Electronic Scoreboard - Lifetime 90056 Owner's Manual

1
BACKBOARD TO RIM ASSEMBLY
Hardware shown at Actual Size
(x8)
3/8" x 1" Button Head Cap Screw
AAP (x8)
#6 x 3/8" Phillips
Pan Head Screw
Parts shown at 10% of Actual Size
ALX (x2)
Rim
BLQ (x1)

Electronic Scoreboard

HARDWARE REQUIRED
BNZ (x4)
15mm M5 Screw
PARTS REQUIRED
AKZ (x2)
Net
TOOLS REQUIRED
10
(x8)
3/8" Washer
BOA (x4)
M5 Nylock Nut
Part shown at 5% of Actual Size
Backboard
(x8)
3/8" Cap Nut
