Appendix B – EasyAG Series II RS232 Technical Specifications
Downloading Readings from Probe
Fuse F201
TTL Port – located at back of interface
JP201
Probe Cable
Red
Orange
Brown
Black
Blue
Purple
Green
Yellow
Green Phoenix connector

Figure 11: EasyAG series II RS232 probe interface board layout

Copyright © 2008-2012 Sentek Pty Ltd All rights reserved
Page 19
