Preparing for Incubation
[ Egg tray assembling method ]
▶ Remove the cable ties fixed to both sides of the egg tray of each shelf(shown in figure ⓒ below).
▶ Before supplying power, make sure that the filler bar(shown in figure ④ below) located in the universal tray
slide plate is inserted in the middle of the carrier frame(shown in figure ③ below).
If cable ties are not removed, egg-rotation problems or malfunctions may occur.
▶ 2 frame fillers are installed on one carrier frame.
▶ The Carrier filler shown in figure below is factory assembled so no assembly is required.
Carrier Filler
Carrier Frame
If the door isn't completely closed, the temperature and humidity might not be controlled, so be careful.
If water is on the machines floor, it will not reach operating temperature.
(Do not place the humidifier water tank on top of the machine.)
More eggs could be inserted if sorted by similar
size.
The eggs intended for incubation must
be fertilized eggs.
▶ A slight gap (about 2mm) is required, between
egg and aluminum divider (as shown in the
figure), this allows smooth egg turning.
Please turn on the device and make
sure that all functions are properly
operating before putting in the eggs.
DIGITAL INCUBATOR
Egg Incubator Hatcher Maru Pro User Manual
2. Before use
3. 부화
① ②
▶
(2) How to install this Incubator /
[ Egg Rotating Device] ]
ⓐ : Carrier Frame ⓑ : Moving Screw
③
▶ ▶
about 2mm
Preparing for Incubation
④
Slide Plate
