Probe Cable
+V
Red
IN
+V
(T)
Orange
IN
+V
(T) Brown
OUT
Ground
Black
TX
Blue
RX
Purple
RTS
Green
CTS
Yellow
Figure 10: EnviroSCAN series II RS232 probe interface board layout
Copyright © 2008-2012 Sentek Pty Ltd All rights reserved
Appendix A – EnviroSCAN Series II RS232 Technical Specifications
Green Phoenix connector
Fuse F201
Fuse F202
Downloading Readings from Probe
JP201
TTL Port
Page 17
