Mounting Drawings

# 6 screws can be used to mount the Light Master controller and keypad.
10
Amico Lighting Solutions
6.63"
6.24"
LightMaster Controller
3.82"
3.43"
Security Power Unit
Ø0.17"
Ø0.17"
