Summary of Contents for InWin infinite IW-CS-INFINITE
- Page 1 User Manual...
- Page 2 Product Video Information Product Video Information Infinite Product Video Infinite Unboxing Guide Video Infinite Installation Video...
- Page 3 A Significant Stride in the Computing Arts InWin’s 11th-generation signature chassis, Infinite, embodies the concept of infinite possibilities. InWin has achieved significant breakthroughs in glass art and craftsmanship. The 180-degree curved glass embraces an aluminium shell to create balance and symmetry, a PC industry-first.
-
Page 4: Specifications
1131 x 546 x 1086 mm (L x W x H) (44.53 x 21.5 x 42.76") Net Weight 47 kg / 103.61 lbs Gross Weight 100 kg / 220.46 lbs * InWin's products comply with RoHS regulations. * Specifications may vary based on different regions. -
Page 5: Package Contents
Package Contents Package Contents Infinite Chassis x 1 Accessories Box 1. PSU Bracket x 1 2. Accessories Bag: a. Hexagon Head Screws x 22 b. M/B Stand-offs x 10 d. 2.5” SSD Screws x 4 c. Stand-off Socket x 1 f. - Page 6 Case Structure Case Structure Power Button USB 3.2 Gen 1 USB 3.2 Gen 2x2 Type-C HD Audio Combo (CTIA – SPK/Mic) Chassis Action Button (Open / Close) Lighting Effect Button 180-Degree Curved Glass Magnetic Side Panel Ultra-Rare Limited Edition Serial Number Sand Casted Aluminium Base...
- Page 7 Case Structure Case Structure Motherboard Mounting Area 2.5” SSD Mounting Area Power Supply Mounting Area Front Fans/ Radiator Mounting Area Rear Fan Mounting Area PCI-E Expansion Slots...
-
Page 8: Connection Cables
Connection Cables Connection Cables I/O Wires Black(P_LED) 1 2 Black (HDD) Black(P_LED) 3 4 Black (HDD) Black(P_SW) 5 6 NC Black(P_SW) 7 8 NC Key 9 10 NC HD Audio Header PORT2_L BLUE PURPLE PORT2_R YELLOW WHITE PORT1_R PORT1_L BLACK USB 3.2 Gen 1 USB 3.2 Gen 2x2 Type-C... - Page 9 Operation Instructions Operation Instructions - Open: In Infinite’s default closed position, hold down “ ” for 3 seconds to open the chassis to the expanded position. - Close: In Infinite’s expanded state, hold down “ ” for 3 seconds to close the chassis to the default position.
- Page 10 Lighting Effect Instructions Lighting Effect Instructions - Press " " to browse through lighting modes. - Press “ ” twice to return to the previous lighting mode. - Hold down “ ” for 2 seconds to turn the lighting ON/OFF. Lighting Modes LED –...
- Page 11 14. For more technical support, please visit the InWin Forum at https://forum.in-win.com/ ■ Warranty 1. For more detailed warranty information, please visit the InWin retail website at www.in-win.com 2. The actual product is subject to change without prior notice. In Win Development Inc. reserves the right to make any final modifications.
- Page 12 Copyright © 2024 In Win Development Inc. All Rights Reserved.
