Broadcom PCIe 4.0 MegaRAID and HBA Tri-Mode Storage
Adapters
This document is the primary reference and user guide for the Broadcom
adapters and Broadcom PCIe 4.0 HBA tri-mode storage adapters, based on the Broadcom PCIe 4.0 tri-mode controller
devices. This document contains the complete installation instructions and specifications for the following PCIe 4.0
tri‑mode storage adapters, referred to as adapters.
•
MegaRAID 9560-16i
•
MegaRAID 9560-8i
•
MegaRAID 9580-8i8e
•
HBA 9500-16i
•
HBA 9500-8i
•
HBA 9500-16e
•
HBA 9500-8e

Overview

The adapters, based on the SAS3916, SAS3908, SAS3816, or SAS3808 tri-mode controller, are high-performance
PCIe-to-SATA/SAS/PCIe (tri-mode) storage adapters. Broadcom tri-mode SerDes technology enables operation of
SAS, SATA, or PCIe (NVMe) storage devices in a single drive bay. A single controller can operate in all three modes
concurrently: SAS, SATA, and PCIe/NVMe. The adapters negotiate between the speeds and the protocols to recognize
and concurrently interface with these three storage devices types.
The adapters provide the following storage interface data transfer rates:
•
SAS data transfer rates of 12Gb/s, 6Gb/s, and 3Gb/s per phy
•
SATA transfer rates at 6Gb/s and 3Gb/s per phy
•
PCIe (NVMe) data transfer rates of 16 GT/s, 8 GT/s, 5 GT/s, and 2.5 GT/s per lane
The following tables summarize key adapter features.
Table 1: MegaRAID Tri-Mode Storage Adapter Features
Adapter
Ports
I/O Processor
Form Factor
Storage Interface Connectors
Host Interface
Storage Interface
Cache Memory
Cache Protection
Super Capacitor
Broadcom
9560-16i
16 internal
SAS3916
LP-MD2
Two SFF-8654 x8
x8 PCIe 4.0
SAS, SATA, and PCIe (NVMe)
8 GB, 2666 MT/
s, DDR4 SDRAM
Yes
CVPM05 module
®
Broadcom 95xx PCIe 4.0 MegaRAID
®
PCIe 4.0 MegaRAID
9560-8i
8 internal
SAS3908
LP-MD2
One SFF-8654 x8
x8 PCIe 4.0
SAS, SATA, and PCIe (NVMe)
4 GB, 2666 MT/
s, DDR4 SDRAM
Yes
CVPM05 module
®
and HBA Tri-Mode Storage Adapters
®
tri-mode storage
9580-8i8e
8 internal,
8 external
SAS3916
LP-MD2
One SFF-8654 x8,
Two SFF-8644 x4
x8 PCIe 4.0
SAS, SATA, and PCIe (NVMe)
8 GB, 2666 MT/
s, DDR4 SDRAM
Yes
CVPM05 module
