4.
Replace lock bar holder only where
drawers will be located and do not add a
holder behind a door.
CAUTION: Drawers must be adjacent in a
case. There cannot be a door or open
case between drawers.
5.
If unit is stacking, connect lock bars
using lock connector.
6.
Add cup washer to top most unit in
case.
7.
Replace lock tabs.
4
LOCK BAR
HOLDER
6
LOCK BAR
CONNECTOR
7
LOCK TAB
CUP WASHER
5
Page 10 of 12
939501628 Rev E
