Eaton
Power Xpert
9395P High Performance (9395P-900) UPS
900 kW, 900 kVA
Installation and Operation Manual
For use with Two UPM (450–600 kVA),Three UPM (675–900 kVA), and
Plus 1 (675–900 kVA) UPS Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power Xpert 9395P-900 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton Power Xpert 9395P-900 Series

  • Page 1 ® ® Eaton Power Xpert 9395P High Performance (9395P-900) UPS 900 kW, 900 kVA Installation and Operation Manual For use with Two UPM (450–600 kVA),Three UPM (675–900 kVA), and Plus 1 (675–900 kVA) UPS Models...
  • Page 3 ® ® Eaton Power Xpert 9395P High Performance (9395P-900) UPS 900 kW, 900 kVA Installation and Operation Manual For use with Two UPM (450–600 kVA),Three UPM (675–900 kVA), and Plus 1 (675–900 kVA) UPS Models...
  • Page 4 National Electrical Code and NEC are registered trademarks of National Fire Protection Association, Inc. All other trademarks are property of their respective companies. © Copyright 2020 Eaton, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton.
  • Page 5: Eaton End-User License Agreement

    2.0 FIRMWARE LICENSE 2.1 Ownership. Eaton or its third party licensors retains all title, copyright and other proprietary rights in, and ownership of the Firmware regardless of the media upon which the original or any copy may be recorded or fixed.
  • Page 6 PRODUCT IS AT LICENSEE’S SOLE RISK. 5.0 GENERAL PROVISIONS 5.1 Update Policy. Eaton may from time to time, but has no obligation to, create Updates of the Firmware or components thereof. 5.2 Limitation on Liability. NOTWITHSTANDING ANY PROVISION OF THIS AGREEMENT TO THE CONTRARY, LICENSEE...
  • Page 7 5.13 Confidentiality. Licensee acknowledges that confidential aspects of the Firmware (including any proprietary source code) are a trade secret of Eaton, the disclosure of which would cause substantial harm to Eaton that could not be remedied by the payment of damages alone and such confidential aspects of the Firmware shall not be disclosed to third parties without the prior written consent of Eaton.
  • Page 8 This page intentionally left blank.
  • Page 9: Table Of Contents

    Eaton End-User License Agreement........
  • Page 10 Using the Color Touchscreen Control Panel ..........® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09...
  • Page 11 Relay Interface Module II ............. . . ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09...
  • Page 12 10.2.3 UPS Environmental ............. . . 10-2 ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 13 Eaton Xpert 9395P-900 Three UPM Plus 1 FI-UPM ....... . .
  • Page 14 UPS Color Touchscreen Control Panel (Typical) ..........® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09...
  • Page 15 FI-UPM Air Filter Location ............. . . ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09...
  • Page 16 LIST OF FIGURES This page intentionally left blank. ® ® viii Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 17: Introduction

    Chapter 1 Introduction ® ® The Eaton Power Xpert 9395P-900 uninterruptible power supply (UPS) is a true online, continuous-duty, transformerless, double-conversion, solid-state, three-phase system, providing conditioned and uninterruptible AC power to protect the customer's load from power failures. The Power Xpert 9395P-900 UPS online power protection system is used to prevent loss of valuable electronic information, minimize equipment downtime, and minimize the adverse effect on production equipment due to unexpected power problems.
  • Page 18: Configurations

    UPM section containing two UPMs each UPM rated for a maximum of 300 kVA for a total maximum of 600 kVA. ISBM or IOM SECTION UPM SECTION Figure 1-1. Power Xpert 9395P-900 Two UPM UPS ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 19: Two Upm Ups With An Fi-Upm

    480V models and 825 kVA for 415V/400V/380V models. FI-UPM UPM SECTION ISBM or IOM SECTION Figure 1-2. Power Xpert 9395P-900 Two UPM UPS with 1 FI-UPM ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 20: Three Upm Ups

    UPM section containing three UPMs. Each UPM is rated for a maximum of 300 kVA for a total maximum of 900 kVA. ISBM SECTION UPM SECTION Figure 1-3. Power Xpert 9395P-900 Three UPM UPS ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 21: Three Upm Plus 1 Ups

    Customer Service Engineer, or the warranty terms become void (see Section 1.10). This service is offered as part of the sales contract for the UPS system. Contact an Eaton service representative in advance (usually a two-week notice is required) to reserve a preferred startup date.
  • Page 22: Ups Standard Features

    Charging at high currents can overheat and damage batteries. 1.2.5 Power Management Software ® Eaton’s Intelligent Power Software solution, based on Web2.0 technology, includes two applications: ® ® Intelligent Power Manager™...
  • Page 23: Options And Accessories

    Introduction Options and Accessories Contact an Eaton sales representative for information about the following options. 1.3.1 Integrated Battery Cabinets Battery backup protection can be provided by equipping the UPS system with Power Xpert 9395P-900 battery cabinets containing sealed lead-acid, maintenance-free batteries. The cabinets are designed for standalone installation and may be installed adjacent to the UPS or in a separate location.
  • Page 24: Input Output Module Configuration

    1.3.8 Inherent Redundancy To deliver greater reliability, the Power Xpert 9395P-900 UPS can be configured by an authorized Eaton Customer Service Engineer for inherent redundancy. When configured, the UPS automatically becomes redundant if the load is at or below the capacity of the UPMs minus the capacity of one UPM. Under normal conditions the UPMs in the UPS share the load equally.
  • Page 25: 1.3.11 Monitoring And Communication

    – PredictPulse is a subscription monitoring and ™ management service from Eaton that collects and analyzes data from connected power infrastructure devices, providing us with the insight needed to make recommendations and take action on your behalf. It’s also powered by CA Technologies, bringing together the best in hardware and software. Like a second set of...
  • Page 26: Using This Manual

    In this manual, the term UPS refers only to the UPS cabinet and its internal elements. The term UPS system refers to the entire power protection system – the UPS cabinet, the battery system, and options or accessories installed. ® ® 1-10 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 27: Symbols, Controls, And Indicators

    Mechanical installation instructions, including site preparation, planning for mechanical installation, and safety information. Detailed illustrations of the cabinet, including dimension and pallet removal drawings. Visit www.eaton.com/powerquality or contact an Eaton service representative for information on how to obtain copies of these manuals. ®...
  • Page 28: Getting Help

    Please use the following e-mail address for manual comments, suggestions, or to report an error in this manual: E-ESSDocumentation@eaton.com 1.10 Warranty To view the UPS warranty please click on the link or copy the address to download from the Eaton website: UPS Product Warranty https://www.eaton.com/content/dam/eaton/products/backup-power-ups-surge-it-power-distribution/ backup-power-ups/portfolio/eaton-three-phase-ups-warranty.pdf ®...
  • Page 29: Safety Warnings

    (ground) connection with loads attached. Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 30 The operating environment should be maintained within the parameters stated in this manual. Keep surroundings uncluttered, clean, and free from excess moisture. Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and outside of the equipment. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 31 End forklift slots may be used for minor positioning if the forks are kept in a horizontal position with no upward angling. If these instructions are not followed, damage to the wiring channel and wiring will occur. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 32 Si ces instructions ne sont pas suivies, des dommages au câblage et à son canal surviendront. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 33 Section I Installation...
  • Page 35: Ups Installation Plan And Unpacking

    If the UPS is to be operated at an altitude higher than 1000m (3300 ft), contact an Eaton service representative for important information about high altitude operation. The operating environment must meet the weight, clearance, and environmental requirements specified.
  • Page 36: Installation Considerations

    When ignored, either one of these aspects can create an undesirable microclimate at the UPS location. If the environment created by this microclimate exceeds the Eaton 9395P UPS operating specification, the UPS reliability, over time, will be reduced. These same environmental extremes will also create reliability concerns for any servers that are exposed to them.
  • Page 37 Maximum Relative Humidity: 95%, non-condensing (see section 3.2.1) NOTE Eaton battery cabinets are located in the same room as the UPS, the battery cabinet environmental requirements supersede the UPS requirements. Operating temperatures above the recommended range will result in decreased battery life and performance, and will reduce or void the battery warranty.
  • Page 38 Table 3-3. 480V Air Conditioning and Ventilation Requirements During Full Load Operation Input/Output Heat Rejection Model Rating Ventilation Required for Cooling Air Exhaust Voltage kW (1000 BTU/hr) Eaton 9395P-900/900* 900 kVA 480/480 34.6 (118) (CSS) 900 kVA Eaton 9395P-900/900 900 kVA 480/480 31.7 (108.3)
  • Page 39 Table 3-5. 400V Air Conditioning or Ventilation Requirements During Full Load Operation Input/Output Heat Rejection Model Rating Ventilation Required for Cooling Air Exhaust Voltage kW (1000 BTU/hr) Eaton 9395P-900/825 825kVA 400/400 34.0 (116.1) (CSS) 825 kW Approximately 3300 liter/sec (7000 CFM) Eaton 9395P-900/750...
  • Page 40: Figure 3-1. Ups Cabinet Dimensions - Three Upm (Front View)

    Figure 3-1. UPS Cabinet Dimensions – Three UPM (Front View) 1880 [74.0] 3036.9 [119.5] Dimensions are in millimeters [inches]. Figure 3-2. UPS Cabinet Dimensions – Two UPM (Front View) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 41: Figure 3-3. Ups Cabinet Dimensions (Right Side View)

    Figure 3-3. UPS Cabinet Dimensions (Right Side View) 1880 [74.0] For 4-wire systems only 1705 [67.1] Dimensions are in millimeters [inches]. Figure 3-4. ISBM Section Dimensions (Front View) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 42: Figure 3-5. Isbm Section Dimensions (Top View)

    Dimensions are in millimeters [inches]. Figure 3-5. ISBM Section Dimensions (Top View) Front [22.0] 111.5 [4.4] [31.9] [2.8] Dimensions are in millimeters [inches]. Figure 3-6. ISBM Section Dimensions (Bottom View) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 43: Figure 3-7. Upm Section Dimensions - Three Upm (Front View)

    Figure 3-7. UPM Section Dimensions – Three UPM (Front View) 1114.4 [44] 475.4 574.4 [18.7] [23] 758.8 [29.9] Front Dimensions are in millimeters [inches]. Figure 3-8. UPM Section Dimensions – Three UPM (Top View) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 44: Figure 3-9. Upm Section Dimensions - Two Upm (Front View)

    Figure 3-9. UPM Section Dimensions – Two UPM (Front View) 34.44 1015.43 37.14 [1.4] [40.0] [1.5] 758.83 [29.9] Front Dimensions are in millimeters [inches]. Figure 3-10. UPM Section Dimensions – Two UPM (Top View) ® ® 3-10 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 45: Figure 3-11. Upm Section Dimensions - Fi-Upm (Front View)

    Figure 3-11. UPM Section Dimensions – FI-UPM (Front View) 510.1 [20.1] 758.83 [29.9] Front Dimensions are in millimeters [inches]. Figure 3-12. UPM Section Dimensions – FI-UPM (Top View) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 3-11...
  • Page 46: Figure 3-13. Ups Center Of Gravity- Fi-Upm And 3X Upms

    918 [36.1] FI-UPM 850 [33.5] 357 [14.1] ISBM/IOM 362 [14.3] 918 [36.1] 3XUPM Side View Figure 3-13. UPS Center of Gravity- FI-UPM and 3X UPMs ® ® 3-12 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 47: Figure 3-14. Ups Center Of Gravity - Fi-Upm And 2X Upms

    918 [36.1] 850 [33.5] ISBM/IOM 357 [14.1] 362 [14.3] 918 [36.1] 2XUPM Side View Figure 3-14. UPS Center of Gravity - FI-UPM and 2X UPMs ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 3-13...
  • Page 48: Figure 3-15. Ups Center Of Gravity - 3X Upms

    896 [35.3] 900 kVA UPS 850 [33.5] ISBM 357 [14.1] 362 [14.3] 918 [36.1] 3XUPM Side View Figure 3-15. UPS Center of Gravity - 3X UPMs ® ® 3-14 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 49: Figure 3-16. Ups Center Of Gravity - 2X Upms

    900-1 kVA UPS 896 [35.3] 850 [33.5] ISBM 357 [14.1] 362 [14.3] 918 [36.1] 2XUPM Side View Figure 3-16. UPS Center of Gravity - 2X UPMs ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 3-15...
  • Page 50: Ups System Power Wiring Preparation

    (from a Wye source) for proper equipment operation. The Eaton 9395P 480V unit is designed for operation on a grounded-wye source of supply. There is no additional connection point for a neutral conductor. The output of this UPS will not directly support phase to neutral loads.
  • Page 51 Because of the future upgradability to a fully rated 825 kVA UPS with the addition of the FI-UPM, the UPS wiring is specified for 825 kVA in these tables. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 52 Figure 6-15. NOTE Bypass wiring data is not applicable to IOM configurations. Battery Conductor Sizing: Eaton strongly recommends using the specified DC conductor size and quantity shown above for optimum system performance and battery run time. Battery Cable Routing Requirements Conduit applications: * Each conduit must have a Positive, Negative, and Ground conductor.
  • Page 53 If an overlapping neutral or make-before-break ATS switch is used, the neutrals must overlap for a minimum of 50 ms during the transition. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 54 Figure 6-15. NOTE Bypass wiring data is not applicable to IOM configurations Battery Conductor Sizing: Eaton strongly recommends using the specified DC conductor size and quantity shown above for optimum system performance and battery run time. Battery Cable Routing Requirements Conduit applications: * Each conduit must have a Positive, Negative, and Ground conductor.
  • Page 55 If an overlapping neutral or make-before-break ATS switch is used, the neutrals must overlap for a minimum of 50 ms during the transition. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 56 Figure 6-15. NOTE Bypass wiring data is not applicable to IOM configurations Battery Conductor Sizing: Eaton strongly recommends using the specified DC conductor size and quantity shown above for optimum system performance and battery run time. Battery Cable Routing Requirements Conduit applications: * Each conduit must have a Positive, Negative, and Ground conductor.
  • Page 57 If an overlapping neutral or make-before-break ATS switch is used, the neutrals must overlap for a minimum of 50 ms during the transition. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 58 Figure 6-15. NOTE Bypass wiring data is not applicable to IOM configurations Battery Conductor Sizing: Eaton strongly recommends using the specified DC conductor size and quantity shown above for optimum system performance and battery run time. Battery Cable Routing Requirements Conduit applications: * Each conduit must have a Positive, Negative, and Ground conductor.
  • Page 59 If an overlapping neutral or make-before-break ATS switch is used, the neutrals must overlap for a minimum of 50 ms during the transition. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 60 Figure 6-15. NOTE Bypass wiring data is not applicable to IOM configurations Battery Conductor Sizing: Eaton strongly recommends using the specified DC conductor size and quantity shown above for optimum system performance and battery run time. Battery Cable Routing Requirements Conduit applications: * Each conduit must have a Positive, Negative, and Ground conductor.
  • Page 61 90°C. See Table 3-17 for power cable terminations, Table 3-18 for supplied terminal hardware, and Table 3-21 for recommended installation parts and tools not supplied by Eaton. The torque values listed in Table 3-17 for the M8 studs are the maximum allowable. Tightening further will risk breaking or twisting the stud.
  • Page 62 3E5A (UPM 4) Table 3-18. Supplied Intercabinet Wiring Terminal Hardware Kit Part Size Quantity Terminals Used On Eaton Part Number UPM AC Input, UPM Battery Input, UPM AC Flat Washer 180500036-080 Output UPM AC Input, UPM Battery Input, UPM AC...
  • Page 63 90°C. See Table 3-19 for power cable terminations, Table 3-20 for supplied terminal hardware, and Table 3-21 for recommended installation parts and tools not supplied by Eaton. Figure 4-17 through Figure 4-20 show the location of the power cable terminals inside the UPS.
  • Page 64 180500037-120 Output, and Ground Rectifier Input, Bypass Input, Battery Input, 180200001-07 Output, and Ground NOTE Bypass terminations are not applicable to IOM configurations. Table 3-21. Recommended Installation Parts and Tools (Not Supplied by Eaton) Part Size Quantity Manufacturer Part Number...
  • Page 65 Terminal Wires in Trade Size Conduits Conduit AC Input to UPS Rectifier (A, B, C, Ground) 480 Vac Eaton 9395P-900/900* AC Input to Bypass and Output Eaton 9395P-900/900 (A, B, C, Ground) Eaton 9395P-900/825 Battery (Common (Positive, Negative, Ground) Battery)
  • Page 66 Trade Size Conduits AC Input to UPS Rectifier (A, B, C, Ground) 415 Vac AC Input to Bypass and Output Eaton 9395P-900/825 (A, B, C, Ground) Battery (Common Battery) (Positive, Negative, Ground) AC Input to UPS Rectifier (A, B, C, Ground)
  • Page 67 Conduits AC Input to UPS Rectifier (A, B, C, Ground) 400 Vac 380 Vac AC Input to Bypass and Output Eaton 9395P-900/825 (A, B, C, Ground) Battery (Common Battery) (Positive, Negative, Ground) AC Input to UPS Rectifier (A, B, C, Ground)
  • Page 68 Wires in Conduit Trade Size Conduits AC Input to UPS Rectifier (A, B, C, Ground) 400 Vac 380 Vac Eaton 9395P-900/450 AC Input to Bypass and Output See Note 1 (A, B, C, Ground) Battery (Common Battery) (Positive, Negative, Ground)
  • Page 69 1000A 1000A 1000A NOTE Because of the future upgradability to a fully rated 900 kW UPS with the addition of the FI-UPM, Eaton recommends using the breaker size specified for a 1100 kW UPS. CAUTION To reduce the risk of fire, connect only to a circuit provided with maximum input circuit breaker current ratings from Table 3-25 in accordance with the NEC, ANSI/NFPA 70.
  • Page 70 800A 800A NOTE Because of the future upgradability to a fully rated 900 kW UPS with the addition of the FI-UPM, Eaton recommends using the breaker size specified for a 1100 kW UPS. There is no manual DC disconnect device within the UPS.
  • Page 71 UPS Installation Plan and Unpacking Table 3-28. Recommended DC Input Battery Disconnect Ratings – Separate Battery Input Rating (each UPM) UPS Model 480V Eaton 9395P-900/900* 800A Eaton 9395P-900/600* Eaton 9395P-900/900 Eaton 9395P-900/825 Eaton 9395P-900/750 Eaton 9395P-900/675 700A Eaton 9395P-900/600 Eaton 9395P-900/550...
  • Page 72: Ups System Interface Wiring Preparation

    REPO wiring should be a minimum of 22 AWG and a maximum of 14 AWG. The REPO switch wiring must be in accordance with NEC Article 725 Class 2 requirements. ® ® 3-38 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 73: Distributed Bypass Power Wiring Preparation

    The UPS sections are heavy (see Table 3-1). If unpacking and unloading instructions are not closely followed, the cabinets may tip and cause serious injury. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 3-39...
  • Page 74 Si ces instructions ne sont pas suivies, des dommages au câblage et à son canal surviendront. Carefully inspect the outer packaging for evidence of damage during transit. CAUTION Do not install a damaged cabinet. Report any damage to the carrier and contact an Eaton service representative immediately. ®...
  • Page 75 Inspect the contents for any evidence of physical damage, and compare each item with the Bill of Lading. If damage has occurred or shortages are evident, contact an Eaton service representative immediately to determine the extent of the damage and its impact on further installation.
  • Page 76: Figure 3-18. Ups Cabinet As Shipped On Pallet (Isbm Section)

    UPS Installation Plan and Unpacking For 4-wire systems only Figure 3-18. UPS Cabinet as Shipped on Pallet (ISBM Section) ® ® 3-42 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 77: Figure 3-19. Ups Cabinet As Shipped On Pallet (Upm Section)

    UPS Installation Plan and Unpacking Figure 3-19. UPS Cabinet as Shipped on Pallet (UPM Section) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 3-43...
  • Page 78 UPS Installation Plan and Unpacking This page intentionally left blank. ® ® 3-44 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 79: Ups System Installation

    éviter de renverser les armoires, ce qui pourrait causer de graves blessures. CAUTION Do not tilt cabinets more than 10° from vertical. Lift the cabinets only with a forklift or damage may occur. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 80 Remove the three bolts securing the left side shipping bracket to the cabinet and three bolts securing the bracket to the pallet (see Figure 4-1 or Figure 4-3). Remove the left side shipping bracket. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 81: Figure 4-1. Removing The Isbm Section Left Side Shipping Bracket

    (see Figure 4-2 or Figure 4-4). Remove the right side shipping bracket. Front Door Pallet Shipping Bracket Bolts Shipping Bracket Left Side Shipping Bolts Bracket Figure 4-1. Removing the ISBM Section Left Side Shipping Bracket ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 82: Figure 4-2. Removing The Isbm Section Right Side Shipping Bracket

    Pull the pallet from under the cabinet. Discard or recycle the pallet and shipping brackets in a responsible manner. Carefully lower the cabinet until the cabinet base contacts the floor. Repeat Steps 2 through 6 for the remaining cabinet. Proceed to paragraph 4-3. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 83: Figure 4-3. Removing The Upm Section Left Side Shipping Bracket

    UPM Removable Front Panels Pallet Shipping Bracket Bolts Wireway Panel Shipping Bracket Left Side Shipping Bolts Bracket Figure 4-3. Removing the UPM Section Left Side Shipping Bracket ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 84: Mechanically Joining The Sections

    Retain the hardware for later use. Remove the screws securing the corner channel and remove the channel (see Figure 4-5). Retain the hardware for later use. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 85: Figure 4-5. Section Joining

    (UPM). NOTE Clearance between the ISBM and the UPM sections must be less than 1/2” so that joining brackets can be installed. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 86: Figure 4-6. Isbm And Upm Sections Joined

    ISBM and UPM sections. Secure the bracket with the screws from the hardware kit (see Figure 4-7). 13. Proceed to paragraph 4.4. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 87: Electrically Connecting The Sections

    Locate the AC and DC input intercabinet power wiring harnesses (long cables labeled xG1, xG2, and xG3). Remove wire ties as necessary and uncoil the cables. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 88 UPM model and secure the hardware (see Figure 4-9). This hardware is used by an Eaton Customer Service Engineer to install a Field Installed UPM (FI-UPM). 13. Locate the ground braid in the bottom left front corner of the UPM section. The ground braid is secured at the factory to the UPM section ground bolt.
  • Page 89 26. If installing a battery system, proceed to paragraph 4.6; otherwise, proceed to Step 27 . 27 . If installing a tie cabinet or distribution panel for a distributed bypass system, proceed to paragraph 4.7; otherwise, proceed to paragraph 4.8. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-11...
  • Page 90: Figure 4-8. Isbm Section Intercabinet Power Terminal Locations

    NOTE On a UPS configured with a Continuous Static Switch (CSS), CB4 is not installed. NOTE On a UPS configured as an Input Output Module (IOM), CB4 is not installed. Figure 4-8. ISBM Section Intercabinet Power Terminal Locations ® ® 4-12 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 91: Figure 4-9. Isbm Section Input Power Terminal Detail

    NOTE On a UPS configured as an IOM, UPM input wiring terminations are the same as an ISBM configuration. Figure 4-9. ISBM Section Input Power Terminal Detail ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 92: Figure 4-10. Isbm Section Battery Input Power Terminal Detail

    UPM 3 Cable 3G4 & 3G5 Gray For 4-wire systems only UPM 4 Cable 4G4 & 4G5 Gray Figure 4-11. ISBM Section Output Power Terminal Detail ® ® 4-14 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 93: Figure 4-12. Ups Intercabinet Interface Harness Locations

    P51, and P70 Harnesses Location of RJ-45 Coiled CAN Cable ISBM Section Right Side View UPM Section Left Side View Figure 4-12. UPS Intercabinet Interface Harness Locations ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-15...
  • Page 94: Figure 4-13. Pl1 Interface Board Location

    ISBM Section Right Side Inside View Figure 4-13. Pl1 Interface Board Location Pl1 Interface Board J39 Inverter CAN Connector Figure 4-14. J39 Location on Pl1 Interface Board ® ® 4-16 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 95: Field Installed Upm Installation

    UPS System Installation Field Installed UPM Installation ® If installing a Plus 1 configuration with an FI-UPM, install the FI-UPM using the instructions in the Eaton Power Xpert® 9395P UPS Field Installed UPM Mechanical Installation Manual (P-164000503) listed in paragraph 1.8.
  • Page 96: Installing Ups External And Battery Power Wiring

    ISBM section. Install the conduit plate and install all conduit runs into the plate. Pull wiring through conduit into the ISBM section wiring area. ® ® 4-18 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 97: Figure 4-15. Isbm And Upm Section Debris Shields

    Three UPM Section Front Ventilation Grill Debris Shields (Remove shields before operating system.) Two UPM Section Front Figure 4-15. ISBM and UPM Section Debris Shields ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-19...
  • Page 98: Figure 4-16. Isbm And Upm Section Conduit And Wire Entry Locations

    Input and Output, and DC Input (Remove panel to drill or punch conduit holes.) Figure 4-16. ISBM and UPM Section Conduit and Wire Entry Locations ® ® 4-20 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 99 11. Using hardware from the external wiring terminal hardware kit (see Table 3-20), connect phase A, B, and C power wiring from output terminals to the critical load. See paragraph 3.2.3 for wiring and termination requirements. 12. Proceed to paragraph 4.8.2. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-21...
  • Page 100: Figure 4-17. Isbm Section Power Terminal Locations

    For 4-wire systems only ISBM NOTE AC Input to Bypass terminals are not applicable to an IOM configuration. Figure 4-17. ISBM Section Power Terminal Locations ® ® 4-22 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 101: Figure 4-18. Isbm Section Power Terminal Detail Aa

    Phase C (E8) Section A–A NOTE AC Input to Bypass terminals are not applicable to an IOM configuration. Figure 4-18. ISBM Section Power Terminal Detail AA ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-23...
  • Page 102: Battery Power Wiring

    Se reporter au chapitre 10 sur les notices techniques pour connaître les tensions maximales du chargeur de batteries.Ne pas installer une armoire endommagée. Signaler les dommages au transporteur et communiquer avec un représentant du service Eaton immédiatement. To install wiring to connections: NOTE An installed FI-UPM is always designated as UPM 4.
  • Page 103: Figure 4-19. Isbm Section Power Terminal Detail Bb - Common Battery

    DC Input from Battery + (E4) Front DC Input from Battery – (E5) Section B–B Figure 4-19. ISBM Section Power Terminal Detail BB – Common Battery ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-25...
  • Page 104: Installing Interface Connections

    Hazardous voltages are present near the user interface terminal area if the UPS is not totally disconnected. AVERTISSEMENT! Des tensions dangereuses sont présentes près de l’enceinte du terminal de l’interface utilisateur si l’onduleur n’est pas totalement débranché. ® ® 4-26 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 105: Tb1, Tb2, And Tb3 Connections (Other Than Tb1 Battery Interface Connections)

    10. Reinstall the top internal safety shield panel and secure with the retained hardware. 11. Reinstall the front door removed in Step 3 and secure with the retained hardware. 12. Close the door and secure the latch. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-27...
  • Page 106: Figure 4-21. Isbm Section Interface Terminal Locations

    (See Figure 4‐27 for detail.) (See Figure 4‐22 for detail.) (See Figure 4‐24 for terminal assignments.) For 4-wire systems only ISBM Figure 4-21. ISBM Section Interface Terminal Locations. ® ® 4-28 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 107 Building Alarm 5 Return NOTE “Return“ indicates connection to electronics circuit ground. “Common” indicates connection to common side of isolated relay contact. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-29...
  • Page 108: Figure 4-22. Interface Terminal Detail

    NOTE Do not directly connect relay contacts to the mains related circuits. Reinforced insulation to the mains is required. NOTE Alarm relay wiring should be a minimum of 22 AWG. Figure 4-23. Typical Alarm Relay Connection ® ® 4-30 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 109: Figure 4-24. Terminal Blocks Tb1, Tb2, And Tb3 Connector Assignments

    NOTE A jumper wire must be connected between pins 1 and 2 on TB1, if the normally-closed REPO contact is not used. Figure 4-24. Terminal Blocks TB1, TB2, and TB3 Connector Assignments ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 110: Tb1 Battery Interface Connections

    11. Reinstall the front door removed in Step 3 and secure with the retained hardware. 12. If wiring X-Slot connections, proceed to paragraph 4.9.3; otherwise, proceed to Step 13. 13. Close the door and secure the latch. ® ® 4-32 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 111: Figure 4-25. Typical Battery Interface Connection - Common Battery System

    NOTE Battery aux and DC shunt trip wiring should be a minimum of 18 AWG. Figure 4-26. Typical Battery Interface Connection – Separate Battery System ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-33...
  • Page 112: X-Slot Connections

    When installing internal wiring to X-Slot terminals, route the wiring through the internal opening in the X-Slot communication bay. For installation and setup of an X-Slot card, contact an Eaton service representative (see page 1-10). To install wiring to connections: If not already installed, install the LAN drops.
  • Page 113: Installing A Repo Switch

    The REPO switch must be a normally-open or normally-closed latching-type switch not tied into any other circuits. NOTE This procedure is intended to be used for the installation of the Eaton-supplied REPO switch. If installing another manufacturer's switch, use this procedure only as a guide.
  • Page 114: Figure 4-29. Normally-Open Repo Switch Wiring

    13. Reinstall the top internal safety shield panel and secure with the retained hardware. 14. Reinstall the front door removed in Step 4 and secure with the retained hardware. 15. Close the door and secure the latch. ® ® 4-36 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 115: Figure 4-30. Normally-Closed Repo Switch Wiring

    NOTE REPO normally-open and normally-closed return terminals are separated on the terminal board but are electrically in common. Figure 4-31. Normally-Closed and Normally-Open REPO Switch Wiring ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-37...
  • Page 116: Installing Options, Accessories, And Distributed Bypass Control Wiring

    Checklist before filling it out, and retain the original. After the installation is complete, an Eaton Customer Service Engineer must verify the operation of the UPS system and commission it to support the critical load. The service representative cannot perform any installation tasks other than verifying software and operating setup parameters.
  • Page 117 Accessories are mounted in installed locations and wiring is terminated inside the UPS cabinet. (OPTIONAL) The debris shields covering the UPS cabinet ventilation grills are removed. Startup and operational checks are performed by an authorized Eaton Customer Service Engineer. ®...
  • Page 118 Controller Area Network (CAN) wiring between the UPS cabinets is properly installed. Pull-chain wiring between the UPS cabinets is properly installed. Adequate workspace exists around the UPS cabinets, the tie cabinet, and other cabinets. Startup and operational checks are performed by an authorized Eaton Customer Service Engineer ® ®...
  • Page 119 Installation Checklist Notes ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 4-41...
  • Page 120 Installation Checklist This page intentionally left blank. ® ® 4-42 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 121: Installing Options And Accessories

    Hot Sync CAN Bridge card (see paragraph 5.1) Parallel system wiring (see paragraph 5.2) RMP II (see paragraph 5.3) RIM II (see paragraph 5.4) SCM II (see paragraph 5.5) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 122: Installing An Optional Hot Sync Can Bridge Card

    Figure 4-21 and Figure 4-27 for X-Slot communication bay locations. To locate the appropriate terminals on the Hot Sync CAN Bridge Card, see Figure 5-2 and Table 5-1. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 123: Figure 5-2. Hot Sync Can Bridge Card Connections

    Normally-open contact closes when UPS is on bypass. RMP II, RIM II, and SCM II connections. CAN L Can H CAN input for parallel operation. Shield ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 124: Installing Distributed Bypass Control Wiring

    NOTE Setup of the Hot Sync CAN Bridge Card for parallel operation must be performed by an authorized Eaton Customer Service Engineer. Contact an Eaton service representative to schedule a date. 12. Reinstall the top internal safety shield panel and secure with the retained hardware.
  • Page 125: Figure 5-3. Distributed Bypass System Can And Pull-Chain Simplified Interface Wiring

    (If Installed) J3–8 (L) J3–8 (L) J3–8 (L) J3–8 (L) J3–9 (H) J3–9 (H) J3–9 (H) J3–9 (H) J3–10 (Shield) J3–10 (Shield) J3–10 (Shield) J3–10 (Shield) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 126: Figure 5-5. Distributed Bypass Pull-Chain Wiring Without Mobs

    TB2–1 TB2–1 (Pull Chain) (Pull Chain) (Pull Chain) (Pull Chain) TB2–2 TB2–2 TB2–2 TB2–2 (Pull Chain Common) (Pull Chain Common) (Pull Chain Common) (Pull Chain Common) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 127: Figure 5-6. Distributed Bypass Pull-Chain Wiring With Mobs

    NOTE Use twisted pair wiring between the UPS and MOB AUX contacts. NOTE Always confirm contact operation prior to wiring. Figure 5-6. Distributed Bypass Pull-Chain Wiring with MOBs ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 128 MOB 2 Aux 2 Com MOB 2 Aux 2 Com MOB 3 Aux 2 Com Pull Chain Common MOB 3 Aux 2 Com MOB 4 Aux 2 Com ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 129: Installing An Optional Remote Monitor Panel

    Close the front door and secure the latch. 10. Restart the UPS. See Chapter 7, “UPS Operating Instructions” for startup instructions ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 130: Figure 5-7. Remote Monitor Panel Ii And Relay Interface Module Ii Terminal Locations

    TB1–5 (RDX*) 0.9 (8) Use twisted pair J3–7 (TX) TB1–4 (RDX) 0.9 (8) TB3 Line 0.9 (8) TB3 Neutral 0.9 (8) Ground Terminal 2.7 (24) Maximum ® ® 5-10 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 131: Installing An Optional Relay Interface Module Ii

    If all connections are secure but the RMP II continues to self-test, replace the fuse with the spare included in the hardware kit. If a fuse replacement does not correct the problem, contact an Eaton service representative for verification that the RMP II is working correctly.
  • Page 132: Installing An Optional Supervisory Contact Module Ii

    Installing Options and Accessories 11. Contact an Eaton service representative for verification and testing of the RIM II and its connections prior to making connections with J1 through J4 (see Table 5-6 and Figure 5-9). You can order interface cables separately for connecting to the 15-Pin D-Sub Connectors.
  • Page 133: Figure 5-10. Supervisory Contact Module Ii Terminal Location

    Connections from the UPS Figure 5-10. Supervisory Contact Module II Terminal Location NOTE Setup of the Hot Sync CAN Bridge Card must be performed by an authorized Eaton Customer Service Engineer. Contact an Eaton service representative to schedule a date.
  • Page 134: Figure 5-11. Supervisory Contact Module Ii Tb2

    Supervisory contacts are rated at 2.0A at 28 Vdc or 120 Vac and 0.15A at 115 Vdc. NOTE Supervisory contacts require an external power supply. Internal 24 Vdc is not capable of supplying contact current. ® ® 5-14 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 135: Accessory Mounting Dimensions

    Surface Mount using #10 Pan Head Screws for Hanging. (Mount with vent holes facing up.) Dimensions are in millimeters [inches]. Figure 5-12. Remote Monitor Panel II Dimensions ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 5-15...
  • Page 136: Figure 5-13. Relay Interface Module Ii Dimensions

    Surface Mount using #10 Pan Head Screws for Hanging. (Mount with vent holes facing up.) Dimensions are in millimeters [inches]. Figure 5-13. Relay Interface Module II Dimensions ® ® 5-16 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 137: Figure 5-14. Supervisory Contact Module Ii Dimensions

    Surface Mount using #10 Pan Head Screws for Hanging. (Mount with vent holes facing up.) Dimensions are in millimeters [inches]. Figure 5-14. Supervisory Contact Module II Dimensions ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 5-17...
  • Page 138 Installing Options and Accessories This page intentionally left blank. ® ® 5-18 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 139 Section II Operation...
  • Page 141: Understanding Ups Operation

    Chapter 6 Understanding UPS Operation UPS System Overview The Eaton Power Xpert 9395P-900 UPS is a continuous-duty, solid-state, transformerless (at 480 Vac), three-phase, true online system that provides conditioned and uninterruptible AC power to the UPS system's output and critical load.
  • Page 142: Single Ups

    DC from the rectifier and uses IGBT devices and pulse-width modulation (PWM) to produce a regulated and filtered AC output. The AC output of the inverter is delivered to the system output through the output contactor K3. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 143: Figure 6-2. Path Of Current Through The Ups In Online Mode

    If the UPS suffers an internal failure, it switches automatically to Bypass mode and remains in that mode until the failure is corrected and the UPS is back in service. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 144: Energy Saver System (Ess) Mode

    (customer configurable). At the completion of the hour, the UPS defaults back to VMMS mode. If the High Alert command is received during the one hour, the one hour timer will be restarted. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 145: Bypass Mode

    K3 opens to isolate the inverter. The backfeed protection contactor is normally closed, ready to support the static switch unless the bypass input source becomes unavailable ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 146: Battery Mode

    DC voltage level is reached where the inverter output can no longer support the shared loads. If the bypass source is available, the UPS transfers to bypass instead of shutting down. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 147: Figure 6-4. Path Of Current Through The Ups In Battery Mode

    NOTE On a UPS configured with a Continuous Static Switch (CSS), bypass breaker (CB4) is not present. Figure 6-4. Path of Current Through the UPS in Battery Mode ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 148: Single Ups Unit System Oneline Configurations

    Table 6-1. Oneline Configurations Oneline Drawing UPS Model System Type Figure 6-5 on page 6-10 Eaton 9395P-900/900* Single Reverse Transfer UPS – Four UPM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch Eaton 9395P-900/900 Eaton 9395P-900/825 Eaton 9395P-900/750...
  • Page 149 Understanding UPS Operation Table 6-1. Oneline Configurations (Continued) Oneline Drawing UPS Model System Type Figure 6-13 on page 6-18 Eaton 9395P-900/900* Single Reverse Transfer UPS – Three UPM, Common Rectifier Feed, Common Battery, IOM Configuration Eaton 9395P-900/900 Eaton 9395P-900/825 Eaton 9395P-900/750...
  • Page 150: Figure 6-5. Four Upm, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters , and map to Table 3‐7. Figure 6-5. Four UPM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch ® ® 6-10 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 151: Figure 6-6. Four Upm, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters , and map to Table 3‐8 . Figure 6-6. Four UPM, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-11...
  • Page 152: Figure 6-7. Three Upm, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters , and map to Table 3‐7. Figure 6-7. Three UPM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch ® ® 6-12 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 153: Figure 6-8. Three Upm, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters , and map to Table 3‐8 . Figure 6-8. Three UPM, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-13...
  • Page 154: Figure 6-9. Two Upm, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch

    (Not supplied with the UPS) NOTE Callout letters , and map to Table 3-7 Figure 6-9. Two UPM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch ® ® 6-14 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 155: Figure 6-10. Two Upm, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch

    (Not supplied with the UPS) NOTE Callout letters , and map to Table 3-10. Figure 6-10. Two UPM, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-15...
  • Page 156: Figure 6-11. Three Upm, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters map to Table 3‐7. , and Figure 6-11. Three UPM, Common Rectifier Feed, Common Battery, Dual-Feed Configuration, Continuous Static Switch ® ® 6-16 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 157: Figure 6-12. Three Upm, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch

    Service Connector NOTE Callout letters , and map to Table 3‐8. Figure 6-12. Three UPM, Common Rectifier Feed, Separate Battery, Dual-Feed Configuration, Continuous Static Switch ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-17...
  • Page 158: Figure 6-13. Three Upm, Common Rectifier Feed, Common Battery, Iom Configuration

    (Not supplied with the UPS) Service Connector NOTE Callout letters map to Table 3‐7. , and Figure 6-13. Three UPM, Common Rectifier Feed, Common Battery, IOM Configuration ® ® 6-18 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 159: Figure 6-14. Three Upm, Common Rectifier Feed, Separate Battery, Iom Configuration

    (Not supplied with the UPS) Service Connector NOTE Callout letters map to Table 3‐7 . , and Figure 6-14. Three UPM, Common Rectifier Feed, Separate Battery, IOM Configuration ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-19...
  • Page 160: Figure 6-15. Four Upm, Common Rectifier Feed, Common Battery, Iom Configuration

    (Not supplied with the UPS) Service Connector NOTE Callout letters , and map to Table 3‐7 . Figure 6-15. Four UPM, Common Rectifier Feed, Common Battery, IOM Configuration ® ® 6-20 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 161: Figure 6-16. Four Upm, Common Rectifier Feed, Separate Battery, Iom Configuration

    (Not supplied with the UPS) Service Connector NOTE Callout letters , and map to Table 3‐8 . Figure 6-16. Four UPM, Common Rectifier Feed, Separate Battery, IOM Configuration ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-21...
  • Page 162: Figure 6-17. Simplified Dual-Feed Ups With Maintenance Bypass Panel

    (BIB) is installed in the maintenance bypass and a single-feed UPS is being installed, a single feed to the maintenance bypass is acceptable for supplying both the UPS and the bypass. Figure 6-17. Simplified Dual-Feed UPS with Maintenance Bypass Panel ® ® 6-22 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 163: Multiple Ups Distributed Bypass System

    The UPSs switch operating modes in response to these system events: ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 164: Online Mode - Distributed Bypass

    Battery Breakers Closed Output to Main Power Flow Critical Load Open Figure 6-18. Path of Current through the UPSs in Online Mode - Distributed Bypass ® ® 6-24 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 165: Bypass Mode - Distributed Bypass

    Battery Breakers Closed Output to Main Power Flow Critical Load Open Figure 6-19. Path of Current through the UPSs in Bypass Mode - Distributed Bypass ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-25...
  • Page 166: Battery Mode - Distributed Bypass

    UPMs begin shutting down until there are no longer enough UPMs online to support the connected load. When this event occurs, the system shuts down. If the bypass source is available, the system transfers to bypass instead of shutting down. ® ® 6-26 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 167: Figure 6-20. Path Of Current Through The Upss In Battery Mode - Distributed Bypass

    ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 168: Multiple Ups Distributed Bypass System Oneline Configurations

    Table 6-2. Multiple UPS Distributed Bypass System Oneline Configurations Oneline Drawing UPS Model System Type Figure 6-21 on page 6-29 Eaton 9395P-900/900* Multiple UPS – Distributed Bypass, Continuous Static Switch, 1+1 and 2+0 Eaton 9395P-900/900 Configurations Eaton 9395P-900/825 Eaton 9395P-900/750...
  • Page 169: Figure 6-21. Typical Distributed Bypass System - Continuous Static Switch, 1+1 And 2+0 Configurations

    Critical Load structure of each UPS is shown in Figure 6‐8. Figure 6-21. Typical Distributed Bypass System - Continuous Static Switch, 1+1 and 2+0 Configurations ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-29...
  • Page 170: Figure 6-22. Typical Distributed Bypass System -Continuous Static Switch, 2+1 And 3+0 Configurations

    NOTE This oneline does not show each UPM in the UPSs, but represents each UPS in the distributed bypass system. The internal Critical Load structure of each UPS is shown in Figure 6‐8. Figure 6-22. Typical Distributed Bypass System -Continuous Static Switch, 2+1 and 3+0 Configurations ® ® 6-30 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 171: Figure 6-23. Typical Distributed Bypass System -Continuous Static Switch, 3+1 And 4+0 Configurations

    NOTE This oneline does not show each UPM in the UPSs, but represents each UPS in the distributed bypass system. The internal Critical Load structure of each UPS is shown in Figure 6‐8. Figure 6-23. Typical Distributed Bypass System -Continuous Static Switch, 3+1 and 4+0 Configurations ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 6-31...
  • Page 172 Understanding UPS Operation This page intentionally left blank. ® ® 6-32 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 173: Ups Operating Instructions

    The control panel is used to set up and control the UPS, and to monitor UPS operation. For a description of the UPS control panel functions, see paragraph 7.3. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 174: Circuit Breakers

    For a description of the UPS control panel functions, see paragraph 7.3. Color Touchscreen Control Panel ISBM Figure 7-2. UPS Color Touchscreen Control Panel (Typical) ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 175: Using The Color Touchscreen Control Panel

    When the unit powers up, the screen displays as shown in Figure 7-3. When power is applied to the system, the display advances to the Sign In screen shown in Figure 7-4. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 176 Touching anywhere on the screen brings up the Sign In Request pop-up. Touch the X in the upper right corner of the pop-up, then touch the padlock symbol in the upper right corner to obtain the password request pop-up (see Figure 7-5). ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 177: Figure 7-4. Parts Of The Touch Screen

    UPS Operating Instructions Figure 7-4. Parts of the Touch Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 178: Figure 7-5. Sign In Or Password Request Screen

    The UPS status area automatically displays the Eaton model number, current time and date, active alarms, active notices, and load percent and battery run time for the UPS. If the Eaton Environmental Monitoring Probe is installed, the temperature and humidity sensed by the probe will also be displayed. The small head symbol between the system model and time allows the operator select a different language from an imbedded list.
  • Page 179: Figure 7-6. Home Screen

    Yellow lines indicates an out-of-tolerance condition. NOTE Screens shown are representative examples of system operation. The screen data will vary based on system activity at the time of observation. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 180: Figure 7-7. Main Menu And Power Maps Screen (Online Mode)

    Figure 7-7. Main Menu and Power Maps Screen (Online Mode) Touching the LOAD kVA button displays the Output kVA screen shown in Figure 7-8. Figure 7-8. Output kVA Screen from Home Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 181: Figure 7-9. Average Efficiency Screen From Home Screen

    Figure 7-9. Average Efficiency Screen from Home Screen Touching the CONSUMPTION button displays the screen shown in Figure 7-10. Figure 7-10. Consumption Screen from Home Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 182: Figure 7-11. Bypass Screen

    Figure 7-12 is an example of a command request confirmation pop-up screen. This type of pop-up allows the user to confirm that the requested command is valid. Figure 7-12. Typical Command Confirmation Screen (Charger Off) ® ® 7-10 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 183: Figure 7-13. Meters Summary Screen

    24 hours, 7 days, 30 days, or 1 year. This is true of all the meters screens listed in the top section. Figure 7‐9 Figure 7‐10 Figure 7-13. Meters Summary Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-11...
  • Page 184: Figure 7-14. Input Meters Screen

    Figure 7-14. Input Meters Screen The Bypass Meters Screen shown in Figure 7-15 displays values pertaining to the Bypass conditions. Figure 7-15. Bypass Meters Screen ® ® 7-12 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 185: Figure 7-16. Output Meters Screen

    UPS Operating Instructions The Output Meters Screen shown in Figure 7-16 displays values pertaining to the system output. Figure 7-16. Output Meters Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-13...
  • Page 186: Figure 7-17. Input Meters Detail Screen

    Figure 7-17. Input Meters Detail Screen The Select Source screen shown in Figure 7-18 allows the operator to choose the individual source for system readings. Figure 7-18. Select Source Screen ® ® 7-14 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 187: Figure 7-19. Battery Meters Screen

    Figure 7-19 shows the Battery Meters basic screen. Figure 7-20 shows the Battery Log access screen. Figure 7-19. Battery Meters Screen Figure 7-20. Battery Log Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-15...
  • Page 188: Figure 7-21. Battery Log Detail

    Figure 7-21 shows the Battery Log Detail screen. Figure 7-22 shows the Battery Log Summary screen. Figure 7-21. Battery Log Detail Figure 7-22. Battery Log Summary Screen ® ® 7-16 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 189: Figure 7-23. System Events Screen

    This message is also written to the Active Events Log and may be added to the History Log. The messages are divided into four categories: alarms, notices, status, and commands. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 190: Figure 7-24. User Log Screen

    Selecting an event opens the Event Detail screen shown in Figure 7-25. This screen details the specifics of the event for the user to see. Figure 7-25. User Log Detail Screen ® ® 7-18 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 191: Figure 7-26. System Status Screen

    Figure 7-27 shows the Module Controls screen. This screen allows control of the individual modules within the system. It also gives their values and status. Figure 7-27. Module Controls Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-19...
  • Page 192: Figure 7-28. Module Control Detail Screen

    The Metering Method screen allows the operator to select line-to-line or line-to-neutral monitoring values. See Figure 7-29 or Figure 7-30. Figure 7-29. Online Mode Metering Method Option Screen ® ® 7-20 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 193: Figure 7-30. Bypass Mode Metering Method Option Screen

    Touching the CLEAN SCREEN button disables the screen for 30 seconds to allow the user to safely clean the screen without affecting operation. Figure 7-31. Settings Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-21...
  • Page 194: Figure 7-32. Configuration Options Screen

    The various Energy Advantage Architecture operations are described in the UPS Installation and Operation manual for your system. Figure 7-33. Energy Advantage Architecture (EAA) Screen ® ® 7-22 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 195: Figure 7-34. Disable Ess Screen

    Figure 7-35. High Alert Timer Screen This screen shown in Figure 7-35 asks the operator if they want to start the High Alert mode timer. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-23...
  • Page 196: Figure 7-36. Statistics Basic Screen

    The screen shown in Figure 7-36 allows the operator to query the system for various operational statistics such as shown in Figure 7-37. Figure 7-36. Statistics Basic Screen Figure 7-37. Statistics Data Detail Screen ® ® 7-24 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 197: Figure 7-38. Ess Comparison Screen

    Figure 7-38. ESS Comparison Screen 7.3.19 UPS Module Map Screen The screen shown Figure 7-39 allows the operator to control the individual UPMs. Figure 7-39. UPS Module Map Screen ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-25...
  • Page 198: Figure 7-40. System Overview Screen

    UPS Operating Instructions 7.3.20 System Overview Screen The screen shown Figure 7-40 displays values for all UPS and UPM parameters. Figure 7-40. System Overview Screen ® ® 7-26 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 199 UPS Operation using the Color Touchscreen Control Panel NOTE The Energy Saver System mode commands are displayed only if installed at the factory or by an Eaton Customer Service Engineer. NOTE The Variable Module Management System and Energy Saver System modes are mutually exclusive.
  • Page 200 à l’étape suivante. N’utiliser cette fonction que pour mettre la charge critique hors tension. NOTE The following instructions are for the Eaton-supplied REPO switch. If a customer-supplied REPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch.
  • Page 201: Figure 7-41. Repo Operation

    L ’intérieur de l’armoire de l’onduleur est alimenté jusqu’à ce que le disjoncteur du circuit d’alimentation en amont soit activé. Activated Deactivated Pushbutton locked into place Unlock pushbutton to release Figure 7-41. REPO Operation ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-29...
  • Page 202 The UPM status indicates ONLINE, CHARGING on the MIMIC Screen. 17 . To activate, enable, or disable any of the UPS operational modes, follow the online screen prompts. ® ® 7-30 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 203 Press the CONTROLS pushbutton on the main menu bar. The System Status screen is displayed. On the System Status screen, the UPS status should indicate SHUTDOWN and the UPM status should indicate OFFLINE. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-31...
  • Page 204 To restart a single UPM from a shutdown state: Press the CONTROLS pushbutton on the main menu bar. The System Status screen is displayed. On the System Status screen, select the UPM command. ® ® 7-32 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 205 The input, output, battery, and bypass backfeed contactors open, and the power module is turned off on the UPS being shut down. Logic power remains on. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-33...
  • Page 206 UPMs are shut down. 12. Perform the LOAD OFF procedure in paragraph 7.5.11 or paragraph 7.5.12 on the UPS being shut down. ® ® 7-34 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 207 13. Press the CONTROLS pushbutton on the System Status menu bar. The UPS Control Command screen is displayed. 14. On the UPS Control Command screen, select GO TO ONLINE. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-35...
  • Page 208 Press the CONTROLS pushbutton on the System Status menu bar. The Charger Control Command screen is displayed. On the Charger Control Command screen, select CHARGER ON. Press the SELECT pushbutton on the Charger Command menu bar. ® ® 7-36 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 209 Restart the UPS after pressing the LOAD OFF pushbutton by following the procedure in paragraph 7.5.1 or 7.5.2. WARNING Power is present inside the UPS cabinet until the upstream input feeder circuit breaker is opened. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality 7-37...
  • Page 210 Restart the UPS by following the procedure in paragraph 7.5.1 or 7.5.2. WARNING Power is present inside the UPS cabinet until the upstream input feeder circuit breaker is opened. ® ® 7-38 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 211 NOTE The following instructions are for the Eaton-supplied REPO switch. If a customer-supplied REPO switch is used, it may not activate in the same manner; refer to the operating instructions provided with the switch.
  • Page 212 UPS Operating Instructions This page intentionally left blank. ® ® 7-40 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 213: Figure 8-1. Optional X-Slot Cards

    LAN drops for use with X-Slot connectivity cards must be provided by facility planners or the customer. For installation and setup of an X-Slot card, contact an Eaton service representative (see page 1-10). Refer to the manual supplied with the X-Slot card for user instructions.
  • Page 214 Real-time alarm events for all subscribed devices via the PredictPulse mobile app (Apple and Android). You can track all alarms by device. As critical alarms occur, Eaton will acknowledge them so you know when Eaton has diagnosed the alarm (and pending notification of resolution).
  • Page 215 The software’s mass configuration capabilities make installation and maintenance easy, which minimizes the effort required and benefits the bottom line. Eaton’s cost effective Intelligent Power Software manages up to ten devices at no charge, with licences for up to 100 devices – or even an unlimited number – also available.
  • Page 216: Figure 8-2. Remote Monitor Panel Ii

    The RMP II can be flush-mounted or surface-mounted on a desktop, or secured to a wall. Figure 8-2 shows an RMP II. Figure 8-2. Remote Monitor Panel II ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 217 The UPS is preparing to shut down because the UPS is in Battery mode and the DC voltage is approaching its low limit. This indicator is accompanied by a horn. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 218: Figure 8-3. Relay Interface Module Ii

    Contacts are closed when approximately two minutes of battery time is remaining before the BATTERY WEAK Pins 5 and 14 critical load is lost. UTILITY FAILURE Pins 6 and 15 Contacts are closed when Utility Failure is detected. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 219: Supervisory Contact Module Ii

    BYPASS NOT AVAILABLE TB2-10 through TB2-12 ON BATTERY TB2-13 through TB2-15 UPS ALARM TB2-16 through TB2-18 ON BYPASS TB2-19 through TB2-21 SHUTDOWN IMMINENT TB2-22 through TB2-24 ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 220 Communication This page intentionally left blank. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 221: Ups Maintenance

    THE BATTERY STRING YOURSELF. VOLTAGES ARE ALWAYS PRESENT IN THE BATTERY STRING. If you suspect that a battery string needs service, contact an Eaton service representative. If the string requires service, refer to the battery manufacturer's operating manual for instructions on battery maintenance or contact an Eaton service representative.
  • Page 222: Performing Preventive Maintenance

    Check the UPS air filters (located behind the front panels or door) and wash or replace as necessary. See Figure 9-1 and Figure 9-3 for filter locations, and Table 9-1 for filter sizes. Contact an Eaton service representative for replacement filters. To remove and replace the filters: Table 9-1.
  • Page 223 Reinstall the ISBM section front panel removed in Step b. and secure with the retained hardware. If opened, close the front door and secure the latch. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 224: Figure 9-1. Isbm Section Air Filter Locations - Continuous Static Switch

    UPS Maintenance ISBM Air Filter UPM Air Filters ISBM Air Filter Figure 9-1. ISBM Section Air Filter Locations – Continuous Static Switch ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 225: Figure 9-2. Upm Section Air Filter Locations

    If the UPS configuration included an FI-UPM model, check the FI-UPM air filter (located behind the front panel) and wash or replace as necessary. See Figure 9-3 for the filter location. The FI-UPM filter size is 20” X 44” X 0.25” . Contact an Eaton service representative for a replacement filter. To remove the filter: ®...
  • Page 226: Periodic Maintenance

    9.2.4 ANNUAL Maintenance Annual preventive maintenance should be performed only by authorized service personnel familiar with maintenance and servicing of the UPS system. Contact an Eaton service representative for more information about service offerings. 9.2.5 BATTERY Maintenance Contact an Eaton service representative for battery maintenance.
  • Page 227: Installing Batteries

    Ne pas éliminer les déchets d’équipements électriques et électroniques (DEEE) aux ordures. Pour connaître la méthode d’élimination appropriée, communiquer avec le centre régional de récupération/réutilisation ou d’élimination des déchets dangereux. ® ® Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 228: Maintenance Training

    UPS Maintenance Maintenance Training A basic training course, available from Eaton, gives you a competent working knowledge of the UPS system operation and teaches you how to perform first level corrective maintenance. For more information about training and other services, contact the Eaton Help Desk (see page 1-10).
  • Page 229: Product Specifications

    The UPS is available in 50 or 60 Hz with various output power ratings. Models Power Rating Frequency Eaton 9395P-900/900* (three or four UPM) 900 kVA, 900 kW 50/60 Hz Eaton 9395P-900/900 (three or four UPM)
  • Page 230: 10.2.2 Ups Output

    Electrostatic Discharge (ESD) Meets IEC 801-2 specifications. Withstands up to 25 kV pulse without damage and with Immunity no disturbance or adverse effect to the critical load. ® ® 10-2 Eaton Power Xpert 9395P-900 UPS Installation and Operation Manual P-164000501—Rev 09 www.eaton.com/powerquality...
  • Page 232 *P-164000501 6* P-164000501 9...

Table of Contents
