The Intelix INT-HD70-TXWP extends HDMI, IR, and RS232 over a single solid core shielded Category 5e
or greater cable using the Valens VS010TX HDBaseT chip. The INT-HD70-TXWP supports 1080p video
signal up to 70m and 4K signals up to 4K@60Hz / 4:2:0 / 8 bit color up to 40m. The INT-HD70-TXWP
supports CEC pass through and is HDCP 2.2 compliant. 48V PoH built in allows the transmitter to be
powered from a compatible Intelix receiver, the transmitter also has 12V DC output for powering 3rd
party device nearby.
The INT-HD70-TXWP is compatible with all Intelix HDBaseT product offerings and any product that
meets the HDBaseT specifications.
• INT-HD70-TXWP HDBaseT Wall Plate Transmitter
• Quick Install Guide
• (3) 2 pin Phoenix connector
• (1) 3 pin Phoenix connector
• (2) Mounting Screws
Product Overview
Package Contents
INT-HD70-TXWP Quick Guide
3
