- Page 2 ORWARD Thank you for your purchase of a NAUTICAM housing. At NAUTICAM, we pride ourselves in the ability to recognize the requirements of professional as well as amateur underwater photographers and fulfill them through the innovative designs of our products. We strive to achieve a high level of user-friendliness by allowing stress-free installation and easy operation of all important functions of the camera.
-
Page 3: Table Of Contents
ABLE OF ONTENTS Warranty ……………………………………………………………………………………………………………. Precautions ………………………………………………………………………………………………………… Package Contents ………………………………………………………………………………………………. Specifications …………………………………………………………………………………………………….. Identification of Parts ………………………………………………………………………………………… Opening and Locking the Housing ……………………………………………………………………… Preparation of the Housing and Installing the Camera………………………………………… Mounting Wet Lenses ………………………………………………………………………………………… Care and Maintenance ………………………………………………………………………………………. Optional Accessories ………………………………………………………………………………………….. -
Page 4: Warranty
NAUTICAM does not hold responsibility for damage, of any nature, to any equipment used with and/or placed within our products. NAUTICAM accepts no liability for any loss of captured images or the inability to capture images even if it is due to the malfunctioning of our products. -
Page 5: Precautions
O-ring(s). • Do not use lubricants from other brands with the silicone rubber O-ring on this housing, only use the lubricant provided by NAUTICAM. • Discontinue use immediately should you notice any leakage. - Page 6 • Do not open the product in a wet or sandy environment. Protect the interior from moisture and debris in order to prevent malfunction or leakage. • Do not store the product in an environment of high humidity. • Do not leave the housing and the monitor in direct sunlight for prolonged periods. •...
-
Page 7: Package Contents
ACKAGE ONTENTS • NA-TG6 Housing • Bayonet Mount Converter (Pre-Installed) • A Pair of Handle Brackets with Screws • Shutter Release Extension • 90126 Spare Silicone Rubber O-ring for Housing • Diffuser • O-ring Remover • Lubricant • Set of Allen Keys •... -
Page 8: Specifications
PECIFICATIONS Housing Body: Aluminum Alloy Construction Surface Treatment: Hard Anodized Display Window: Abrasion Resistant Polycarbonate Width: 162mm Height: 103mm Dimensions Depth: 93mm Weight in Air Approx. 0.67kg Weight in Water Slightly negative Depth Rating 100 meters Mount System Pre-Installed Bayonet Mount Compatible Olympus Tough TG-6 Cameras... -
Page 9: Identification Of Parts
DENTIFICATION OF ARTS On/Off Lever Rear Dial M10 Strobe Mounting Hole Zoom Lever Accessory Coldshoe Optical Fibre Mount Shutter Release Lever Lens Release Button Bayonet Mount *Handle brackets and Shutter release extension are not displayed. - Page 10 Threaded Holes for Handle Brackets (Right) / Hand Strap Threaded Holes for Lens Alignment ‘I’ Mark Handle Brackets (Left) Housing Lock Safety Button Housing Lock Attachment Point for Hand Strap *Handle brackets and Shutter release extension are not displayed.
- Page 11 Mounting Holes for LCD Movie Button Magnifier Attachment Rail Info Button Playback Button Mode Dial Up/Exposure Compensation Button Left/Mode Function Button OK Button Right/Flash Button Down/Sequential Shooting/Self-Timer /Erase Button Menu Button *Handle brackets and Shutter release extension are not displayed.
- Page 12 Sacrificial Zinc Anode 1/4” – 20UNC Tripod Socket* *The maximum length of screws that can be used with the tripod sockets is 4mm.
-
Page 13: Opening And Locking The Housing
PENING AND OCKING THE OUSING To open the housing: 1. Press the housing lock safety button. 2. Turn the housing lock anti-clockwise for 270°, until the lock reaches the “Open” position as shown. - Page 14 Prepar To lock the housing: 1. Close the housing while the housing 2. Turn the housing lock clockwise for is in the “Open” position. 270°, until the lock reaches the “lock” position as shown. Confirm that the white indicator line on the safety button is visible.
-
Page 15: Preparation Of The Housing And Installing The Camera
Prepar REPARATION OF THE OUSING AND NSTALLING THE AMERA To install the camera into the housing 1. After verifying that the main O-ring is in good condition, lightly coat it with the lubricant provided. 2. Make sure the O-ring groove located in the front part of the housing is free from any foreign material;... -
Page 16: Mounting Wet Lenses
OUNTING ENSES Compatible Wet Lenses with NA-TG6 housing: Macro : SMC-1, SMC-2, CMC-1, CMC-2 It requires to use #83214 Bayonet Mount Adaptor for SMC/CMC to mount wet macro lenses to the housing. Wide-angle: WWL-C : It can directly mount on the housing. (Full zoom range) - Page 17 To mount Wet Lens Align the ‘I’ mark on wet lens (or bayonet Turn the wet lens (or bayonet mount adaptor) clockwise until ‘I’ mount adaptor) with the ‘I’ mark on the mark on wet lens (or bayonet bayonet mount of the housing. mount adaptor) aligns with the ‘O’...
- Page 18 To unmount Wet Lens Press and hold the BLUE lens release Remove the wet lens (or bayonet mount button and then turn the wet lens (or adaptor) when ‘I’ mark on the wet lens (or bayonet mount adaptor) count bayonet mount adaptor) aligns with ‘I’ mark on the bayonet mount of the clockwise housing.
- Page 19 To avoid an interference between #71207 Flexitray II with left handle and bayonet mount of the housing, install the base plate of Flexitray II by rotating 180° as shown above and adjust the handle location accordingly. #71206 Easitray II with left handle is incompatible with NA-TG6 or NA-TG5 with #83255 Bayonet Converter.
-
Page 20: Care And Maintenance
O-ring with the provided lubricant before reinstalling it in the groove. A damaged O-ring should be discarded immediately and replaced only with one that is provided by NAUTICAM. • Replace the main O-ring annually. It is recommended that you ship the housing to our distributor for... -
Page 21: Optional Accessories
PTIONAL CCESSORIES P.N. 25123 P.N. 25221 P.N. 25106 P.N. 36316 LCD Magnifier attachment rails M10 strobe mounting LCD Magnifier with Dioptric Hand strap for Mirrorless IL NA-S110/S120/TG3/G7X/G7XII/TG5/TG6 ball for housing Adjustment camera & compact camera housing (Standard) P.N. 71208 P.N. 71207 Adjustable right handle II Flexitray II with left handle (for Easitray II &... - Page 22 P.N. 83203 P.N. 81301 P.N. 81302 Wet Wide Lens Compact (WWL-C) Compact Macro Convertor 1 Compact Macro Convertor 2 130 Deg. FOV with Compatible 24mm (CMC-1, 4.5X Magnification) (CMC-2, 2.8X Magnification) Lenses (incl. float collar) P.N. 83214 P.N. 72233/72234 P.N. 83252/83253 P.N.
