Table 11: External Adapter Cable Pinout
Pin Signal
A1 No Connect
A2 CINT#
A3 GND
A4 PERp0, RX0+
A5 PERn0, RX0-
A6 GND
A7 PERp3, RX3+
A8 PERn3, RX3-
A9 GND
B1 PWR
B2 CBLPRSNT#
B3 GND
B4 PERp1, RX1+
B5 PERn1, RX1-
B6 GND
B7 PERp2, RX2+
B8 PERn2, RX2-
B9 GND
Broadcom
Pin Signal
C1 CMICLK
C2 CMIDAT
C3 GND
C4 PETp0, TX0+
C5 PETn0, TX0-
C6 GND
C7 PETp3, TX3+
C8 PETn3, TX3-
C9 GND
D1 PWR
D2 MGTPWR
D3 GND
D4 PETp1, TX1+
D5 PETn1, TX1-
D6 GND
D7 PETp2, TX2+
D8 PETn2, TX2-
D9 GND
®
