- Page 1 IW- - - - RS104 RS104 RS104 RS104- - - - 07 U s e r M a n u a l U s e r M a n u a l U s e r M a n u a l U s e r M a n u a l...
-
Page 2: Table Of Contents
Table of Contents PREFACE ............................1 SAFETY INFORMATION ......................... 1 CAUTION ............................2 SPECIFICATIONS ..........................3 12Gb/s BACKPLANE SPECIFICATIONS .................... 5 Product Introduction ......................6 Box Contents ......................... 6 Accessories Box ......................7 General Information ...................... 8 1.3.1 Front Panel Controls and Indicators ................. 9 1.3.2 Rear Panel Configuration .................... - Page 3 Backplane Introduction ....................... 18 Compatibility Lists ......................19 Q & A ..........................20 Technical Support ........................ 21...
-
Page 4: Preface
InWin’s server website. SAFETY INFORMATION To ensure a safe and smooth operation of your InWin IW-RS104-07, it is essential that you choose an appropriate location for the system, provide an appropriate operating environment and supply an adequate amount of power for all components of the system. As you plan for installation, follow the guidelines below to ensure that the system and its environment are safely and appropriately positioned for efficient operation and service. -
Page 5: Caution
Installing or Removing Jumpers: A jumper is a short length conductor used to close, open or bypass part of an electronic circuit. Jumpers on InWin backplanes have a small tab on top that you can pick up with your fingertips. Grip the jumper carefully and plug the jumper to cover the jumper pins on the backplane. -
Page 6: Specifications
• HQ: 552pcs The actual product is subject to change without prior notice. InWin Development Inc. reserves the right to make any final modifications. The adjacent image is for reference only. All hardware components and optional parts are not included. - Page 7 Product Dimensions...
-
Page 8: 12Gb/S Backplane Specifications
12Gb/s BACKPLANE SPECIFICATIONS Slimline Backplane Backplane- - - - 1 416.6mm x 33mm Dimensions (W x H) Passive Backplane Type Mini-SAS HD (SFF-8643) x 1, Slimline (SFF-8654) x 4 Host Interface NVMe/SAS/SATA (SFF-8639) x 4 HDD Interface Oculink Backplane Backplane- - - - 2 416.6mm x 33mm Dimensions (W x H) Passive... -
Page 9: Product Introduction
1 Product Introduction Box Contents When you open the IW-RS104-07 box, the contents should include following:... -
Page 10: Accessories Box
Accessories Box Item Item Accessories Box Solderable Standoffs x 2 Label x 1 6 + 7-pin SATA to SATA Device x 1 Power LED 3-pin to 2-pin Adapter x 1 2.5" SSD screws x 24 Cable Ties and Mounts x 5 Backplane Jumper x 1 Single Power Supply Accessories a. -
Page 11: General Information
General Information When you open the chassis, it should reflect the diagram’s image. -
Page 12: Front Panel Controls And Indicators
1.3.1 Front Panel Controls and Indicators The IW-RS104-07 supports 2.5"/3.5"SAS/SATA disk bays x 4 or 2.5"/3.5" NVMe disk bays x 4 in specific areas. The control panel, USB I/O ports and indicators are located on the handles. ❷ ❺ ❶... -
Page 13: Rear Panel Configuration
Power Supply Window compatibility list to select the compatible models. System I/O (Depends on InWin offers a customized service for 1U I/O shield. For more M/B Specifications) information, please contact InWin’s sales reps. The slot supports standard high profile cards. The bracket should Full-Height PCIe Slot x 1 be removed before using. -
Page 14: Hardware Installation
07 Series Motherboard & Expansion Card Installation. HDD Tray Installation The IW-RS104-07 features tool-less trays. Users no longer need to use screws to mount disks, and can swap drives faster. For a quick installation video, please visit 07 Series HDD Tray Installation. -
Page 15: Power Supply Cable Information
2.5.1 Power Supply Cable Information 650W Single PSU Cable Information Length Unit: mm... - Page 16 750W Redundant PSU Cable Information Length Unit: mm...
-
Page 17: Internal Hdd Installation
2.6 Internal HDD Installation The IW-RS104-07 offers 3 x 2.5" internal SSD drive bays, and one of the 2.5" internal SSD drive bays can be replaced with an ODD. These drive bays can be mixed by customers into several combinations. -
Page 18: Installing The Slide Rail
2.8 Installing the Slide Rail The InWin IW-RS104-07 is a rackmount model, which supports EIA-RS310D standard cabinet and chassis racks. InWin provides standard slide rails to allow customers to mount the chassis onto the cabinet. 2.8.1 Identifying the Slide Rail The slide rail by your order might be different. -
Page 19: Mounting The Chassis Onto The Cabinet
Step 2: Mount the inner rails onto the chassis by the direction which the arrows show. Step 3: Install the outer rails and the brackets onto the rack. 2.8.3 Mounting the chassis onto the cabinet Step 1: Make sure the ball bearing retainer is at the forefront. Step 2: Insert the inner rail to the outer rail which has already locked up on the cabinet. - Page 20 Step 3: Mount the inner rail onto the chassis by the direction which the arrows show on the image. Step 4: Tighten the thumb screws to secure the chassis.
- Page 21 Backplane Introduction The backplane varies by order. Please reference the backplane user guide to complete the installation. The download link is at the download section of each product. Please visit the InWin website: ipc.in-win.com. SAS3 Backplane: Top Side Bottom Side...
- Page 22 To reach the best performance and avoid system failure, InWin strongly recommends customers to choose the components from InWin’s compatibility list. All the components are tested in InWin’s lab, and assured the components are compatible with InWin’s chassis. You can...
- Page 23 If I don’t need the front cover, can I have the standard handle? A: The InWin IW-RS104-07 supports both the standard handle and the bezel handle. If you would like your chassis with a standard metal handle, please contact your local reps to purchase the bezel package for replacement.
- Page 24 You can buy the verified cable from InWin to eliminate compatibility issues. 6 Technical Support If you need help with installation or troubleshooting, you can contact your local InWin sales reps, or send an e-mail to InWin’s local contacts for technical assistance.
