SPEAKMAN GRAVITYFLO
PORTABLE EYE WASH
WITH WATER HEATING UNIT
INSTALLATION INSTRUCTIONS
KEEP THIS MANUAL WITH EMERGENCY FIXTURE
CONTENTS:
I.
Introduction
II.
Specifications
III.
Installation
IV.
Operation in Emergency Situation
V.
Periodic Cleaning & Maintenance
VI.
Replacement Parts
ANSI Z358.1 for portable eyewash units and
ANSI A117.1-1986 for barrier-free design.
Conforms to UL 499 and CSA 22.2 No.8
PO Box 191 Wilmington, DE 19899
SE-4350
OWNERS' MANUAL AND
IAPMO (E-6417) Approved to meet
SPEAKMAN
Visit us on the web at www.speakmancompany.com
1
®
Phone: 800-537-2107 Fax: 800-977-2747
92-3136-R1
11/15/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRAVITYFLO SE-4350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Speakman GRAVITYFLO SE-4350

  • Page 1 SPEAKMAN GRAVITYFLO PORTABLE EYE WASH SE-4350 WITH WATER HEATING UNIT OWNERS’ MANUAL AND INSTALLATION INSTRUCTIONS KEEP THIS MANUAL WITH EMERGENCY FIXTURE CONTENTS: Introduction Specifications III. Installation Operation in Emergency Situation Periodic Cleaning & Maintenance Replacement Parts IAPMO (E-6417) Approved to meet ANSI Z358.1 for portable eyewash units and...
  • Page 2: Product Overview

    Speakman's HEATED GRAVITYFLO Eyewash is designed to exceed the ANSI recommended flow for portable eyewash. Model SE-4350 makes emergency protection instantly available when required. CAUTION: This Eyewash container should only be used with water and the Speakman SE-4210 Anti-Microbial Water Preservative. SPEAKMAN ®...
  • Page 3: Specifications

    ___________________________________________ SPECIFICATIONS Tank: 20 Gallon, Speakman Blue, High Density Polyethylene Spray Heads: (2) Black, Molded Polypropylene Activator (Pull Strap): Yellow, Thermoplastic Elastomer Wall Mounting Bracket: 11 Gauge Steel with Black Powder Coat Finish Fill Cap: Black, High Density Polyethylene Side Outlet: Integral ¾” GHT for Draining Tank & Connecting the SE-4920 Drench Hose Option Drain: Integral ¾”...
  • Page 4: Installation

    For safety reasons, Speakman Company highly recommends your SE-4350 be filled to the maximum capacity of 20 US gallons for optimal Eyewash performance. b) Start with a clean Eyewash container. c) Check to see that drain plug is in place; fill with 20 gallons of water and a Speakman SE-4210 antimicrobial water preservative. SPEAKMAN ®...
  • Page 5: Operation

    Tampering with the unit or using it for non-emergency purposes may cause the unit to have a low water level when needed, as there is no water level indicator. SPEAKMAN ® PO Box 191 Wilmington, DE 19899 Phone: 800-537-2107 Fax: 800-977-2747 Visit us on the web at www.speakmancompany.com...
  • Page 6 Scrub all components clean with hot soapy water and rinse thoroughly. Reassemble and replace on unit. Test water flow to be sure unit is operational. Reminder Speakman Company recommends weekly testing for optimum performance and recording of results for maximum efficiency. Several test record tags are provided for this purpose. SPEAKMAN ®...
  • Page 7: Replacement Parts

    12" TAMPER-EVIDENT TIES (QTY.6) EYEWASH TESTING RECORD DATE INITIALS DATE INITIALS DATE INITIALS DATE INITIALS DATE PURCHASED MODEL NO. SUPPLIER OPTION SPEAKMAN ® PO Box 191 Wilmington, DE 19899 Phone: 800-537-2107 Fax: 800-977-2747 Visit us on the web at www.speakmancompany.com...
