Danfoss VLT 4000 ME Manual page 9

■ Line supply 3 x 380 - 460 V
According to international requirements
1. For type of fuse, see section Fuses.
2. American Wire Gauge.
3. Measured using 100 ft screened motor cables at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Max. cable cross section is the
maximum possible cable cross section that can be fitted on the terminals.
Always comply with national and local regulations on min. cable cross-section.
5. Connection bolt 1 x M10 / 2 x M10 (mains and motor), connection bolt 1 x M8 / 2 x M8 (DC-bus).
MG.40.A4.22 - VLT is a registered Danfoss trademark
Output
I [A] (380-440 V)
VLT,N
current
I (60 s) [A] (380-440 V)
VLT, MAX
I [A] (441-460 V)
VLT,N
I (60 s) [A] (441-460 V)
VLT, MAX
Output
S [kVA] (400 V)
VLT,N
power
S [kVA] (460 V)
VLT,N
Typical shaft output (400 V) P
VLT,N
Typical shaft output (460 V) P
VLT,N
Max. cable cross-section to motor and
2 2) 4) 5)
DC-bus [mm ]
Max. cable cross-section to motor and
2) 4) 5)
DC-bus [AWG]
Min. cable cross-section to motor and
2 2) 4) 5)
DC-bus [mm /AWG]
Max. input
I [A] (380 V)
L,N
current
(RMS) I [A] (460 V)
L,N
Max. cable cross-section to power [mm
4) 5)
Max. cable cross-section to power [AWG]
4) 5)
Max. pre-
1)
[-]/UL [A]
fuses
Weight
[lbs]
Chassis
Weight
[lbs]
NEMA 1
Weight
[lbs]
NEMA 12
Efficiency at rated frequency
Power loss
at max. [W]
load.
Enclosure
VLT® 4000 VT
VLT type 4152 4202
212 260
233 286
190 240
209 264
147 180
151 191
[kW] 110 132
[HP] 150 200
2x185 2x185
2x350 2x350
mcm mcm
35/2 35/2
208 256
185 236
2 2)
]
2x185 2x185
2)
2x350 2x350
mcm mcm
300/300 350/350
195 195
210 210
210 210
0.98
2619 3309
Chassis/NEMA 1/NEMA 12
4252 4302 4352
315 395 480
347 435 528
302 361 443
332 397 487
218 274 333
241 288 353
160 200 250
250 300 350
2x185 2x185 2x185
2x350 2x350 2x350
mcm mcm mcm
35/2 35/2 35/2
317 385 467
304 356 431
2x185 2x185 2x185
2x350 2x350 2x350
mcm mcm mcm
450/400 500/500 630/600
295 295 295
314 314 314
314 314 314
4163 4977 6107
21
