Ricoh SWALLOW 2 Service Manual page 76

13 October 1997
4. Cleaning Unit
(every 120 k)
5. Development Unit
(every 240 k)
6. Paper Feed (every
120 k for each paper
feed station)
Replace pick-up,
feed and separation
rollers for each
paper feed station,
by-pass feed, and
the LCT
(every 240 k).
A214 only:
Replace the
separation torque
limiter for the
by-pass feed
station
(every 240 k).
PREVENTIVE MAINTENANCE SCHEDULE
1. Clean the inside of the cleaning unit and the
seals.
2. Replace the cleaning blade.
1. Remove the old developer.
2. Clean the development unit and seals.
3. Clean around the openings of the toner supply
unit with a blower brush.
4. Pour in a pack of new developer.
5. Replace the development filter.
1. Clean the paper guide plate.
2. Clean the paper feed, pick-up, separation, and
relay rollers for each paper feed station,
by-pass feed, and the LCT.
3. Replace the bottom plate pad for each paper
feed station, by-pass feed, and the LCT.
4. Clean the registration rollers.
73
