Connection of the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consultation with the dealer or an experienced radio/TV technician. The Sentek SOLO system complies with the following specifications; • FCC Part 15 Subpart B Radio Frequency Devices – Unintentional Radiators •...
Head Unit ........................14 Batteries........................14 Appendix A – EnviroSCAN Series II RS232 Technical Specifications.... 16 Appendix B – EasyAG Series II RS232 Technical Specifications ....18 Appendix C - Sentek SOLO Quick Reference Guide........20 Product Set-up checklist.....................20 Preparation........................20 Field Installation ......................20 Downloading .........................20...
Sentek SOLO Introduction Background Sentek SOLO is a cost effective, continuous soil moisture and salinity monitoring solution. The system consists of a battery powered, logging probe connected to a Head Unit, which allows for in-field download via a laptop or SoloPORTER.
Page 11
System Setup Hardware Setup 4. The Sentek SOLO Head Unit comes with 2 x mounting brackets, allowing for either a horizontal or vertical orientation. Attach the mounting brackets in the desired position at the back of the Head Unit with supplied screws.
Probe Configuration Sentek SOLO probes can be configured either through the Head Unit using a Solo Download Cable or through the TTL port on the probe interface using a PConfig cable. Please refer to the PConfig User Guide or Help file for the complete usage instructions on how to configure Sentek probes.
4. If required, enter custom calibration coefficients for each sensor. Each coefficient should be separated by a semicolon (i.e. A;B;C). See the Sentek Calibration Manual for more information. 5. Save these settings to the probe by clicking Write to Probe.
1. Select Power tab to show the battery voltage supplied to the probe. The probe operating thresholds should only be changed after advice from Sentek. The probe supply voltage should be ≈ 6.1V with new batteries. Figure 8: Power tab...
“Calibrated Value” of individual sensors (ignore the “Total” row). d) Write to Probe (if required). The data from the Sentek SOLO probe is downloaded in-field using either a Solo Download Cable to a laptop, or the SoloPORTER. Download Using Solo Download Cable 1.
The graph in Figure 9 shows the typical curve of the voltage graph from a Sentek SOLO system. It should be noted that the actual life of the system may be less than shown. Factors such as sample frequency, ambient temperature, battery age, manufacturer, quality and other unpredictable factors could have an adverse effect on the life of the battery.
The above statement is provided purely as an estimate, based on a ‘best case’ operating scenario with standard Sentek parts. It should be noted that the actual life of the system may be less than 80% of the estimate provided above. Factors such as ambient temperature, battery age, manufacturer and other unpredictable factors could have an adverse effect on the life of the battery.
Product Set-up checklist This appendix is designed to be a short guide for installers of Sentek SOLO. It can be printed and carried into the field and act as a reminder for the basic steps needed to install a complete Sentek SOLO system.
