MENU NAVIGATION
Blue
Go to next unit
key
Active energy, active power etc .
Red
More information of unit
key
E . g . phase L1, L2, L3, total, Min . / Max values
Yellow
Service key, on the right side bellow the red terminal cover .
key
To save a configuration, push the service key for 5 seconds.
COMMISSIONING / CHECK-UP
To check for operation:
Phase rotation
Current per phase
Negative energy direction
Sequence of phase (L1 L2 L3)
For meter with CT's:
- Current Transformer ratio
- If present: remove the short circuit on the current transformer
Terminal tightening torque
Read-out interface: Correct address
Neutral conductor connected
