Tri-Mode Storage Adapter Technical Specifications

Operating and Nonoperating Conditions

The following table lists the operating (thermal and atmospheric) conditions and nonoperating (such as storage and
transit) environment for the storage adapters. The minimum airflow, measured as linear feet per minute (LFPM)
at 55°C, must be met to avoid operating the controller's processor and board components above their maximum
junction temperatures.
Table 26: Operating and Nonoperating Conditions
Adapter
Relative Humidity
Range (Noncondensing)
9560-16i 5% to 90%
9560-8i 5% to 90%
9580-8i8e 5% to 90%
9500-16i 5% to 90%
9500-8i 5% to 90%
9500-16e 5% to 90%
9500-8e 5% to 90%

Tri-Mode Storage Adapter Power Supply Requirements

All power is supplied to the tri-mode storage adapter through the PCIe 3.3V rails and the 12V rail. Onboard switching
regulator circuitry that operates from the 3.3V rails and the 12V rail provides the necessary voltages. The following states
describe the typical power consumption of the adapters.
Typical power is measured with maximum I/O traffic, typical silicon process material, and nominal voltages operating the
card at an ambient temperature of 45°C with required airflow.
The supply voltages supplied by the PCIe edge connector are 12V ± 8% and 3.3V ± 9%.

MegaRAID Tri-Mode Storage Adapter Power Supply Requirements

The following table describes the typical power consumption of the MegaRAID adapters.
Table 27: MegaRAID Tri-Mode Storage Adapter Typical Power Consumption
Power Mode
3.3V Supply
+12V Supply
Total Power
a. For adapters with a CVPM, this range applies with or without the CVPM attached.
Broadcom
Operating Conditions
Minimum
LFPM
200
200
200
150
150
150
150
Typical Power (W)
9560-16i 9560-8i
0.22 0.22
12.99 9.42
13.21 9.64
Broadcom
Nonoperating Environment
Temperature Relative Humidity
a
Range Range (Noncondensing)
0°C to +55°C
0°C to +55°C
0°C to +55°C
0°C to +55°C
0°C to +55°C
0°C to +55°C
0°C to +55°C
9580-8i8e
0.66
13.59
14.25
® ®
95xx PCIe 4.0 MegaRAID and HBA Tri-Mode Storage Adapters
Temperature
Range
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
5% to 95% –40°C to +70°C
