Speakman SA-2203 Instructions

Instructions for Models:

SB-1811
SB-1811-E
Need Help?
For additional assistance or service call:
SPEAKMAN Company
400 Anchor Mill Road
New Castle, DE 19720
PHONE: 800-537-2107
EMAIL: customerservice@speakman.com
WEB: www.speakman.com
92-SB-1811-R2

What You Need To Know:

Tools:

Required:

*Adjustable *Groove Joint *Phillips
Wrench Pliers Screwdriver
*Teflon Tape

Helpful:

*Supply Lines *Basin Wrench *Pipe Wrench
*Hacksaw *Tubing Cutter *Utility Knife
*Eye Protection

Important Notes:

Be sure to read instructions thoroughly before
beginning installation. Do not overtighten any
connections or damage may occur. This faucet has
an operating range of 20-80 psi.
Safety Tips:
Cover your drain to prevent loss of parts.
Be sure to wear eye protection while cutting pipe.
Maintenance:
Your new Lavatory Faucet is designed for years
of trouble-free performance. Keep it looking new
by cleaning it periodically with a soft cloth.
Avoid abrasive cleaners, steel wool, and harsh
chemicals as these will dull the finish and void
your warranty.
Shut off water supplies. Remove old faucet. Clean
①
sink surface in preperation for installation of new
faucet. Place Faucet Body (1), Slip Ring (2), and
optional Deck Plate (3), as well as optional Putty
Plate (4) in order shown below.
1
3
4
Slide Rubber Washer (1), and Metal Washer (2)
②
onto threaded shank of faucet. Thread Mounting
Nut (3) onto faucet shank until hand tight. Use phillips
screwdriver to tighten Mounting Screws (4), securing the
faucet to the sink.
1
3
4
③
Connect Hose with red stripe (1), to HOT water
supply. Connect Hose with blue stripe (2), to the
COLD water supply. Use adjustable wrench to tighten
connections. Take care to not overtighten. Note: Angle
valves shown are not included.
1 COLD
HOT 3/8"
Compression
Fitting
④
Insert Drain Body (1) into drain hole of sink from
above.From underneath install Rubber Gasket (2),
Red Fiber Washer (3), and Lock Nut (4) in the order
shown below. Secure Lock Nut with Groove Joint Pliers.
Take care to not overtighten.
1
3
4
Install Rubber Washer (2) between Lower Drain
⑤
Pipe (3) and Drain Body (1). Thread Lower Drain
Pipe (3) onto Drain Body (1).
1
3
