Summary of Contents for Nauticam NA - D780
-
Page 1: Table Of Contents
NA - D780 For Nikon D780 DSLR Camera PN 17226 User Manual Housing DSLR Introduction Package Contents Important Instructions Part Names and Functions Housing Mount Opening the housing Closing the housing Preparation for Use Optional Accessories Care/Storage Warranty Specifi cations... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-D780 Padded Travel Case... -
Page 3: Important Instructions
O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specifi ed by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product. -
Page 4: Part Names And Functions
PART NAMES AND FUNCTIONS Rear View Delete button Menu button WB button QUAL button Metering button Live view selector Fn 3 button Multi selector i button Moisture alarm window Multi selector - center... - Page 5 PART NAMES AND FUNCTIONS Top + Front Views Flash compensation button M16 Accessory port Optical fi ber cable connection Mode dial lock release button Release mode dial Main switch M10 Accessory port M14 Accessory port Exposure compensation button M16 Accessory port Main command dial Accessory mounting ball Port lock safety button...
- Page 6 PART NAMES AND FUNCTIONS Back + Side Views 1/4” Threaded tripod holes Zinc Anodes Zoom/Focus knob release Zoom/Focus knob AF-mode lever Fn 1 lever Info lever Playback lever AF-ON lever Movie record lever LV lever Shutter release lever ISO lever Sub-command dial PV lever Fn 2 lever...
-
Page 7: Housing Mount
HOUSING MOUNT Housing mount Compatible accessories M16 Accessory port 25625 M16 Vacuum valve II (pushbutton release) M14 Accessory port 26074 M14 Nikonos 5-pin bulkhead 26075 M14 Ikelite style bulkhead M10 Accessory port 25221 M10 Strobe mounting ball 25224 M10 Strobe mounting ball with hole M5 Accessory ports 25228 M5 Strobe mounting ball... -
Page 8: Opening The Housing
OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock outward lift up the back housing... -
Page 9: Closing The Housing
CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking turn housing lock inward until you hear and feel it click into place housing locked in place securely... -
Page 10: Preparation For Use
PREPARATION FOR USE * drawings as illustrations only Installing the Camera - housing tray attachment unlock camera tray lever and remove the tray from the housing attach the camera tray by tightening the tray screw into the tripod socket of the camera make sure the camera buttons are engaged with the camera tray * pull out the zoom/focus knob if... - Page 11 PREPARATION FOR USE * drawings as illustrations only Port Mounting depress safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in rotate locking lever clockwise to lock...
- Page 12 PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
- Page 13 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm CR2032 Battery Alarm ON/OFF remove battery press the battery down until it insulation fi lm click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will fl...
- Page 14 PREPARATION FOR USE * drawings as illustrations only Setting up integrated LED fl ash trigger small LED This housing uses an integrated LED fl ash triggering system. This optical fl ash trigger can fi re at the full fps of the camera, making it the ideal solution for the rapid fi...
- Page 15 PREPARATION FOR USE * drawings as illustrations only Changing lens/port without opening the housing If using with vacuum valve : remove the cap from the vacuum valve and press the red button to release pressure before unlocking port lock If using without vacuum valve, please follow from step 2 unlock port lock and remove port assembly...
-
Page 16: Optional Accessories
OPTIONAL ACCESSORIES * drawings as illustrations only Vacuum valve system remove the plug of M16 accessory port from the housing remove the cap from the vacuum valve hand pump slightly lubricate the o-ring and make sure the o-ring is in place vacuum valve accesory port on housing... - Page 17 OPTIONAL ACCESSORIES * drawings as illustrations only Strobe Mounting Ball Installing M5 Strobe Mounting Ball - RECOMMENDED M5 screw remove M5 screw with the allen key provided in the screw #25228 M5 Strobe mounting ball directing onto housing package the M5 thread * the anti-corrosion screw may also be Anti-corrosion unscrewed while removing M5 screw, if this...
-
Page 18: Care/Storage
CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation. -
Page 19: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals. -
Page 20: Specifications
Hard Anodized Aluminium Alloy Display window Abrasion Resistant Polycarbonate 28130 Hand Strap for Handle Size S 25625 M16 Vacuum Valve II (Pushbutton Release) Dimensions 32201 Nauticam 180˚ straight viewfi nder Width 351 mm 32203 Nauticam 45˚ viewfi nder Height 187 mm... - Page 21 87517 EMWL Bayonet Holder for Ø90 Float Arm with Aluminium Float Collar (incl. N120 to N100 port adaptor) 85204 0.57x Wide Angle Conversion Port 2 *please refer to Nauticam port charts for more setup information. with Aluminium Float Collar (compatible with 14mm lenses) FLASH TRIGGERING Optical TTL...
- Page 22 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
