Installing the LightMaster Multifunction Switch
7.
Connect two wires from the nurse call to the bottom
terminal block in the keypad in order to operate two
functions through the pillow speaker. (Optional)
NOTE: The nurse call should be connected to only one
keypad in the room.
8.
Once powered the keypads should communicate with
each other as shown below. After installing the keypad,
check all functions work properly.
www.amico.com
9
