A
A
–
E
A
A
–
E
P
P
E
N
D
I
X
P
P
E
N
D
I
X
PCB Revision:
Identification Label:
Interface connector type:
RS232 Interface pin configuration:
Jumper
Fuse specifications:
Voltage Supply (RS232 +Vin): 5 – 15 V DC (Solo nominal is 6V)
TTL Interface connector type: Brand: JST
TTL Interface pin configuration:
Voltage Supply (TTL +Vcc):
RS232 baud rate:
TTL Interface baud rate:
Total current consumption:
Time to sample 1 sensor:
Maximum sensors supported: 16 Moisture Sensors or
Copyright © 2008-2012 Sentek Pty Ltd All rights reserved
S
C
A
N
S
S
C
A
N
S
N
V
I
R
O
E
N
V
I
R
O
E
REV 2.3
XPI-SC-E RS232/485
Brand: Phoenix Contact
MC 1,5/8-ST-3,5 (Plug)
MC 1,5/8-G-3,5 (Socket)
1.
+Vin
2.
+Vin(T) Telemetry (not supported on Solo)
3.
+Vout(T) Telemetry (not supported on Solo)
4.
Ground
5.
TX – RS232 Data
6.
RX – RS232 Data
7.
Request to send (RTS acts as DTR in the Plus systems)
8.
Clear to Send (CTS)
JP201 Telemetry (not supported on Solo)
F201
F202
B 6B-PH-K (Socket)
PHR- 6 (Plug), SPH-002T-P0.5S (Crimp connectors)
1.
+Vcc
2.
Transmit data (Tx)
3.
Receive data (Rx)
4.
NC
5.
NC
6.
Ground
5 Volts, supplied by the probe interface
1200, 2400, 9600 (default), 19200 and 38400 bits/second
SoloPORTER only supports 9600 baud
1200, 2400, 9600 (default), 19200 and 38400 bits/second
400µA standby @ 12V DC
105mA sampling (Moisture) @ 12V DC
130mA Sampling (TriSCAN) @ 12V DC
45 milliseconds maximum (Moisture only)
90 milliseconds maximum (TriSCAN)
16 TriSCAN Sensors
Appendix A – EnviroSCAN Series II RS232 Technical Specifications
I
I
R
S
2
3
2
T
I
I
R
S
2
3
2
T
R
I
E
S
E
R
I
E
S
E
Littelfuse 0154-500 (500mA fast blow)
Littelfuse 0154-003 (3A fast blow, Unused Telemetry on Solo)
Downloading Readings from Probe
S
S
C
H
N
I
C
A
L
P
E
C
I
F
C
H
N
I
C
A
L
P
E
C
I
F
I
C
A
T
I
O
N
S
I
C
A
T
I
O
N
S
Page 16
