Huvitz Excelon CAB-4000 Operator's Manual page 43

• The value of the edging options affects the final output as followings :
• Like the above picture, if the operator use ratio(%) mode from the Front side
about a so thin lens, the machining of the thinnest part could be dangerous.
1.6mm
• Using the distance(mm) mode from the front side, you can set the specific
distance, However, if the thickness of the thin area is less than the double of the
designated value, the machine internally forces it to be machined by the 50% of
the thickness at the thin position.
Excelon Operator's Manual
Operation Tips
50%
[ Ratio(%) mode
from the front side ]
50%
[ Distance(mm) mode
from the front side ]
1.6mm
43
