Page 8: Introduction - Safety And Guidelines
Right hand and left hand are determined by facing the direction of forward travel respectively. HORSCH reserves the right to alter illustrations as well as technical data and weights contained in this manual at any time without notice. -
Page 9: Warranty Guidelines
Warranty Guidelines 1. The period of warranty for material defects relating to HORSCH products will be 12 months. In the case of written deviations from the statutory provisions, these agreements shall apply. They shall become effective upon delivery of the machine to the end customer, unless the unit is stored during seasonal months, whereas the machine is not utilized. - Page 10 10 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 11: Machine Registration Form: Customer's Copy
I hereby confirm receipt of the Owner’s Manual and Parts Catalog for the above mentioned machine. I have been instructed and informed by a HORSCH factory trained Service Technician / authorized Dealer representative in the operation and functions of the machine, as well as in the safety requirements. - Page 12 12 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 13: Machine Registration Form: Dealer's Copy
I hereby confirm receipt of the Owner’s Manual and Parts Catalog for the above mentioned machine. I have been instructed and informed by a HORSCH factory trained Service Technician / authorized Dealer representative in the operation and functions of the machine, as well as in the safety requirements. - Page 14 14 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 15: Machine Registration Form: Horsch's Copy
I hereby confirm receipt of the Owner’s Manual and Parts Catalog for the above mentioned machine. I have been instructed and informed by a HORSCH factory trained Service Technician / authorized Dealer representative in the operation and functions of the machine, as well as in the safety requirements. - Page 16 16 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 17: Delivery Form: Dealers's Copy
Delivery Form: DEALERS’s Copy Serial Number: …………………………………… At the time the machine is delivered, the following checklist is a reminder of information which should be conveyed directly to the customer. Check off each item as it is fully explained to customer. - Page 18 18 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 19: Product Specification
The Serial number, along with Model number of the machine, can be found on the Serial Number Tag. HORSCH, LLC has placed a Serial Number Tag (reference picture below) on the machine with the above mentioned information. It is located on the main frame cross member tube directly behind the front hitch, just off center towards the left hand side of each machine. -
Page 20: In These Operating Instructions
In These Operating Instructions The operating instructions distinguish between three different types of warning and safety instructions. The following graphic symbols are used: Important instructions! If there is a risk of injury! If there is a risk to life and limb! It is important that all the safety instructions contained in these operating instructions and all the warning signs on the machine are read thoroughly and understood prior to operation of the machine. -
Page 21: Information Regarding Safety
Information Regarding Safety The following warnings and safety instructions apply to all sections in these operating instructions. Safety Symbols on the Machine: Read and adhere to the operating instructions before starting up the machine! Stay clear of swinging area of retractable and extendible machine parts! Switch the engine off and pull out the key before starting maintenance and repair work! Never reach into areas where there is a risk of crushing, as long as parts... -
Page 22: Operational Safety
Operational Safety The machine must only be put into operation after receiving instructions by employees of the authorized dealer or a HORSCH employee. The machine registration form has to be completed and returned to HORSCH. Road Traffic Safety The valid road traffic regulations are to be observed when traveling on public roads, paths and areas. -
Page 23: Pressure Accumulator
Pressure Accumulator Depending on the equipment of the machine, the hydraulic system may have a pressure accumulator installed. Do not open or work (welding, drilling) on the pressure accumulator. Even after being emptied, the accumulator is still preloaded by gas pressure. Always depressurize the pressure accumulator before starting work on the hydraulic system. -
Page 24: Extracting Stuck Machine Safety & Guidelines
Extracting Stuck Machine Safety & Guidelines Follow proper hooking and towing recommendations below for extracting stuck machines. If damage is incurred to a machine during extraction due to improper procedure, any applicable warranties may be void! Avoid wet, water logged and muddy ground conditions so as not to get stuck. •... -
Page 25: Hydraulic Function Precautions
Hydraulic Function Precautions When handling the machine, ensure that no persons are in the danger zone. The hydraulic functions are controlled at tractor hydraulic controls from inside the cab. Safety Measures in Case of Injury from Oil Eyes: Should any oil be splashed into your eyes, rinse with water for 15 minutes. -
Page 26: Tire Information
Tire Information • Proper Tire inflation is important. Inflate tires to 30 psi. Verify tightness of all wheel lugs. Torque to 220 ft-lbs. • Tire Specifications Model Type Brand Series Ply Size Index Rating PT300/400 Transport Firestone All Traction 14.9-24 5080 Utility R-4 PT300/400... -
Page 27: Transport/Installation
Transport/Installation There is higher danger of accident during initial installation. Please pay attention to the notes in the corresponding chapters. Delivery The machine with implements is normally delivered completely assembled on a low loader. If parts or modules had to be disassembled for transportation purposes, these will be assembled by our distributor. -
Page 28: Transport
Transport Depending on country specific regulations and working width, the equipment can be transported on public roads, either attached to a tractor or on a trailer or low loader. • The permissible dimensions and weights for transport must be complied with. •... -
Page 29: Technical Data
Technical Data Joker PT-300 Working width: ......... 30’ Transport height: ........10’8” Transport width: ........19’5” Weight: ............13,800 lbs. Tires: …............14.9-24 Firestone All Traction R4 8-ply Load Index-D 5,080 lbs at 30 PSI Number of discs: …........68 Hydraulic control units: ...... -
Page 30: Setting/Operation
Setting/Operation Cultivation discs: The disc blades of the machine cut the harvest residues and the soil and mix the residues into the soil down to working depth. The Joker series high speed tillage machines are equipped with 20’’ disc blades. There are currently two (2) options available of disc blades to equip your machine to suite your needs: Smooth Disc Blade Notch Disc Blade... - Page 31 Notes on cleaning: The mechanical seals of the disc hubs are very sensitive. If water has entered them and the machine is then parked over a longer period of time, damage may occur. This can cause corrosion, and both mechanical seal rings may stick together. The mechanical seal rings will then rotate around the O-ring and damage it.
- Page 32 Assembly, Bearing Blade – 5-Hole 32 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
- Page 33 Assembly Sequence: Fill hub unit completely with grease. Tapered Roller Bearing should be packed with grease prior to installation! P T - S e r i e s J o k e r O w n e r ’ s M a n u a l 33 | P a g e...
-
Page 34: Road Lighting Equipment
Road Lighting Equipment Pin Description Ground Brake Left Turn Not Used* Right Turn Tail Lights 7. 12V +* * If you’re not getting Depth Control option to power “ON”, you may have to switch 12V+ to Pin 4. 7-Pin Connector Check the road lighting equipment at regular intervals to prevent any other road users from being endangered by negligence! 34 |... -
Page 35: Hitching/Unhitching The Machine
Hitching/Unhitching the Machine Nobody is to remain between the tractor and the machine when hitching up and unhitching. Hitching-up: • Hitch up the machine to the trailer coupling ring on the tractor. • Connect hydraulic lines. • Connect the road lighting equipment plug and check the function. •... -
Page 36: Folding/Unfolding
The folding process should only be performed in the field, because the coulter discs could get caught in the ground. On the road, discs and road surface layer could get damaged. Joker PT-Series Folding: • Raise machine completely • Raise finishing system completely •... -
Page 37: Leveling Implement
Leveling Implement Implement is leveled at factory, but some adjustment may be needed. To Level Machine: 1. Park machine on level ground unfolded. 2. Lower machine to ground and put all hydraulics in float. 3. Loosen adjusting rods on front of machine. 4. -
Page 38: Field Operating Instructions
Field Operating Instructions Entering Field: 1. Remove yellow safety stops. 2. Unfold wings and place SCV in float once both wings are on ground. Return SCV to neutral once wing pressure gage reads 0 psi. Turn SCV to 40% flow. 3. -
Page 39: To Set Rolling Basket Position
To Set Rolling Basket position: 1. It is best recommended to operate the rolling basket packer system in a Float position at all times, rather than continuous pressure. Continuous hydraulic down pressure may cause the rolling baskets to raise the rear gang of discs on the machine out of the ground during operation, hindering performance and field finish. -
Page 40: Maintenance
Maintenance: There is little maintenance required to the rolling baskets. The bearings must be installed correctly to the baskets and frame to minimize side load and premature bearing failure. The bearings and the stub shaft may be shimmed accordingly to minimize the side load. Illustrations below indicate proper shimming technique. - Page 41 For further part illustrations and identification see model year specific parts catalog. For further part information and availability see your nearest authorized HORSCH dealer. P T - S e r i e s J o k e r O w n e r ’ s M a n u a l...
-
Page 42: Parking The Machine
Parking the Machine: Only park the machine on a firm and level surface. The Joker may be parked folded in transport position provided extra precaution is taken but is not recommended. Lift the machine to its highest position. • Insert the provided yellow safety stops to the rear lift (x2) and the front hitch cylinder. DO NOT •... -
Page 43: Maintenance And Servicing
Maintenance and Servicing Observe the safety instructions for maintenance and servicing. Your machine has been designed and constructed for maximum power, efficiency and user- friendliness according to a multitude of operating conditions. Your machine has been checked at the factory and by your appointed authorized dealer prior to delivery in order to determine that the machine is in perfect condition. -
Page 44: Lubricating Machine
• Oily waste and waste oil have to be disposed of according to the legal regulations. Check with your local Hazardous Waste Material Management facility. Service HORSCH hopes you are completely satisfied with your machine and the HORSCH company itself. Please contact your distribution partner or authorized dealer in the event of a problem. -
Page 45: Maintenance Schedule
Maintenance Schedule Maintenance Schedule After the first few operating hours: Work instructions: Interval: All screwed and plug-in Check for tightness and tighten screw connections connections In operation Lubricate Lubricate the safety pins 40 hours Lubricate the wing cylinder bolts 40 hours Lubricate the bolt on drawbar Daily Lubricate the packer shaft... -
Page 46: Lubrication Points
Lubrication Points 46 | P a g e P T - S e r i e s J o k e r O w n e r ’ s M a n u a l... -
Page 47: Troubleshooting
Troubleshooting Problem Cause Solution Machine does not track Machine is not level front Adjust hitch tilt cylinder. straight. to back. Machine does not stop at Cylinders not reaching set Adjust SCV timer setting desired depth. points before hydraulic so valve returns to neutral flow stops. -
Page 48: Bolt Tightening Torques - Metric Bolts
Bolt Tightening Torques - Metric Bolts Bolt tightening Torques - Metric bolts (Ft. Lbs) Bolt Diameter Grade 4.8 Grade 5.8 Grade 8.8 Grade 10.9 Grade 12.9 Wheel Nuts/ Bolts Size Pitch Dry Lubed Dry Lubed Dry Lubed Dry Lubed Dry Lubed 0.50 0.70 0.80... -
Page 49: Bolt Tightening Torques - Imperial Bolts
Bolt Tightening Torques - Imperial Bolts Bolt tightening Torques - Imperial bolts (Ft. Lbs) Bolt Diameter SAE Grade 2 SAE Grade 5 SAE Grade 8 Size Thread Lubed Lubed Lubed Lubed 5/16 5/16 7/16 7/16 9/16 9/16 1000 1 1/8 1280 1150 1 1/8... -
Page 50: Hardware Tightening Information
Hardware Tightening Information Do NOT use these values if a different torque specification or value or tightening procedure is given for a specific application. Torque values listed are for general use only. Use the above chart as a reference. Check tightness of fasteners periodically. Shear bolts are designed to fail under predetermined loads. -
Page 51: Notes
Notes: Go to Top P T - S e r i e s J o k e r O w n e r ’ s M a n u a l 51 | P a g e... - Page 52 HORSCH, LLC 200 Knutson St. Mapleton, ND 58059 USA Telephone: (701) 532-1000 Fax: (701) 532-1101 Email: info.us@horsch.com Web: www.horsch.com PN 04519211...
