3.3 Exclusion of safety edge in the last 5 cm of the closure
In case of uneven floors, it could be necessary deactivating the safety edge in the last part of the closure (not
more than 5 cm to comply with the standards) in order to avoid any accidental activation of the safety edge.
This procedure must be performed by qualified installer only, who will take charge of its correct application.
WARNING: this procedure can be used only for doors which require more than 10 seconds each manoeuvre. The
exclusion of the safety edge is applied only if the closure starts from the upper limit switch and it is not stopped.
P1
hold-to-run
DEACTIVATION
P1
10x
X
11x
Press P1 button ten times and keep it
keep it
pressed
pressed for 5 seconds. The buzzer emits
(
5 s)
3 beeps.
Open the door completely by means of
a memorized transmitter. The buzzer emits
a long beep when the upper limit switch is
reached. Put on the floor, exactely under the
max. 5 cm
door, a sturdy object not more than 5 cm high.
Close the door (in hold-to-run mode), with
no interruption. The door will stop at the
obstacle and the control unit will make a
long beep. Open the door completely and
remove the object. Close the door to verify the
correct application of the procedure.
keep it
Press P1 button eleven times and keep it
pressed
pressed for 5 seconds. The buzzer emits 5
(
5 s)
beeps.
11
