8. TECHNICAL SPECIFICATIONS
Power supply
Operating temperature range
IP rating
Motor characteristics:
Voltage
Maximum power
Maximum output power for flashing light
Reception frequency
Radio memory capatibility (transmitters)
Wireless safety system BST25
Functioning range
Answering time in manoeuvre
Carrier frequency
Power supply
Consumption when transmitting
The manufacturer, Teleco Automation s.r.l, declares that the type of radio equipment is compliant with
Directive 2014/53/EU. The full text of the EU compliance declaration is available at the following Internet
address: www.telecoautomation.com/ce.
8.1 WARNINGS
The above mentioned product must be installed only by qualified technical personnel in compliance with
the standards of automatic openings. All connections must be rated for a single-phase power supply of
240V. For the disconnection from the power line, use an all-pole switch with contact with an opening of
at least 3.5 mm. Only suitable materials for the connections must be used to guarantee insulation that
complies with current standards on the subject of electrical safety. All the necessary safety devices are to
be seen separately. Incorrect wiring will cause incorrect functioning impairing the safety purpose for which
the product has been designed so that people injuries could occur; failure to follow instructions can cause
personal injury and/or property damage. The correct functioning of the product must be checked once a
year. Keep the 240V wires separately from the low voltage safety wires. The earth-wires must be fixed with
an additional fastening on the terminals; this fastening has to be done by qualified technical personnel during
the installation phase. The appliance has been tested with a power supply wire type H05VV-F; the power
supply wires for outdoor use have not to be lighter than the ordinary wires type H05RN-F. The safety devices
have to be in conformity with EN12978. The installation of the control unit has to be done by fixing the box
vertically with the cable glands downwards. The product is in conformity with the RAEE and RoHS directive.
The earth wire must be longer than the other wires because it must be the last to break off if the cable clamps
are slack. Remember that there are specific standards that must be complied with both as regarding the
safety of the electrical systems and as regarding the remote control of tubular motors for roller blind.
In the view of a constant development of their products, the manufacturer reserves the right for changing
technical data and features without prior notice.
240V~ ÷ 50Hz
-20°C ÷ +50°C
IP20
240V~
700W
300W - resistive load (240V~)
868.3MHz
32
10m
< 100ms
2.4GHz
2 x 1.5V AA or 2 x 3.6V lithium batteries
13mA
18
