Confirming Adapter Installation
If you are installing the 3C592 EISA adapter in a computer
running Windows 95, you can confirm the adapter's
installation by following these steps:
1 After starting Windows 95, double-click the My Computer
icon.
2 Double-click the Control Panel icon.
3 Double-click the System icon.
The System Properties box appears, detailing your system
setup.
4 Click the Device Manager tab.
A list of devices appears, arranged by type.
5 Click the Network Adapters tab.
The name of the installed 3Com adapter appears, as shown
below:
3Com EtherLink III Bus-Master EISA Ethernet
Adapter
This confirms the adapter's installation.
6 Double-click the adapter's name to display a description
of the adapter and its current status.
The next dialog box confirms that the adapter is working
properly.
7 Click the Cancel button to leave each dialog box and
return to the Control Panel.
For on-line help information about any of the fields in the
display boxes, click the question mark (?) in the upper right
corner of the box and move the question mark cursor to the
field of interest and click again.
