Table 19: LED Designations
LED Type
LED2 Yellow IOC over
temperature
LED3 Green system heartbeat
HBA 9500-8i Adapter – Connector and LED Designations
The adapter is a 6.127 in. × 2.712 in. (155.65 mm × 68.90 mm) board. The component height on the top and bottom of the
adapter complies with the PCIe specification.
The following figure shows the connectors and LED locations on the adapter. Pin 1 on the headers and connectors is
highlighted in red in the figure.
Figure 7: Card Layout of the HBA SAS 9500-8i Tri-Mode Storage Adapter
The following table describes the headers and connectors on the adapter.
Table 20: Headers and Connectors
Connector
J2 Standard edge card connector
J4 Default SBR header
J8 Onboard serial UART connector
J17 Storage interface connector
Broadcom
Stays on solid to indicate that the SAS3816 IOC temperature sensor is over the temperature
threshold. When the device is in the proper temperature range, this LED is off.
Indicates that the SAS3816 IOC is operating normally.
Type
The interface between the storage adapter and the host system.
With the PCIe interface, this connector provides power to the board and an I
interface connected to the I
2-pin connector. Reserved for Broadcom use.
4-pin connector. Reserved for Broadcom use.
One SFF-8654 8-port internal connector.
Connects the adapter by cable to the storage devices.
®
Broadcom 95xx PCIe 4.0 MegaRAID
Description
Description
2
C bus for the IPMI.
®
and HBA Tri-Mode Storage Adapters
2
C
95xx-MR-HBA-Tri-Mode-UG104
29
