Ricoh SWALLOW 2 Service Manual page 66

13 October 1997
Mode No.
Total Jam
Counter †
°7-501 (Copies +
Originals)
Total Jams by
Paper Size †
(Note: This is
actually the
Total Copy
°7-502
Paper Jam
Counter. The
counter is not
divided up by
Paper Size)
Total Original
Jam Counter
°7-503
Total Jams by
Location †
°7-504-001
to
7-504-006
Total Original
Jams by
°7-505-001 Location †
to
7-505-002
Function
Displays the total number of copy jams
plus original jams (max. 4 digits).
The first digit is displayed in the
reduce/enlarge indicator. Hold down the
" " key to display the last three digits.
•
Displays the total copy paper jam
counter (max. 4 digits).
The first digit is displayed in the
reduce/enlarge indicator. Hold down the
" " key to display the last three digits.
•
Displays the total original jam counter
(max. 4 digits).
The first digit is displayed in the
reduce/enlarge indicator. Hold down the
" " key to display the last three digits.
•
Displays the total copy paper jam counts
by location (max. 4 digits).
SP Number Paper Jam Location Symbol
SP7-504-001
SP7-504-002
SP7-504-003
SP7-504-004
SP7-504-005
SP7-504-006
The first one digit is displayed in the
reduce/enlarge indicator. Hold down the
" " key to display the last three digits.
•
Displays the total original jams in the DF
by location (max. 4 digits).
SP7-505-001: Feed-in section
SP7-505-002: Feed-out section
The first digit is displayed in the
reduce/enlarge indicator. Hold down the
" " key to display the last three digits.
•
63
SERVICE PROGRAM MODE
Settings
Y
A
B
C
Z
R
