Technical data
®
NAUTILUS
CC plus
Height max..................................................480 mm
Width...........................................................606 mm
Depth ..........................................................676 mm
Weight .............................................................64 kg
Nominal voltage ..........230 V AC ±10 %, 50 / 60 Hz
Nominal output....................... 3680 VA (Eco 10 VA)
short-time operation ............................... max. 5 min
Compressed air.............................. 1/4 ", 5 .... 8 bar
(0.5 .... 0.8 MPa), (72.5 .... 116 psi),
Noise emission...................................... < 70 dB (A)
Ambient temperature (max.) .................. 10... 30 °C
230 V AC ±10 %, 50 / 60 Hz, 3680 VA.. REF 26475
English ⋅ Nautilus
NAUTILUS
Height ......................................................... 418 mm
Width .......................................................... 606 mm
Depth.......................................................... 676 mm
Weight .............................................................63 kg
Nominal voltage ......... 230 V AC ±10 %, 50 / 60 Hz
Nominal output ....................... 3680 VA (Eco 10 VA)
short-time operation ...............................max. 5 min
Compressed air .............................. 1/4 ", 5 .... 8 bar
≥ 100 l / min
Noise emission ...................................... < 70 dB (A)
Ambient temperature (max.) ..................10... 30 °C
(50...86 °F)
230 V AC ±10 %, 50 / 60 Hz, 3680 VA.. REF 26470
®
CC plus ⋅ Nautilus
®
T
(0.5 .... 0.8 MPa), (72.5 .... 116 psi),
®
T
en
≥ 100 l / min
(50...86 °F)
15
