Name
H3C X130
10G SFP+
LC LRM
Transceiver
H3C X130
10G SFP+
LC LR
Transceiver
H3C X130
10G SFP+
LC ER
40km
Transceiver
Connection procedure
WARNING!
Do not stare into any open apertures of operating transceiver modules or optical fiber connectors.
The laser light emitted from these apertures might hurt your eyes.
CAUTION:
Insert a dust cap into any open optical fiber connector and a dust plug into any open fiber port or
transceiver module port to protect them from contamination and ESD damage.
To connect an optical fiber:
Insert an SFP/SFP+ transceiver module into an SFP/SFP+ port on the interface module.
1.
Identify the Rx and Tx ports on the SFP transceiver module. Use the optical fiber to connect the
2.
Rx port and Tx port on the transceiver module to the Tx port and Rx port on the peer end,
respectively.
Verify the LINK LED.
3.
If the LED is on, a fiber link has been set up.
If the LED is off, no link is present. The reason might be wrong connection of the Tx and Rx
ends. Swap the fiber connectors in the Tx and Rx ports at one end of the fiber.
Center
Fiber
Fiber
wavelen diameter
mode
gth (nm) (µm)
1310 MMF 50/125
1310 MMF 50/125
1310 MMF 50/125
1310 MMF 62.5/125
1310 MMF 62.5/125
1310 SMF 9/125
1550 SMF 9/125
Model
band Transmi
width ssion
(MHz* distance
km)
220 m
1500
(721.78 ft)
220 m
500
(721.78 ft)
100 m
400
(328.08 ft)
220 m
200
(721.78 ft)
220 m
160
(721.78 ft)
10 km
N/A (6.21
miles)
40 km
N/A (24.85
miles)
8
Interface index (dBm)
Output Receive Optical
optical sensitiv saturat
power ity ion
–6.5 to
≤ –6.5 ≤ +1.5
+0.5
–6.5 to
≤ –6.5 ≤ +1.5
+0.5
–6.5 to
≤ –6.5 ≤ +1.5
+0.5
–6.5 to
≤ –6.5 ≤ +1.5
+0.5
–6.5 to
≤–6.5 ≤ +1.5
+0.5
–8.2 to
≤ –14.4 ≤ +0.5
+0.5
–4.7 to
≤ –15.8 ≤ –1
+4
