The following table describes the LEDs on the adapter.
Table 21: LED Designations
LED Type
LED 2 Yellow IOC over
temperature
LED3 Green system heartbeat
HBA 9500-16e Adapter – Connector and LED Designations
The adapter is a 6.600 in. × 2.707 in. (167.65 mm × 68.77 mm) board. The component height on the top and bottom of the
adapter complies with the PCIe specification.
The following figure shows the connectors and LED locations on the adapter. Pin 1 on the headers and connectors is
highlighted in red in the figure.
Figure 8: Card Layout of the HBA 9500-16e Storage Adapter
The following table describes the headers and connectors on the adapter.
Table 22: Connectors
Connector
J2 Standard board edge connector
J18 Storage interface connectors
J4 Default SBR header
J8 Onboard serial UART connector
The following table describes the LEDs on the adapter.
Broadcom
Stays on solid to indicate that the SAS3808 IOC temperature sensor is over the temperature
threshold. When the IOC is in the proper temperature range, this LED is off.
Indicates that the SAS3808 IOC is operating normally.
Type
PCIe x8 board edge connector.
With the PCIe interface, this connector provides power to the board and an I
interface connected to the I
Four SFF-8644 external connectors.
Connect the adapter by cable to the storage devices.
2-pin connector. Reserved for Broadcom use.
4-pin connector. Reserved for Broadcom use.
®
Broadcom 95xx PCIe 4.0 MegaRAID
Description
Description
2
C bus for the IPMI.
®
and HBA Tri-Mode Storage Adapters
2
95xx-MR-HBA-Tri-Mode-UG104
C
30
