    Table of Contents PREFACE ............................1 SAFETY INFORMATION ......................... 1 CAUTION ............................2 SPECIFICATIONS ..........................3 12Gb/s BACKPLANE SPECIFICATIONS .................... 4 Product Introduction ......................5 Box Contents ......................... 5 Accessories Box ......................6 General Information ...................... 7 1.3.1 Front Panel Controls and Indicators ................. 8 1.3.2 Rear Panel Configuration ....................
  • Page 3 Compatibility Lists ......................18 Q & A ..........................19 Technical Support ........................ 20...
  • Page 4: Preface

    InWin’s server website. SAFETY INFORMATION To ensure a safe and smooth operation of your InWin IW-RS110-07, it is essential that you choose an appropriate location for the system, provide an appropriate operating environment and supply an adequate amount of power for all components of the system. As you plan for installation, follow the guidelines below to ensure that the system and its environment are safely and appropriately positioned for efficient operation and service.
  • Page 5: Caution

    Installing or Removing Jumpers: A jumper is a short length conductor used to close, open or bypass part of an electronic circuit. Jumpers on InWin backplanes have a small tab on top that you can pick up with your fingertips. Grip the jumper carefully and plug the jumper to cover the jumper pins on the backplane.
  • Page 6: Specifications

    • HQ: 552pcs The actual product is subject to change without prior notice. InWin Development Inc. reserves the right to make any final modifications. The adjacent image is for reference only. All hardware components and optional parts are not included.
  • Page 7: 12Gb/S Backplane Specifications

    Product Dimensions 12Gb/s BACKPLANE SPECIFICATIONS Slimline Backplane Backplane- - - - 1 400mm x 37.3mm Dimensions (W x H) Passive Backplane Type Slimline (internal SFF-8654 x 10, for PCIe protocol) + 8643 x 3 for SAS Host Interface protocol 8639 x 10 (for NVMe/SAS/SATA device) HDD Interface Oculink Backplane Backplane- - - - 2...
  • Page 8: Product Introduction

    1 Product Introduction Box Contents When you open the IW-RS110-07 box, the contents should include following:...
  • Page 9: Accessories Box

    Accessories Box Name Name Accessories Box Motherboard Stand-off Sockets x 11 Label x 1 Solderable Standoffs x 2 Power LED 3-pin to 2-pin Adapter x 1 Backplane Jumper x 1 Redundant Power Supply Accessories Cable Ties and Mounts x 5 a.
  • Page 10: General Information

    General Information When you open the chassis, it should reflect the diagram’s image.
  • Page 11: Front Panel Controls And Indicators

    1.3.1 Front Panel Controls and Indicators The IW-RS110-07 supports 2.5" SAS/SATA disk bays x 10 or 2.5" NVMe disk bays x 10. The control panel, USB I/O ports and indicators are located on the handles. ❷ ❶ ❸ ❹ ❺...
  • Page 12: Rear Panel Configuration

    Power Supply Window compatibility list to select the compatible models. System I/O (Depends on InWin offers a customized service for 1U I/O shield. For more M/B Specifications) information, please contact InWin’s sales reps. The slot supports standard high profile cards. The bracket should be Full-Height PCIe Slot x 1 removed before using.
  • Page 13: Hardware Installation

    07 Series Motherboard & Expansion Card Installation. HDD Tray Installation The IW-RS110-07 features tool-less trays. Users no longer need to use screws to mount disks, and can swap drives faster. For a quick installation video, please visit 07 Series HDD Tray Installation.
  • Page 14 650W Single PSU Cable Information Length Unit: mm...
  • Page 15 750W Redundant PSU Cable Information Length Unit: mm...
  • Page 16: Connecting Cables

    NVMe SSDs through either Oculink x 10 or Slimline x 10 connectors. 2.5.1 Connecting Backplane Through SAS Connectors The InWin IW-RS110-07 needs the SAS cable to connect to the backplane and your motherboard or RAID controller. InWin provides verified SAS cables for installation, please contact InWin local partners and sales to get more information.
  • Page 17: Installing The Slide Rail

    2.6 Installing the Slide Rail The InWin IW-RS110-07 is a rackmount model, which supports EIA-RS310D standard cabinet and chassis racks. InWin provides standard slide rails to allow users to mount the chassis onto the cabinet. 2.6.1 Identifying the Slide Rail The slide rail by your order might be different.
  • Page 18: Mounting The Chassis Onto The Cabinet

    Step 2: Mount the inner rails onto the chassis by the direction which the arrows show. Step 3: Install the outer rails and the brackets onto the rack. 2.6.3 Mounting the chassis onto the cabinet Step 1: Make sure the ball bearing retainer is at the forefront. Step 2: Insert the inner rail to the outer rail which has already locked up on the cabinet.
  • Page 19 Step 3: Mount the inner rail onto the chassis by the direction which the arrows show on the image. Step 4: Tighten the thumb screws to secure the chassis.
  • Page 20: Backplane Introduction

    3 Backplane Introduction The backplane varies by order. Please reference the backplane user guide to complete the installation. The download link is at the download section of each product. Please visit the InWin website: ipc.in-win.com. Oculink Backplane: Top Side Bottom Side...
  • Page 21 To reach the best performance and avoid system failure, InWin strongly recommends customers to choose the components from InWin’s compatibility list. All the components are tested in InWin’s lab, and assured the components are compatible with InWin’s chassis. You can...
  • Page 22 If I don’t need the front cover, can I have the standard handle? A: The InWin IW-RS110-07 supports both the standard handle and the bezel handle. If you would like your chassis with a standard metal handle, please contact your local sales reps to purchase the bezel package.
  • Page 23 Where can I buy the SAS cable? A: The 12Gb SAS to 4 SATA or 12Gb SAS to 6Gb SAS are standard cables that you can easily buy from many vendors. You can buy the verified cable from InWin to eliminate compatibility issues.
