Part List - Pro-Form PFIVEL63212.0 User Manual

PART LIST—Model No. PFIVEL63212.0
Item Description
1 Main frame
2 Handlebar post
3 Pedal tube
4 Swing tube
5 Handle tube
6 Fixed handlebar
7 Front stabilizer
8 Rear stabilizer
9 Pedal
10 Computer
11 Carriage bolt M8×74
12 Arc washer
13 Acorn nut M8
14 Inner hex pan-head screw M8x40
15 Bolt M8x20
16 Carriage bolt M8×45
17 Pedal tube joint
18 Arc washer D5
19 Cross pan-head screw M5X55
20 Big washer
21 Hex bolt M8x15
22 Round end cap
23 Hex bolt M8x45
24 Flat washer d8x1.2
25 Nylon nut M8
26 Hex bolt M8x75
27 Washer
28 Nylon nut M10×1.25
29 End cap S17
30 Extension wire
31 Sensor wire
32 Flat washer
33 Screw
34 Screw 4.2×18
35 End cap S14
36 Pulse sensor wire
37 Rolling end cap
38 Adjustable end cap
39 Foam grip
40 Mushroom end cap
41 Fixed handlebar foam grip
42 Plastic spacer
Qty. Item Description
1 43 Sleeve 26.8×28
1 44 Sleeve 26.8×20
1each 45 Flat washer D10
1each 46 Alloy bushing
1each 47 Chain cover
1 48 Rotating disk
1 49 spacer 32×26
1 50 cross pan tapping screw 4.8×20
1each 51 Flywheel
1 52 Flywheel axle
4 53 Bearing
20 54 Axle sleeve
12 55 Thin nut M10X1
4 56 Bolt
4 57 Flange nut M10×1.25
4 58 cross pan tapping screw 2.9×12
2 59 Bolt M6x16
1 60 Axle
1 61 Nylon nut
2 62 Belt
4 63 Belt tray
2 64 Magnet
4 65 Bearing 6203RS
6 66 Spring washer
6 67 Hex nut M6x55
2 68 Hex nut M6
2 69 spring
2 70 Bushing
6 71 Magnet plate axle
1 72 Spring washer d8
1 73 Spring washer
2 74 Spring washer d6
2 75 Nylon nut M10
6 76 end cap S13
4 77 cross pan tapping screw 4.2×20
2 78 Cross bar
2 79 Rotating disk cap
2 80 Hex bolt M10x55
2 81 Adapter 230V / 6V,500mA
2 82 Motor
1 83 Main Adapter
2
15
Qty.
8
4
2
4
1each
2
2
11
1
1
2
1
3
2
2
2
4
1
4
1
1
1
2
2
1
1
1
2
1
2
2
4
2
2
8
2
2
2
1
1
1
