Table of Contents

I.
INTRODUCTION
II.
FEATURES
III.
IV.
V.
VI.
VII.
VIII.
IX.
RS-232 FORMAT
I. INTRODUCTION
Thank you for your purchase of JADEVER high precision electronic weighing scale, which enables
you to measure both quantity and weight. The scale is easy to operate, precise, stable and with fast
display reaction. It is applicable in the electronic, hardware, plastic, medicine, textile and various other
industries. It is useful for packaging, inventory and various production and quality control cases. It will
help you save your time, labor, money, and reduce material waste, lower cost, improve your work
efficiency, thus to achieve maximum return on investment.
II. FEATURES
1. The microprocessor in this scale features
(1) Zero point tracking function.
(2) Tare and pre-tare function.
2. Easy operating and water-resistant membrane keypad.
3. Easy to read LCD display.
4. Counting function is applicable, with backlight function.
5. Tare range is unlimited.
6. The case shell is made of ABS shockproof plastics; stainless steel weighing pan is used for
long-term operation.
Page 1

TABLE OF CONTENTS

---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
---------------------------------
WEIGHING SCALE
1
1
2
3
3
4
6
6
6
7
7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LPWN-1530 and is the answer not in the manual?

Questions and answers

Related Manuals for Jadever LPWN-1530

Summary of Contents for Jadever LPWN-1530

  • Page 1: Table Of Contents

    --------------------------------- I. INTRODUCTION Thank you for your purchase of JADEVER high precision electronic weighing scale, which enables you to measure both quantity and weight. The scale is easy to operate, precise, stable and with fast display reaction. It is applicable in the electronic, hardware, plastic, medicine, textile and various other industries.

  • Page 2: Assembly

    III. ASSEMBLY A. Models LPWN-1530、 LPWN-7515、LPWN-1530K 1. Remove the protection copper screw [2], and then screw out the protection copper screw [1]; 2. Align the three-hole aluminum column [6] and center of the three round holes on the scale support [5] with the corresponding hole on the “-”shaped iron piece inside hole [7]. Then fix the three-hole aluminum column [6] and scale support [5] on the “-”shaped iron piece of the...

  • Page 3: Precautions

    D. Wind Shield Note: Always reinstall the transportation protection device before transporting the scale, lest the precision sensor should be damaged due to bumping and falling during transportation. IV. PRECAUTIONS Full charge the battery after unpacking the scale. Recharge the battery: When battery symbol appears on the LCD display, charge the battery with AC power cord plug in, the indicator of charge will light up in red;...

  • Page 4: Function Setting

    Cross reference list of keys in Chinese and English 單位 中文 扣重 歸零 開關 列印 轉換 O N / ENGLISH ZERO PRINT MODE TARE O FF VI. FUNCTION SETTING LCD Display Function Selection Reference Model display Page 4, Item 1 ↓...

  • Page 5: Operation

    4. Press MODE key once again, the LCD display will show , which means the scale enters into filter setting mode; press down TARE , the display will show Fil 2 , press TARE key again to switch the filter degree as 1, 2, 3 or 4. Level 4: Reaction is slower, effect on filtering is higher. 5.

  • Page 6: Weighing Unit Conversion

    WEIGHING UNIT CONVERSION VIII. 1 kg = 1000 g 1 斤 500g 1 HK jin 16 HK ounce 1 HK ounce 37.799375g 1 Taiwan ounce = 37.49995g 1 Taiwan jin = 16 Taiwan ounce 1 lb 453.59237g 1 oz 28.3495231g IX.

  • Page 7: Appendix 2

    2. Troubleshooting When Err. Msg. Troubleshooting Err2 Check and remove any object from weighing pan or malfunction of LOAD CELL Power on Power on Err3 Check if A/D or LOAD CELL malfunctions Power on Err4 Beep alert. Switch power off and power on again, or perform calibration Power on Battery symbol Charge the battery with power on...
  • Page 8 ： weight Example: N.W. ：+2.508lb T.W. ：+ 0.040lb G.W. ：+2.548lb 4. lb-oz ： weight lb Weight oz Example: N.W. ：+2lb 8.12oz T.W. ：+ 0lb 0.64oz G.W. ：+2lb 8.76oz 5. Jin ： weight Example: N.W. ：+2.275jin T.W. ：+ 0.037jin G.W. ：+2.312jin 6.
  • Page 9 Example: Total：+ 0 pcs 9. % Example: + 0 % G = GROSS N = NET T = TARE Printer and output format (example: kg) SH-24 EZ2-S N.W.:+1.6025 kg N.W.:+ 1.1375 kg T.W.:+0.0000 kg T.W.:+ 0.0180 kg G.W.:+1.6025 kg G.W.:+ 1.1555 kg Signal Output RS-232 Connector/ WEIGHING SCALE...

This manual is also suitable for:

Lpwn-7515Lpwn-1530kLpwn-3075Lpwn-150
