Need help?

Do you have a question about the TI-MAX X Series and is the answer not in the manual?

Questions and answers

Related Manuals for NSK TI-MAX X Series

Summary of Contents for NSK TI-MAX X Series

  • Page 1 Contra Angle Handpiece Titanium Body X35L,X35, X70L,X70,X75L,X75 X55L,X55,X57L,X57 OM-C0404E 002...
  • Page 2 CAUTION • When operating the handpiece always consider the safety of the patient. • The handpiece is designed only for dental clinical use by licensed person. • Do not attempt to disassemble the handpiece nor tamper with the mechanism. • Do not allow any impact on the shank. Do not drop the handpiece. •...
  • Page 3 • Always keep the file, reamer shank clean, Entry of debris into the chuck cause file or reamer run-out and the file or reamer could not be mounted inmost. • DO NOT exceed the maximum permissible rotation speed that manufactor recomend. •...
  • Page 4 1.Connecting / Disconnecting the motor and the handpiece To connect the motor and the handpiece, align the positioning marks of the motor and the handpiece, and insert straightly. This procedure will also align the light receptacle and allow you to use illumination if your handpiece and motor are equipped for illumination. (X35L,X70L,X75L,X55L,X57L) To disconnect, hold the front part of the motor and the back part of the handpiece, and pull out straightly.
  • Page 5 B) X70 Series or X75 Series Push the push-button to open the chuck. Insert the instrument shank into the chuck and lightly turn the file with light push. When the file engages with the latch mechanism, where the file sinks, and release the push-button. (2) Hand file (X35 Series) Push the push-button to open the chuck, and remove the Quick-fit Adapter.
  • Page 6 * Accepts handle diameters Ø3.8-4.1mm Typical applicable hand instruments: Union Broach, Zipperer, Mani, Meisinger, Komet, Kerr. Removing Push the push-button with a thumb, and the file is removed. CAUTION Make sure that the motion is completely stopped when to depress the push-button and disengage the latch mechanism. Avoid accidental depression of the push-button during rotation.
  • Page 7 3. Insertion and Removal of the Eva Tip or Profin Tip (X55L,X55) (1) Tip Insertion A) Eva Tip Insert an Eva Tip into the head. B) Profin Tip Insert a Profin Tip into the head. After adjusting the direction of the tip to the desired angle, push it firmly into the slit at the plunger of the head.

  • Page 8: Check Before Treatment

    5. Check before treatment Check that the Head Cap (or ring) is firmly tightened. Also check for handpiece vibration, noise and overheating. If any abnormalities are found do not use the handpiece and contact your Authorised NSK Dealer.
  • Page 9 6. Lubrication CAUTION Supply PANA SPRAY Plus or/and Care3 Plus after each use and/or before autoclaving. PANA SPRAY Plus E-Type Spray Nozzle Handpiece 1. Push E-type spray nozzle attachment over the PANA SPRAY Plus nozzle until it firmly seats. 2. Remove the file from handpiece. 3.
  • Page 10 • Supply lubricant until it comes out of the handpiece head (for approx. 2 seconds). • Keep the PANA SPRAY Plus can upright. Care3 Plus NSK Care3 Plus automatic handpiece cleaning and lubrication system After connecting the handpiece to the correct adaptor, activate the Care3 System per the Care3 System instructions. 7. Sterilization This product can be washed via Thermo·Disinfector.
  • Page 11 Autoclave Procedure: 1. Scrub dirt and debris from the handpiece, and wipe clean with alcohol-immersed cotton swab or cloth. Do not use a wire brush. 2. Lubricate with PANA SPRAY Plus. Refer to 5. Lubrication. 3. Insert into an autoclave pouch. Seal the pouch. 4.
  • Page 12 Do not use a pointed tool or sharp edges to clean the glass rod optic end. They may damage the mirror finish and reduce the light transmission efficiency. If the glass rod optic end has become damaged, send the handpiece to the NSK dealer for repair.
  • Page 13 9. Utrasonic cleaning (X57L,X57) Tighten To remove the paste that against into the Handpiece, perform ultrasonic cleaning day by day. Loosen 1) Loosen the ring and take off the ring and attaching screw.(Fig.10) Ring and Ring and Ring and 2) Perform the ultrasonic cleaning for 5 minutes ONLY for the attaching screw. attaching screw attaching screw attaching screw...

  • Page 14: Specification

    SPECIFICATION Model X35L X70L X75L Intended to use Endodontic Allowable Max. Speed 40,000min 40,000min 22,000min 22,000min 40,000min 40,000min Motor Micro Motor Micro Motor Air Motor Air Motor Micro Motor Micro Motor EngineFiles EngineFiles File ( Against titanium file ) ( Against titanium file ) EngineFiles EngineFiles EngineFiles...
  • Page 15 Model X55L Intended to use Interdentium polishing EVA/Profin Tip EVA/Profin Tip Vertical Reciprocating Vertical Reciprocating Motion (Stroke Length1.4 mm) (Stroke Length1.4 mm) Allowable Max. Speed 40,000min 40,000min Gear Ratio 4 : 1 Reduction 4 : 1 Reduction Spray Type Single Spray Single Spray Optics Glass Rod Optic...
  • Page 16 Model X57L Intended to use Tooth polishing Gear Ratio 16:1 Reduction 16:1 Reduction Rotation Speed 40,000min 40,000min Optics Glass Rod...
  • Page 17 The EU directive 93/42/EEC was applied in the design and production of this medical device. 2013.00.20 00...
