Error code description

ChkEr
Four-Digit Error Code Display
0 0 0 0
Fourth Digit in Error Code in PASCAL CV Display Module
0 No error.
Pressure outside nominal measuring range.
1
2 Temperature outside specified range.
3 Pressure outside nominal measuring range and temperature outside specified range.
Analog output limited to current value.
4
5 Pressure outside nominal measuring range and analog output limited to current value.
6 Temperature outside specified range and analog output limited to current value.
Pressure outside nominal measuring range; temperature outside specified range;
7
and analog output limited to current value.
Third Digit in Error Code in PASCAL CV Display Module
0 No error.
8
General device error (always shown with other errors)
Second Digit in Error Code in PASCAL CV Display Module
0
No error.
2 A memory cell in the microprocessor is faulty.
First Digit in Error Code in PASCAL CV Display Module
0 No error.
1 Data in sensor module invalid.
2
Data in basic module invalid.
3 Data in sensor and basic module invalid or do not match.
4 Connected sensor not detected by basic module.
8
Measuring bridge / pressure sensor faulty.
Digits on a gray background indicate errors that can only be remedied by the manufacturer.
All other issues can be remedied by the customer.
Operating Instruction BA_029_2019-08_10.00 Pressure transmitter PASCAL CV
Error in sensor module or this basic module cannot
access the sensor.
The sensor module has been replaced or there is an error
in the basic module.
Error in sensor module (compensation table/ set-up data)
