PARTS LIST
ITEM
QTY
REFERENCE
Required Circuit Components
1
1
C1
2
1
C2
3
1
C3
4
2
C4, C5
5
1
C6
6
1
C8
7
1
C9
8
1
C10
9
2
C11, C16
10
1
C13
11
1
C14
12
1
C17
13
1
D1
14
2
D2, D6
15
2
D3, D7
16
2
D4, D8
17
1
D5
18
1
D9
19
3
D11, D12, D13
20
1
ISO1
21
1
ISO2
22
1
L1
23
1
Q1
24
1
Q2
25
1
R1
26
2
R2, R3
27
1
R4
28
1
R5
29
1
R6
30
1
R7
31
1
R8
32
1
R9
33
1
R10
34
1
R11
35
1
R12
36
1
R13
37
1
R14
38
1
R15
39
1
R16
40
1
R19
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
DEMO MANUAL DC1145B
PART DESCRIPTION
Cap., Elec. 4.7μF 63V 20%
Cap., NPO 680pF 50V 10% 0805
Cap., X5R 0.1μF 100V 20% 1206
Cap., Tant. 47μF 20V 20% 7343
Cap., X5R 10μF 16V 20% 1206
Cap., X5R 4.7μF 16V 20% 0805
Cap., X7R 1μF 100V 20% 1210
Cap., X7R 0.01μF 25V 10% 0805
Cap., X7R 0.01μF 25V 10% 0603
Cap., X7R 0.033μF 50V 20% 0603
Cap., X7R 2200pF 250V 10% 1812
Cap., X7R 0.47μF 16V 20% 0805
Diode, Schottky 3A 60V PowerDi5
Rect Bridge GP 100V/0.8A PbF
Diode, High Speed
Diode, Zener 8.2V 200MW SOD-323
Diode, Schottky 2A 20V SMA
Voltage Supressor, 58V
Diode, SWITCH 75V 200MW SOD323
Opto Iso., NEC High Ctr. PbF
Opto Iso., 4PIN MFLAT SINGLE DC HIGH V COUPLER NEC, PS2913-1-K-A
Inductor, 8.2μH DO1608C
XSTR, High Voltage PbF SOT23
MOSFET, N-Chan., 200V SUPERSOT(6LEADS)
Res., Chip 13 0.1W 5% 0805
Res., Chip 220k 0.1W 5% 0805
Res., Chip 150 0.1W 5% 0603
Res., Chip 10k 0.1W 5% 0603
Res 0.05 OHM 1/4W 1% 1206 SMD
Res, Chip 45.3 0.06W 1% 0603
Res., Chip 1k 0.06W 5% 0603
Res., Chip 7.5k 0.1W 5% 0603
Res., Chip 402 0.1W 1% 0603
Res., Chip 6.8K 0.1W 5% 0603
Res., Chip 107k 0.1W 1% 0603
Res., Chip 200k 0.1W 5% 0603
Res., Chip 61.9k 0.06W 1% 0603
Res., Chip 28.0k 0.1W 1% 0603
Res., Chip 100k 0.1W 5% 0603
Res., Chip 300k 0.1W 5% 0603
MANUFACTURER/PART NUMBER
PANASONIC, EEEFK1J4R7R
AVX, 08055A681KAT2A
Taiyo Yuden, HMK316BJ104ML-T
Kemet, T495D476K020ATE100
Taiyo Yuden, EMK316BJ106ML
Taiyo Yuden, EMK212BJ475MG
TDK, C3225X7R2A105M
Kemet, C0805C103K3RACTU
Kemet, C0603C103K3RACTU
AVX, 06035C333MAT2A
Murata, GA343QR7GD222KW01L
AVX, 0805YC474KAT2A
Diodes Inc., PDS360-13
Diodes Inc., HD01-T
Philips Semi., BAS516
Diodes Inc., MMSZ5237BS-7-F
Diodes Inc., B220A-13-F
Diodes Inc., SMAJ58A-13-F
Diodes Inc., 1N4148WS-7-F
NEC, PS2911-1-K-A
COILCRAFT, DO1608C-822ML
ON Semi., MMBTA42LT1G
Fairchild Semi., FDC2612
Vishay CRCW080513R0JNEA
Vishay, CRCW0805220KJNEA
Vishay, CRCW0603150RJNEA
Vishay, CRCW060310K0JNEA
Vishay, WSL1206R0500FEA
Vishay, CRCW060345R3FKEA
Vishay, CRCW06031K00JNEA
Vishay, CRCW06037K50JNEA
Vishay, CRCW0603402RFKEA
Vishay, CRCW06036K80JNEA
Vishay, CRCW0603107KFKEA
Vishay, CRCW0603200KJNEA
Vishay CRCW060361K9FKEA
Vishay, CRCW060328K0FKEA
Vishay, CRCW0603100KJNEA
Vishay, CRCW0603300KJNEA
