■ Line supply 3 x 380 - 460 V
According to international requirements
Output current
Output
Typical shaft output
Typical shaft output
Max. cable cross-section
to motor and DC-bus
Min. cable. cross-section
to motor and DC-bus
Max. input current
(RMS)
Max. cable, cross-section,
power
Max. line-fuses
Efficiency at rated frequency
Weight NEMA 1
Weight NEMA 12
Power loss at max. load.:
Enclosure
1. See section Fuses.
2. American Wire Gauge
3. Measured using 100 feet shielded motor cable at rated load and rated frequency.
4. Min. cable cross-section is the smallest cable cross-section allowed to be fitted on the terminals. Always comply with national and local regulations on
min. cable cross-section.
MG.40.A4.22 - VLT is a registered Danfoss trademark
VLT® 4000 VT
VLT type
I [A] (380-440 V)
VLT,N
I (60 s) [A]
VLT, MAX
(380-440 V)
I [A] (441-460 V)
VLT,N
I (441-460 V)
VLT, MAX
S [kVA] (400 V)
VLT,N
S [kVA] (460 V)
VLT,N
P [kW]
VLT,N
P [HP]
VLT,N
2
[mm ]/[AWG]
4) 2
[mm ]/[AWG]
I [A] (380 V)
L,N
I [A] (460 V)
L,N
2
[mm ]/[AWG]
1)
[A]/UL [A]
[lbs]
[lbs]
W
4016 4022 4027
24.0 32.0 37.5
26.4 35.2 41.3
21.0 27.0 34.0
23.1 29.7 37.4
17.3 23.0 27.0
16.7 21.5 27.1
11 15 18.5
15 20 25
2)
16/6 16/6 16/6
2)
10/8 10/8 10/8
24.0 32.0 37.5
21.0 27.6 34.0
2)
16/6 16/6 16/6
63/40 63/40 63/50
0.96
21 46 46
28 96 96
419 559 655
NEMA 1/NEMA 12
4032 4042
44.0 61.0
48.4 67.1
40.0 52.0
44.0 57.2
31.6 43.8
31.9 41.4
22 30
30 40
16/6 35/2
10/8 10/8
44.0 60.0
41.0 53.0
16/6 35/2
63/60 80/80
60 60
102 122
768 1065
19
