2. INSTALLATION
Basic installation
Complete installation
7
6
4
5
4
4
2
1
1 - RPS control unit
2 - Tubular motor (240Vac)
3 - Hand transmitter
4 - Safety edge wireless transmitter
3
2
1
1 - RPS control unit
2 - Tubular motor (240Vac)
8
3 - Hand transmitter
4 - Safety edge wireless transmitter
5 - Alarm wireless sensor
6 - Wireless security keypad
7 - External courtesy light
8 - Alarm buzzer
3
