Speakman SA-1002 Installation Instructions

INSTALLATION INSTRUCTIONS
SA-1002
SA-1010
Slide Bar
with Adjustable Hand Shower Bracket
92-SA-1002-03
NEED HELP?
For additional assistance or service please contact:
POSITION IN PLACE
Place Slide Bar Assembly into the desired mounting position. Take care that the Slide Bar is
2
oriented in a vertical position. Using a pencil, lightly trace outline of End Brackets on to wall.
X2
DRILL MOUNTING HOLES
Drill 1/4" holes in marked locations. If drilling into tile, be sure to use a drill bit designated for tile. If
4
mounting directly into stud or wood wall, drilling mounting holes is not required.
TOOLS & SUPPLIES NEEDED
Pencil Measuring Level
Tape
Drill Drill Bit Tile Drill Bit
1/4" 1/4"
Phillips Phillips Mounting
Drive Bit Screwdriver Hardware
(Included)
Hex Key Eye Protection
Wrench
(Included)
www.speakman.com
800-537-2107
X4
+
OR
IMPORTANT
SAFETY TIPS:
Be sure to read and understand all instructions
before beginning installation.
Inspect all connections after installation.
Cover the drain to avoid loss of parts.
Be sure to wear proper eye protection.
Do NOT over tighten any connections or damage
may occur.
Observe all local plumbing and building code
IMPORTANT:
This item is NOT designed for use as a grab bar.
Do not mount in locations where product is likely
to be used as a grab bar.
FINISH MAINTENANCE:
Your new product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. Avoid
abrasive cleaners, steel wool, and harsh
chemicals as these will dull the finish and void
your warranty.
WARRANTY:
Warranty information can be found at:
www.speakman.com
CALIFORNIA PROPOSITION 65
CALIFORNIA PROPOSITION 65:
WARNING:
This product can expose you to
chemicals including lead, which is known to the
State of California to cause cancer and birth
defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov.
MARK MOUNTING LOCATIONS
Center Mounting Bracket within traced outline. Mark the 2 locations with a pencil.
3
X4
INSERT PLASTIC ANCHORS
Push the Plastic Anchors (x4) into the drilled holes. Ensure the plastic anchors are flush with the
5
wall. (Note: Plastic Anchors provided may not be suitable for all types of wall construction, seek
professional help if in doubt).
PREPARE FOR MOUNTING
Using the included Hex Key Wrench,
1
loosen, but do not remove the Set Screws
and remove the Mounting Brackets from
the Slide Bar Assembly.
X2
X4
